Q2L
D I R E C T V E N T F I R E P L A C E - N O V A
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
4001609
50-3054
Version Française: www.enviro.com/fr.html
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q2L and is the answer not in the manual?

Questions and answers

Related Manuals for Enviro Q2L

Summary of Contents for Enviro Q2L

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 4001609 50-3054 Version Française: www.enviro.com/fr.html Page 1...

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the Q2L unit is pulled out of its installation, and the vent- A barrier designed to reduce the risk of burns from the air intake system is disconnected for any reason, ensure that...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions ..........2 Codes And Approvals .

  • Page 5: Codes And Approvals

    This appliance has been tested by INTERTEK and found to comply with the established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (Q2L; NATURAL GAS, PROPANE GAS) TESTED TO: ANSI Z21.88-2014/CSA 2.33-2014 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 (R2009) GAS FIRED APPLIANCES FOR HIGH ALTITUDES...

  • Page 6: Specifications

    14 15/16" 34 3/8" 380mm 874mm VIEWING AREA 27 11/16" 703mm 6" 153mm 15 13/16" 401mm GAS LINE Figure 1. Q2L Dimensions - Top Vent 14 15/16" 34 3/8" 380mm 874mm VIEWING AREA 27 11/16" 703mm 6" 153mm 15 13/16" 401mm GAS LINE Figure 2.

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING...

  • Page 8: Pilot Light

    Operating Instructions iLot ight 1. Turn off the gas to the fireplace. If not recently done, remove the glass and let the unit air out for at least five (5) minutes to clear out any gas. Turn on gas to the heater. Leak test all joints with soapy water.

  • Page 9: Burner Lighting

    After the unit has gone through the first burn, turn the unit OFF, including the pilot, and let the unit get completely cold. Then remove the glass and clean it with a good gas fireplace glass cleaner, available at your local Enviro dealer. See “M DATE: 7/17/2014 aIntenance ”...

  • Page 10: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 11). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 11: Cleaning Decorative Surfaces

    Maintenance And Service Leaning ecoRatiVe uRfaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked/unwrapped carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints. It is important to note that fingerprints and other marks can leave a permanent stain on plated finishes.

  • Page 12: Burner Removal

    Maintenance And Service uRneR emoVaL The burner may need to be removed for a few reasons, including cleaning under the burner or to be replaced all together. Proceed only when the unit has completely cooled down. Step 1: Remove the glass door as shown in the M aIntenance anD erVIce...

  • Page 13: Fuel Conversion

    Maintenance And Service onVeRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 14 Maintenance And Service Conversion Kit Installation: Turn control knob on the gas valve to the “OFF” position and shut the gas supply off at the shut-off valve upstream of the unit. CAUTION: The gas supply must be shut off prior to disconnecting the electrical power and before proceeding with the conversion.
  • Page 15 Maintenance And Service Red o-ring Red o-ring is visible is not visible g) Re-attach the black protection cap that was removed in step a (Figure A). LPG Configuration Figure D. O-ring on valve screw. Reinstall the air diverters, burner tube, grate, and the ceramic log set as indicated in this manual. Reconnect the main gas line if it was disconnected and open the shut-off valve at the gas line to the unit.

  • Page 16: Initial Installation

    There are several installation safety guidelines that must be adhered to. Please carefully read the safety precautions at the front of this manual. NOTE: The Q2L comes as a top vent unit but can be converted to a rear vent. WARNING: Clearances must be sufficient to allow access for maintenance and service.

  • Page 17: Rear Vent Conversion

    Initial Installation QUALIFIED INSTALLERS ONLY onVeRsion For smaller openings the Q2L can be converted from a top vent to a rear vent unit. DV Adaptor Must use 1/4” Exhaust Tube 8-32 Bolts to secure DV adaptor Cover Plate Figure 14. Upper Mounting Holes...

  • Page 18: Corner Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation The dimensions for installing a fireplace in the corner of a room are given in Figures 17A and 17B. Refer to “I ” for allowable pipe lengths. nItIal nstallatIon llowaBle axIal onFIGuratIons WARNING: Do not interfere with the structural integrity of the walls. 8 "...

  • Page 19: Framing Plate Installation

    A steel framing plate is included with your Q2L. The plate does not come installed on the unit but it attaches very easily with a 1/4” hex driver as shown below. This plate is used as a supportive surface to fill in the air gap above the unit in the installation construction.

  • Page 20: Mantle & Non-Combustible Clearances

    (in front of the included steel framing plate). The non-combustible is only required directly over the firebox opening and does not need to span the entire width of the framing plate. : The Q2L can be placed on the floor if desired although it is recommended that it be Ront of raised aleast an inch or higher for more heat sensetive materials such as carpet or linoleum.

  • Page 21: Direct Vent

    The vent length for the Q2L must be between 6” (150 mm) and 40’ (12.2 m). This model is vented with co-axial 4” intake, 6 5/8” exhaust aluminum or stainless steel approved rigid vent leading into a vertical or horizontal termination cap.

  • Page 22: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 20. Vent Termination Restrictions, refer to Table 3 Table 3: Vent Termination Clearances Letter Canadian Installation US Installation Description...

