Q2LI / Q2LID
D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
C#4001609
Version Française: www.enviro.com/fr.html
If the information in this manual is not followed exactly, a
installer, service agency or the gas supplier.
CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS
CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES
50-3057
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q2LID and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro Q2LID

Summary of Contents for Enviro Q2LID

  • Page 1 Q2LI / Q2LID D I R E C T V E N T F I R E P L A C E - I P I OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the Q2LI / Q2LID unit is pulled out of its installation, and A barrier designed to reduce the risk of burns from the the vent-air intake system is disconnected for any reason,...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals....................5 Specifications......................6 Dimensions.....................6 Rating Label Location..................6 Operating Instructions....................7 Lighting and Turning Off Instructions..............7 Air Shutter......................8 Normal Sounds During Operation..............8 Remote Control Operation.................8 Initializing the System for the First Time............11 Switching to Continuous Pilot................11 Fan Control.....................13 Maintenance And Service....................14 Routine Maintenance..................14...

  • Page 5: Codes And Approvals

    This appliance has been tested by INTERTEK and found to comply with the established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (Q2LI / Q2LID; NATURAL GAS, PROPANE GAS) TESTED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES...

  • Page 6: Specifications

    874mm 874mm VIEWING AREA 27 11/16" 29.1/4" 703mm 743mm 6" 153mm 15 13/16" 401mm GAS LINE Figure 1. Q2LI / Q2LID Dimensions - Top Vent 14 15/16" 34 3/8" 380mm 874mm 34.3/8" 874mm VIEWING AREA 29.1/4" 27 11/16" 743mm 703mm 6"...

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 8: Air Shutter

    Operating Instructions hutteR The air shutter adjustment lever is on the right hand side of the control area (see Figure 4). The air shutter allows the amount of air coming into the fireplace to be adjusted in order to accommodate different climates and venting arrangements.

  • Page 9: Remote Control Operation

    Operating Instructions For Q2LID models refer to the separate Dexen user manual supplied for remote control operations. emote ontRoL peRations Proflame 2 is a modular remote control system that directs the functions of the Westport. The Proflame 2 TMFSLA is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance.
  • Page 10 Operating Instructions CPI Mode Figure 6: Proflame 2 Transmitter LCD Screen. (ifc): ntegRateD iRepLace ontRoLLeR The Proflame 2 IFC (Figure 7) connects directly to the gas valve, stepper motor, pilot and covection fan with a wiring harness. The IFC is mainly powered by 120 VAC but can also run off a battery backup four (4) AA type batteries for shorter periods of time.

  • Page 11: Initializing The System For The First Time

    When the Q2LI / Q2LID is turned off press the mode key to index to the constant pilot (CPI) mode icon (see figure 9). Pressing the up arrow key will select Continuous Pilot Ignition (CPI) and pressing the down arrow key will return to IPI.
  • Page 12 Operating Instructions Turn off the Appliance Press the ON/OFF Key on the Transmitter. The Transmitter LCD display Room Temperature will only show the room temperature and Icon (see Figure 10). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.

  • Page 13: Fan Control

    Operating Instructions Fan Control The Q2LI comes with a convection fan that can be controlled with the Transmitter. The fan speed can be adjusted thorugh six (6) speeds. To control the fan press the MODE key (Figure 5) to index to the fan control icon (Figure 13).

  • Page 14: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 15). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 15: Cleaning Decorative Surfaces

    Maintenance And Service Leaning ecoRative uRfaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked/unwrapped carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints. It is important to note that fingerprints and other marks can leave a permanent stain on plated finishes.

  • Page 16: Burner Removal

    Maintenance And Service uRneR emovaL The burner may need to be removed for a few reasons, including cleaning under the burner or to be replaced all together. Proceed only when the unit has completely cooled down. Step 1: Remove the glass door as shown in the m aIntenance anD erVIce...

  • Page 17: Fuel Conversion

    Maintenance And Service onveRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.

