Q1LI
D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
4001609
50-3000
Version Française: www.enviro.com/fr.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q1LI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro Q1LI

Summary of Contents for Enviro Q1LI

  • Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 4001609 50-3000 Version Française: www.enviro.com/fr.html...

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 • Do not abuse the glass by striking it or slamming the door shut. HOT GLASS WILL • If the Q1LI unit is pulled out of its installation, and the vent- CAUSE BURNS air intake system is disconnected for any reason, ensure that...

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions......................2 Table of Contents......................4 Codes And Approvals....................5 Specifications......................6 Dimensions.....................6 Rating Label Location..................6 Operating Instructions....................7 Lighting Instructions..................7 Air Shutter......................8 Normal Sounds During Operation................8 Remote Control Operations.................8 Initializing the System for the First Time..............11 Switching to Continuous Pilot ...............11 Fan Control.....................14 Maintenance And Service....................14 Routine Maintenance..................14...

  • Page 5: Codes And Approvals

    After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.

  • Page 6: Specifications

    (641mm) (420mm) 8 " (417mm) 120V Line Plug 8 " (136mm) 8 " (93mm) Figure 1. Q1LI Dimensions - Top Vent 8 " 4 " (350mm) (112mm) 8 " 2 " (168mm) (548mm) Figure 2. Q1LI Dimensions - Rear Vent &...

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. ighting anD uRning nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING:...

  • Page 8: Air Shutter

    The Proflame 2 GTMFL is a modular remote control system that directs the functions of the Q1LI. The Proflame 2 GTMFL is configured to control the on/off main burner operation, its flame levels and provides on/off and Smart thermostatic control of the appliance. The system controls a remotely actuated...
  • Page 9 Operating Instructions ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and a wiring harness to connect the Receiver to the gas valve, stepper motor and Fan Control Module. ATTENTION! - TURN “OFF”...
  • Page 10 Operating Instructions CPI Mode Figure 6: Proflame 2 Transmitter LCD Screen. (ifc): ntegRateD iRepLace ontRoLLeR The Proflame 2 IFC (Figure 7) connects directly to the gas valve, stepper motor, pilot and covection fan with a wiring harness. The IFC is mainly powered by 120 VAC but can also run off a battery backup four (4) AA type batteries for shorter periods of time.

  • Page 11: Initializing The System For The First Time

    When the Q1LI is turned off press the mode key to index to the constant pilot (CPI) mode icon (see figure 9). Pressing the up arrow key will select Continuous Pilot Ignition (CPI) and pressing the down arrow key will return to IPI.
  • Page 12 Operating Instructions Turn off the Appliance Room Temperature Press the ON/OFF Key on the Transmitter. The Transmitter LCD display will only show the room temperature and Icon (see Figure 10). A single “beep” from the IFC confirms reception of the command and both the pilot light (if the unit is not set to continuous pilot) and main burner will turn off.

  • Page 13: Fan Control

    Operating Instructions Fan Control The Q1LI comes with a convection fan that can be controlled with the Transmitter. The fan speed can be adjusted thorugh six (6) speeds. To control the fan press the MODE key (Figure 5) to index to the fan control icon (Figure 13).

  • Page 14: Maintenance And Service

    The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. Remove the door (see page 15). The replacement glass will come with a new gasket installed. Remove any silicone remnants from the door.

  • Page 15: Cleaning Decorative Surfaces

    Maintenance And Service Leaning ecoRative uRfaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked/unwrapped carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints. It is important to note that fingerprints and other marks can leave a permanent stain on plated finishes.

  • Page 16: Burner Removal

    Maintenance And Service uRneR emovaL The burner may need to be removed for a few reasons, including cleaning under the burner, converting the unit to a different gas type, or to replace the burner altogether. Proceed only when the unit has completely cooled down.
  • Page 17 Maintenance And Service Conversion Kit Installation: Turn the unit off by pressing the ON/OFF Key on the remote and shut off gas supply at the shut-off valve upstream of the unit. CAUTION: The gas supply must be shut off prior to disconnecting the electrical power and before proceeding with the conversion.
  • Page 18 Maintenance And Service 13. Relight the main burner in both the “HI” and “LO” positions to verify proper burner ignition, operation and proper fl ame appearance. Confi rm the inlet and manifold pressures are within the acceptable ranges as directed in section I .

