VIP4Tools Coaxial
User and
Maintenance Manual

TABLE OF CONTENTS

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Manual drafted in compliance with
EC Directive 06/42
Dropsa products can be purchased from Dropsa branches and authorized distributors,
www.dropsa.com/contact or contact us sales@dropsa.com
C2086IE- WK 21/07
visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIP4Tools Coaxial and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DROPSA VIP4Tools Coaxial

Summary of Contents for DROPSA VIP4Tools Coaxial

  • Page 1: Table Of Contents

    Manual drafted in compliance with C2086IE– WK 21/07 EC Directive 06/42 http://www.dropsa.com Via Benedetto Croce, 1 Dropsa products can be purchased from Dropsa branches and authorized distributors, visit Vimodrone, MILANO (IT) www.dropsa.com/contact or contact us sales@dropsa.com t. +39 02 250791...

  • Page 2: Introduction

    1. INTRODUCTION This User and Maintenance Manual refers to VIP4Tools Coaxial. You can find additional copies and newer revisions of this document from our website http://www.dropsa.com. Alternatively contact one of our Sales Offices. This manual contains important information on health and safety issues for the personnel. It is recommended to attentively read this manual and carefully keep it in good condition so that it is always available to personnel requiring to consult it.

  • Page 3: Machine Components

    Air-oil modules (from 1 to 8 outlets), consisting in mini-pumps with adjustable flowerate and assembled  on sub-bases;  SAMBA level sensor, which indicates lubricant minimum level via a N.O. electric contact.  (To reverse N.O. to N.C., please contact Dropsa Eng. Dept.); Air-oil lubrication nozzle.  MINIMUM ELECTRIC LEVEL OIL REFILL PLUG...

  • Page 4: Unpacking And Installing The Panel

    6. UNPACKING AND INSTALLING THE PANEL 6.1 UNPACKING Once a suitable location has been found to install the unit, remove the panel from package. Check the unit has not been damaged during transportation or storage. No particular disposal procedures are necessary as package materials are no dangerous for health or environment.
  • Page 5 6.5 PNEUMATIC CONNECTIONS (see drawing on ch. 12. DIMENSIONS) Connect the air supply to the inlet push-in by means of a Ø 6 mm (Ø 0.23 in.) nylon pipe. In order to stop air supply a check valve must be arranged. 6.5.1 CONNECTION DIAGRAM CONNECTION DIAGRAM PUMP WITH SOLENOID VALVE CONNECTION DIAGRAM PUMP WITH PNEUMATIC TIMER...

  • Page 6: Instructions For Use

    COAXIAL VERSION 6.8 ELECTRIC WIRING WARNING: At the end of all connecting operations, make sure that pipes and wires are safe from impacts and carefully fixed. 7. INSTRUCTIONS FOR USE 7.1 PRIOR TO MACHINE START-UP Verify the unit is undamaged. ...

  • Page 7: Troubleshooting

    The following diagnostic table indicates the main anomalies which may be encountered, the probable causes and possible solutions. If you cannot solve the problem, do not attempt to disassemble parts of the machine but contact the Engineering Department of DROPSA S.p.A. ANOMALY...

  • Page 8: Maintenance Procedure

    9. MAINTENANCE PROCEDURE The machine does not require any special tool for check or maintenance tasks. However, it is recommended the use only of appropriate and in good conditions tooling, protective devices (gloves) and clothing (626/94 and DPR 547/55) to avoid injury to persons or damage to machine parts.
  • Page 9 11.3 ACCESSORIES PART N° DESCRIPTION 3132572 Timer Kit 1s ÷ 1 min. EV – 24 V DC: with the kit must be ordered also: part. num. 39979 – connector - quantity 1; 3132574 part. num. 53923 – screw - quantity 3; part.

  • Page 10: Dimensions

    12. DIMENSIONS 1 Lt. (0.22 galloni) 3 Lt. (0.66 galloni) Number of elements mm (in) 255 (10.04) (14.3) (15.4) (16.5) (17.6) (18.7) (19.8) (20.9) (22.0) 220 (8.66) 117,5 (4.6) Air outlet tube Ø 6 Air outlet tube Ø 3 Peso kg (lbs) (5.9) (7.0)

  • Page 11: Handling And Transportation

    13. HANDLING AND TRANSPORTATION Prior to shipping, the equipment is carefully packed in cardboard package. During transportation and storage, always maintain the pump the right way up as indicated on the box. On receipt check that package has not been damaged. Then, storage the machine in a dry location.