  • Page 18: Conversion Kit Installation

    Maintenance And Service Conversion Kit Installation: 1. Turn the unit off by pressing the ON/OFF Key on the remote and shut off gas supply at the shut-off valve upstream of the unit. CAUTION: The gas supply must be shut off prior to disconnecting the electrical power and before proceeding with the conversion.
  • Page 19 Maintenance And Service 13. Relight the main burner in both the “HI” and “LO” positions to verify proper burner ignition, operation and proper flame appearance. Confirm the inlet and manifold pressures are within the acceptable ranges as directed in section I .

  • Page 20: Initial Installation

    Initial Installation QUALIFIED INSTALLERS ONLY ntRoDuction This section of the owner’s manual is for the use of qualified technicians only. Fireplace placement, hearths, facing, mantels, and venting terminations will be covered, as well as the gas and electric systems. There are several installation safety guidelines that must be adhered to. Please carefully read the safety precautions at the front of this manual.

  • Page 21: Rear Vent Conversion

    Initial Installation QUALIFIED INSTALLERS ONLY onveRsion For smaller openings the Q2LI / Q2LID can be converted from a top vent to a rear vent unit. DV Adaptor Exhaust Tube Must use 1/4” 8-32 Bolts to secure Cover Plate and DV Adaptor Cover Plate Figure 24A.

  • Page 22: Corner Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation The dimensions for installing a fireplace in the corner of a room are given in Figures 27A and 27B. Refer to “I ” for allowable pipe lengths. nItIal nstallatIon llowaBle axIal onfIguratIons WARNING: Do not interfere with the structural integrity of the walls. 8 "...

  • Page 23: Framing Plate Installation

    A steel framing plate is included with your Q2LI / Q2LID. The plate does not come installed on the unit but it attaches very easily with a 1/4” hex driver as shown below. This plate is used as a supportive surface to fill in the air gap above the unit in the installation construction.

  • Page 24: Mantle And Non-Combustible Clearances

    & n antLe ombustibLe LeaRances When installing the Q2LI / Q2LID as a zero clearance fireplace the correct clearances and materials must be used: : A minimum 10” (254mm) of non-combustible facing material must be used above the bove firebox opening (in front of the included steel framing plate). The non-combustible is only required directly over the firebox opening and does not need to span the entire width of the framing plate.

  • Page 25: Direct Vent

    The vent length for the Q2LI / Q2LID must be between 6” (150 mm) and 40’ (12.2 m). This model is vented with co-axial 4” intake, 6 5/8” exhaust aluminum or stainless steel approved rigid vent leading into a vertical or horizontal termination cap.

  • Page 26: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 30. Vent Termination Restrictions, refer to Table 3 Table 3: Vent Termination Clearances Letter Canadian Installation US Installation Description...

  • Page 27: Venting Clearances

    Initial Installation QUALIFIED INSTALLERS ONLY enting LeaRances A 1” (25 mm) clearance to combustibles must be maintained around any vertical vent pipe. Around a horizontal vent pipe, the clearance to combustibles should be 2” (51 mm) above and 1½” (38 mm) on the sides and bottom.
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY Table 6: Vent Part Numbers (must state if galvanized or black wanted) M&G Duravent Selkirk Amerivent Metal-Fab Description Direct Vent Pro EXCELDirect DIRECT-TEMP AMV DV Sure-Seal DV* 46DVA-06 4DL6 4DT-06 6” pipe length 7” pipe length 46DVA-09 4DL9 4DT-09...

  • Page 29: Horizontal Termination - Rear Vent

    The Q2LI / Q2LID can be installed as a natural gas Appliance in rear vent applications with no vertical rise within the parameters as shown in Figures 32 and 33. If any vertical rise is required a top vent configuration should be used.

  • Page 30: Allowable Co-Axial Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe xiaL onfiguRations Figures 34 shows the range of venting options for top vented configurations only using either vertical or horizontal terminations; any layout that remains within the shaded area is acceptable. Having the fewest number of elbows is ideal as they tend to disrupt air movement. Using 45˚ elbows is preferable to using 90˚...