  • Page 19: Initial Installation

    Please carefully read the safety precautions at the front of this manual. NOTE: The Q1LI comes as a top vent unit but can be converted to a rear vent. Warning: Clearances must be sufficient to allow access for maintenance and service.

  • Page 20: Rear Vent Conversion

    Initial Installation QUALIFIED INSTALLERS ONLY onveRsion For smaller openings the Q1LI can be converted from a top vent to a rear vent unit. Vent Collar Base Plate Step 1: Using a T20 screwdriver remove the vent collar, base plate, Exhaust Spigot cover plate and exhaust spigot (28 screws total) as shown in Figure 23.

  • Page 21: Insulating Material

    Initial Installation QUALIFIED INSTALLERS ONLY nsuLating ateRiaL Depending on the chosen vent configuration, either one or both pieces of insulating material supplied with the unit are required for correct installation. Rear Vent: When using the rear vent configuration both the ceramic board and fiberglass insulation are required. Place the ceramic board on top of the unit first and then place the insulation on top of the ceramic board as shown in Figure 25.

  • Page 22: Standoffs

    The Q1LI is supplied with two sets of standoffs that serve as a framing guide and must be used when the unit is being installed as a fireplace. The front set of standoffs mount to sides of the unit (see Figure 27)

  • Page 23: Corner Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation The dimensions for installing a fireplace in the corner of a room are given in Figures 29 and 30. Refer to “I nItIal ” for allowable pipe lengths. nstallatIon llowaBle axIal onfIguratIons Do not interfere with the structural integrity of the walls. 2 "...

  • Page 24: Mantle And Non-Combustible Clearances

    LeaRances When installing the Q1LI as a zero clearance fireplace the correct clearances and materials must be used: : A minimum 10” of ½” thick non-combustible facing material, with a R-Value no less than bove 0.26, must be used (see Figure 31).

  • Page 25: Direct Vent

    The vent length for the Q1LI must be between 7” (18 cm) and 44ft (13.4 m). This model is vented with co-axial 4” intake, 6 5/8” exhaust aluminum or stainless steel approved rigid vent leading into a vertical or horizontal termination cap.

  • Page 26: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination estRictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Figure 32. Vent Termination Restrictions, refer to Table 3. Table 3: Vent termination clearances. Letter Canadian Installation US Installation Description...

  • Page 27: Venting Clearances

    Direct Vent GS 4” - 6 5/8” The Q1LI fireplace has been tested and certified for use with AMERICAN METAL PRODUCTS “AMERIVENT DIRECT”, SIMPSON DURAVENT TYPE GS PIPE FOR GAS STOVES. SECURITY CHIMNEY’S “SECURE VENT DIRECT VENT SYSTEM” and SELKIRK “DIRECT-TEMP VENT SYSTEM” kits are available for horizontal and vertical venting.
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a Direct Vent GS starting collar in conjunction with Secure Vent, Direct-Temp, AmeriVent Direct, and EXCELDirect venting systems. Use of these systems with the Direct Vent GS starting collar is deemed acceptable and does not affect the Intertek WH listing of the appliance.

  • Page 29: Horizontal Termination - Rear Vent W/ No Rise

    The Q1LI can be installed in rear vent applications with no vertical rise within the parameters as shown in Figures 34 and 35. Approved horizontal termination 18” (46 cm) Max. vent length Approved through wall thimble Max.

  • Page 30: Allowable Co-Axial Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLowabLe xiaL onfiguRations Figures 36a & b show the range of possible vent confi gurations if the unit is top or rear vented, for vertical and horizontal terminations. Any layout that remains within the shaded areas is acceptable. Having the fewest number of elbows is ideal, as they tend to disrupt air movement.

  • Page 31: Co-Linear Venting Adapter Kit (50-2982)

    DapteR The Q1LI can be converted from solid co-axial venting to 3” (76mm) flexible co-linear venting to allow for installation into exisiting masonary fireplaces (see Figures 37-39). Co-linear venting can not be used in combustible chimney installations. This adapter kit is for vertical terminations only and can’t be connected to a chimney flue serving a seperate solid-fuel burning stove or appliance.
  • Page 32 Initial Installation QUALIFIED INSTALLERS ONLY Adapter Kit Installation: Vent Collar Base Plate Step 1: Using a T20 screwdriver 4” Exhaust Spigot remove the vent collar, base plate, cover plate and 4” exhaust spigot (28 screws total) as shown in Figure 38. The vent collar, base plate, and 4”...

