D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
50-3064
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Enviro Q4

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 50-3064 Version Française: www.enviro.com/fr.html...
  • Page 2: Safety Precautions

    afety recautionS WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the Q4 unit is pulled out of its installation, and the vent- A barrier designed to reduce the risk of burns from the air intake system is disconnected for any reason, ensure that...
  • Page 4: Table Of Contents

    able of ontentS Safety Precautions..................2 Table of Contents....................4 Codes And Approvals..................5 Specifications....................6 Dimensions..................6 Rating Label ..................7 Door Removal and Installation..............8 Installation Set-Up...................8 Firebox Liner Installation...............8 Log Burner / Ember Bed Installation............10 Log Set Installation................11 Porcelain Panel Kit Installation............14 Start-Up & Operation..................15 Normal Sounds During Operation............15 Remote Control Operations..............15 Technical Data..................15...
  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local Enviro dealer.
  • Page 6: Specifications

    PecificationS imensions 4” (101mm) 20” (508mm) Figure 1. Dimensions of the Firebox. ating abeL ocation The Rating and Lighting instruction label is located below the door frame, underneath the firebox attached to a chain. To access the label, slide the plate forward out from under the firebox. Always return it when finished.
  • Page 7: Rating Label

    DO NOT REMOVE THIS LABEL / N'ENLEVEZ PAS CETTE ETIQUETTE C-14447   VENTED GAS FIREPLACE HEATER ENVIRO MODEL: FOYER AU GAZ A EVACUATION MODELE ENVIRO: 3151093 NAT: (Gaz naturel) LPG (Propane) Certified for use in Canada & USA Certifié pour installation au Canada et aux Etats-Unis.
  • Page 8: Door Removal And Installation

    nStallation emovaL anD nstaLLation 1) The fireplace door is hung on two (2) hooks on the top of the firebox. The two (2) door latches at the bottom of the firebox hook over the tabs on the bottom of the door frame. Large hooked end for removing the door.
  • Page 9 nStallation 1. Prior to installing the firebox liners, you will need to ensure the Rear Brick Rear Brick Panel Support is in the correct position. The support Panel Support (in lower position) is located at the back of the firebox (see Figure 9) and can be installed in two (2) positions.
  • Page 10: Log Burner / Ember Bed Installation

    nStallation uRneR mbeR nstaLLation 1. Use the two (2) T-20 screws provided; install the rear burner shield onto the back of the burner. The mounting holes are just above the mixing tubes at the rear of the burner, refer to Figure 15. Burner Mounting Brackets Mixing Tubes...
  • Page 11: Log Set Installation

    nStallation Slot Grate Tab Figure 20: Slot for Firebox Grate. Figure 21: Tab on Firebox Grate. 4. Install the burner accent pieces as shown in Figure 19. There are a left, a right and a front ceramic trim. On each side of the burner and on the inside of each burner side accent pieces there is a slot, which should be aligned in order to position the log grate correctly (see Figure...
  • Page 12 nStallation Figure 25: Log 3 in Place. Figure 26: Log 4 in Place. 2. Install Left Rear log with the right side on the grate, using a groove on the bottom of the log to index itself to the grate (see Figure 24). The right side self locates on the first log.
  • Page 13 nStallation Figure 30: Log 8 in Place. Figure 31: Log 9 in Place. 8. Situate Log 8 between the right grate finger, the right firebox liner and the grate cross bar (see Figure 30). On the back of the log near the top end is a ceramic pin, this pin sits into a groove on the top of Log 9.
  • Page 14: Porcelain Panel Kit Installation

    nStallation oRceLain aneL nstaLLation 1. Install the porcelain Light Covers over the Light Cover Base. The tabs on the back of the Light Cover slide down behind the Light Cover Base. Refer to Figures 96 & 97. 2. Ensure the Rear Brick Panel Support is in the lower position.
  • Page 15: Start-Up & Operation

    PeRations The Proflame GTMF is a modular remote control system that directs the functions of the Q4. The Proflame GTMF is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance. The system controls a remotely actuated 120V/60Hz power outlet, fan speed through six (6) levels and has a constantly powered 120V/60Hz power outlet.
  • Page 16 & o tart Peration TRANSMITTER (Remote Control with LCD Display) The Proflame Transmitter uses a streamline design with a simple button layout and informative LCD display (Figure 35). The Transmitter is powered by three (3) AAA type batteries. A Mode Key is provided to Index between the features and a Thermostat Key is used to turn on/off or index through Thermostat functions (Figure 35 &36).
  • Page 17: Wall Mounting The Receiver

    & o tart Peration ounting eceiveR The receiver can be placed inside a standard Junction type wall box either by itself or in combination with a light dimmer control. This installation can take place up to 8’ft (2.4m) from the appliance control valve. 1.
  • Page 18 Remote Actuated Accent Lights The Q4 is shipped with two (2) firebox accent lights. They are connected to the auxiliary power outlet of the Proflame Fan Control Module. The lights can be turned on or off using the Auxiliary function on your remote control.
  • Page 19 Split Valve Operation The split flow operation on the Q4 turns off the rear section of the burner, greatly reducing the heat output of the unit. If you’d like to have the fireplace on but would not like to have as much heat in the room, you can turn off this function.
  • Page 20: Air Shutter Adjustment

    Turn off the appliance if it is not going to be attended for any length of time. Always place the Transmitter where children cannot reach it. hutteR Djustment The Q4 is setup to work with two (2) gas orifices. The orifice on the left (looking...
  • Page 21: Check For Proper Burner Flame

    Lame Once your new Q4 has run through the “first fire”, (see section on first firing) check for proper flame appearance. A gas appliance’s performance is dependent on several factors. Vent configuration, fuel type, altitude and restrictor setting are all factors in how the final flame appears in the firebox. The fireplace must be operated for a minimum of 30 minutes or the flame will not normalize.
  • Page 22: Service / Maintenance

    & c afety creen leaning The safety screen included with this stove can be removed for cleaning. Removal and re-installation is show in the steps below. Warning: The safety screen becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before begining this installation.
  • Page 23: Lighting Instruction Label

    VENTED GAS FIREPLACE HEATER ENVIRO MODE appliance needs fresh air for safe operation and must be installed with provisions for FOYER AU GAZ A EVACUATION MODELE ENVIRO: combustion and ventilation air. See installation and operating instructions manual. Keep burner and control compartment clean.
  • Page 24: Light Bulb Replacement

    The Q4 will require maintenance, which can usually be planned on an annual basis. Service should include cleaning, battery replacement, light replacement, venting inspection and inspection of the burner, log sets and firebox liners. The vemting systems should be periodically examined by a qualified agency.
  • Page 25: Notes

    oteS...
  • Page 26 oteS...
  • Page 27: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...
  • Page 28: Installation Data Sheet

    NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc _________________________________________ MAIN BURNER ORIFICE:__________# DMS PHONE:___________________________________ PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 March 2, 2015 www.enviro.com C-14446...