  • Page 31: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination NOTES: 1. Horizontal pipes must not be level. For every 12” (305 mm) of horizontal travel (away from the stove), there should be at least ¼” (6.4 mm) of vertical travel. Never allow the vent to run downward, as this could cause high temperatures or even present the possibility of a fire.
  • Page 32 Initial Installation QUALIFIED INSTALLERS ONLY Exhaust Restrictors: Your Q2 fireplace is supplied with 2 different exhaust restrictors. Your venting configuration will determine which restrictor plate you will need to use. Look at the Fig. 24 on page 26 to determine which restrictor your installation will require. WARNING: IMPROPERLY SETTING THE RESTRICTOR SIZE CAN ALTER THE LOOK AND EFFICIENCY OF YOUR FIREPLACE AND IN CERTAIN SITUATIONS CAN CAUSE OVERHEATING ISSUES WHICH CAN LEAD TO BUILDING FIRE.

  • Page 33: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY Step 4. With the hole now framed, the wall thimble installed, and the pipe extending into the wall, proceed to the outside. Attach the termination to the pipe using RTV and Mil-Pac or Rutland No 78 Stove and Gasket Cement to seal joints.

  • Page 34: Flex Vent

    Initial Installation QUALIFIED INSTALLERS ONLY Step 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.

  • Page 35: Gas Line Connection And Testing

    Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’ (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 37).
  • Page 36 Use 4X7 Flex Adapter Kit [50-3788]: This kit will allow you to adapt co-axial flex to the fireplace, make your Any Enviro Approved vent run, then adapt back to rigid venting (flex not Rigid Venting included).
  • Page 37 Figure 40: Fully Labeled Gas Valve. TO TEST VALVE PRESSURES See Dexen User Manual for Q2LID valve details The pressure taps are located on the top right of the valve shown in Figure 40. • Turn set screw 1 turn counter clockwise to loosen, ”...

  • Page 38: Electrical Requirements

    If any of the original wire as supplied with the appliance must be replaced, it must be replaced with 18 AWG wire with a temperature rating of 105°C Note: For Q2LID specific wiring diagram refer to the Dexen user manual supplied and label attached to the fireplace.

  • Page 39: Secondary Installation

    Secondary Installation aneL nstaLLation ptionaL These instruction are applicable to both the Q2 model brick liner set (50-2977) and the Q2 model enamel porcelain liner set (50-2978). Step 1: Be sure the fireplace is cool. Remove the door, the log set (if installed), log grate, burner tube, and the upper and lower air diverters.

  • Page 40: Fire Grate And Log Set Installation

    Secondary Installation Rate anD nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. All of the logs come with either a notch or ledge to make alignment easier. Using the pictures provided, carefully set the logs in place (see Figures 37 through 41).
  • Page 41 Secondary Installation Rate anD nstaLLation continueD STEP 5 STEP 6 Break up the ember wool as fine as possible (clump Place Centre Top Crossover Log #8 at an angle on top the wool together and separate it using the supplied of the Rear Log #10 and Left Mid Log #5 pins.

  • Page 42: Trouble Shooting

    Trouble Shooting Q2LiD iagnostic Lash oDes Does not appLy to moDeLs 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset.
  • Page 43 Trouble Shooting Note: For Q2LID specific troubleshooting refer to the Dexen user manual supplied Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high ·...

  • Page 44: Parts List

    Parts List Table 10: Q2 Parts List Note: For Q2LID specific replacement parts refer to the Dexen user manual supplied Reference Part Description Part Number Number Door Release Tool 50-2510 Convection Fan Only 50-2493 Convection Fan w/Mount 50-3836 S.I.T. 885 Valve w/ NG Stepper Motor...

  • Page 45: Parts Diagram

    Parts Diagram Page 45...

  • Page 46: Notes

    Notes Page 46...

  • Page 47: Warranty

    Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.

  • Page 48: Installation Data Sheet

    NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com Winter 2021 C-15721 Page 48...