  • Page 33: Air Restrictor Settings

    When installing the Q1LI with 8ft (2.44M) or more of vertical venting, either co-axial or co-linear, it may be necessary to restrict the fresh air supply in the firebox to control the combustion and flame appearance. Using the pair of air restrictors supplied with the unit, install them on each side of the firebox and adjust to the correct setting as outlined in the figure and table below.

  • Page 34: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination NOTES: 1. Horizontal pipes must not be level. For every 12 inches (305 mm) of horizontal travel (away from the stove), there should be at least ¼ inch (6.4 mm) of vertical travel. Never allow the vent to run downward, as this could cause high temperatures or even present the possibility of a fire.

  • Page 35: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY NOTE: For Simpson Duravent only, place a bead of Mil-Pac or Rutland No 78 Stove and Gasket Cement on the outer edge of the inner exhaust pipe (non-flared end). Push the pipe sections together, then twist about ¼...
  • Page 36 Initial Installation QUALIFIED INSTALLERS ONLY STEP 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
  • Page 37 Initial Installation QUALIFIED INSTALLERS ONLY NOTES: (1) If an offset is necessary in the attic to avoid obstructions, it is important to support the vent pipe every 3 feet (914 mm), to avoid excessive stress on the elbows, and possible separation. Wall straps are available for this purpose (see Figure 44).

  • Page 38: Solid Fuel Fireplace Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oLiD iRepLace nstaLLation Table 9: Min. Fireplace Dimensions Width Height Depth Fireplace Dimensions 20¼” (51.4 cm) 27½” (69.8 cm) 12½” (31.7 cm) Note: Space must be left for gas line on left side of unit for servicing purposes The base, sidewalls and top structure of the solid fuel firebox cannot be altered with the exception of: removal of dampers, removal of smoke shelf or baffle, removal of ember catches, removal of log grate, removal of viewing screen/curtain, and removal of doors.

  • Page 39: Gas Line Connection And Testing

    Initial Installation QUALIFIED INSTALLERS ONLY onnection anD esting WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the left side of the unit terminating in a 3/8”...

  • Page 40: Electrical Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY LectRicaL equiRements The fireplace must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current CSA C22.1 Canadian Electrical Code Part 1, Safety Standards For Electrical Installations, or The National Electrical Code ANSI / NFPA 70 in the US.

  • Page 41: Secondary Installation

    Secondary Installation Rate anD nstaLLation The placement of the logs is not arbitrary. If they are positioned incorrectly, the fl ames can be “pinched” and will not burn correctly. All of the logs come with either a notch or ledge, which make alignment easier. Using the pictures provided, carefully set the logs in place (see Figures 50 through 56).
  • Page 42 Secondary Installation Step 3: Install the big y shaped twig on the far left side by locating the bottom of it on the far left log grate upright. The twig should run parallel with the side of the fi rebox and the top will rest on the top of the ember bed.
  • Page 43 A small amount on the bottom side of the logs is normal. Remove and replace the logs in the same manner described above. If new coal nuggets or logs are required, contact your nearest ENVIRO dealer. Never operate the fi replace with the glass door removed.

  • Page 44: Optional Porcelain Panels (50-2939) Installation & Removal

    Secondary Installation (50-2939) i ptionaL oRceLain aneLs nstaLLation anD emovaL Turn off the gas control knob and allow the unit to cool. Please ensure that your porcelain panels have not been damaged. To Install Panels: 1. Remove the glass door by following the instruction in the “m aIntenance anD erVIce...

  • Page 45: Trouble Shooting

    Trouble Shooting iagnostic Lash oDes 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.

  • Page 46: Troubleshooting

    Troubleshooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high · Set the thermostat to a lower temperature ·...
  • Page 47 Troubleshooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.

  • Page 48: Parts List

    Battery Holder 4 x AA 50-3027 Fireplace Floor Pad 12” x 20” 50-3016 Co-Linear Vent Kit 50-2982 Q1LI Owners Manual 50-3000 Q1 Conversion Kit - LP to NG (IPI) 50-2994 Q1 Conversion Kit - NG to LP (IPI) 50-2984 12 oz. Can of Matallic Black Touch Up Paint...

  • Page 49: Parts Diagram

    Parts Diagram...

  • Page 50: Notes

    Notes...

  • Page 51: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...

  • Page 52: Installation Data Sheet

    � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com September 5, 2014 C-14396...