  • Page 23: Venting Clearances

    Direct Vent GS 4” - 6 5/8” The Q2L fireplace has been tested and certified for use with AMERICAN METAL PRODUCTS “AMERIVENT DIRECT”, SIMPSON DURAVENT TYPE GS PIPE FOR GAS STOVES. SECURITY CHIMNEY’S “SECURE VENT DIRECT VENT SYSTEM” and SELKIRK “DIRECT-TEMP VENT SYSTEM” kits are available for horizontal and vertical venting.
  • Page 24 Initial Installation QUALIFIED INSTALLERS ONLY EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a Direct Vent GS starting collar in conjunction with Secure Vent, Direct-Temp, AmeriVent Direct, and EXCELDirect venting systems. Use of these systems with the Direct Vent GS starting collar is deemed acceptable and does not affect the Intertek WH listing of the appliance.

  • Page 25: Horizontal Termination - Rear Vent

    The Q2L can be installed in rear vent applications with no vertical rise within the parameters as shown in Figures 22 and 23. If any vertical rise is required a top vent configuration should be used. Approved horizontal termination 12”...

  • Page 26: Allowable Co-Axial Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe xiaL onfiguRations Figures 24 shows the range of venting options for top vented configurations only using either vertical or horizontal terminations; any layout that remains within the shaded area is acceptable. Having the fewest number of elbows is ideal as they tend to disrupt air movement. Using 45˚ elbows is preferable to using 90˚...

  • Page 27: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination NOTES: 1. Horizontal pipes must not be level. For every 12” (305 mm) of horizontal travel (away from the stove), there should be at least ¼” (6.4 mm) of vertical travel. Never allow the vent to run downward, as this could cause high temperatures or even present the possibility of a fire.

  • Page 28: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY NOTE: For Simpson Duravent only, place a bead of Mil-Pac or Rutland No 78 Stove and Gasket Cement on the outer edge of the inner exhaust pipe (non-flared end). Push the pipe sections together, then twist about ¼...
  • Page 29 Initial Installation QUALIFIED INSTALLERS ONLY Step 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
  • Page 30 Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3’ (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 28).

  • Page 31: Gas Line Connection And Testing

    Initial Installation QUALIFIED INSTALLERS ONLY onnection anD esting WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a 3/8”...

  • Page 32: Electrical Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL eQuiRements This Q2 will operate without external electrical power. This model has a Millivolt gas control which uses the pilot flame to generate enough electricity to operate the main burner. This appliance when equipped with a blower, must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY STANDARDS FOR ELECTRICAL INSTALLATIONS, OR THE NATIONAL ELECTRICAL CODE ANSI / NFPA 70 in the U.S.

  • Page 33: Electrical Fan Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL eQuiRements Optional Fan Kit (50-2981): The fan will not operate if the appliance is cold. Once the unit is lit and the fan is set to the desired level, the fan will automatically turn on upon reaching operating temperature. The fan will automatically turn off after the appliance has cooled down.

  • Page 34: Secondary Installation

    1. Remove the contents from the box and inspect for any damage to the fan assembly. If damage is noticed call your nearest ENVIRO dealer. Inspect the wirng harness and ensure it resembles Figure 1. 2. Disconnect the power source that will be coming into the appliance by flipping the circuit breaker to avoid personal injury or damage to the components.

  • Page 35: Panel Installation (Optional)

    Secondary Installation aneL nstaLLation PtionaL These instruction are applicable to both the Q2 brick liner set (50-2977) and the Q2 enamel porcelain liner set (50-2978). Step 1: Be sure the fireplace is cool. Remove the door, the log set (if installed), log grate, burner tube, and the upper and lower air deflectors.

  • Page 36: Fire Grate And Log Set Installation

    Secondary Installation Rate anD nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the flames can be “pinched” and will not burn correctly. All of the logs come with either a notch or ledge to make alignment easier. Using the pictures provided, carefully set the logs in place (see Figures 37 through 41).
  • Page 37 Secondary Installation Step 3: Install the small finger-shaped log into position. There is a notch cut out on the underside the will locate the log on the grate. Be sure the log rests in the center of the two grate arms and points straight up onto the smooth pad on the ember bed.

  • Page 38: Trouble Shooting

    Trouble Shooting Problem Possible Cause Solution The main burner does not The gas valve may not be on. • Check that the gas control knob is in the “ON” position. ignite when called for. Thermostat is not calling for • Adjust the thermostat several degrees above ambient heat.

  • Page 39: Parts List

    FPI Burner Switch EC-026 S.I.T. Nova Valve 50-1421 S.I.T. Pilot Assembly - Standing Pilot EC-015 120 Degree Fan Temperature Sensor EC-001 Q2L Log Tube Burner 50-3024 High Definition Log Set 50-2979 Electrical Box Strain Relief 50-3019 Electrical Box 50-3018 Door Complete...

  • Page 40: Parts Diagram

    Parts Diagram Page 40...

  • Page 41: Notes

    Notes Page 41...
  • Page 42 Notes Page 42...
  • Page 43 Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...

  • Page 44: Installation Data Sheet

    NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com September 2, 2015 C-14515 Page 44...
