Summary of Contents for Enviro Q4

Page 1 If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier. 50-3065 Version Française: www.enviro.com/fr.html...
Page 2: Safety Precautions
afety recautionS WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
Page 3 NEVER ALLOW CHILDREN shut. TO TOUCH GLASS. • If the Q4 unit is pulled out of its installation, and the vent- A barrier designed to reduce the risk of burns from the air intake system is disconnected for any reason, ensure that...
Page 4: Table Of Contents
able of ontentS Safety Precautions..................2 Table of Contents....................4 Codes And Approvals..................5 Specifications....................6 Dimensions..................6 Rating Label Location................6 Rating Label..................7 Planning Your Installation................8 Introduction..................8 Non-Combustible Material Zone............8 Typical Framing - Internal Chase............9 Typical Framing - External Chase............10 Typical Framing - Corner:..............11 Typical Framing - Sidewall and Mantel..........12 Typical Framing - Raised Hearth............13 Installation of Fireplace Facing............14 Installation of Optional Facing Trim.............15...
Page 5: Codes And Approvals
After the unit has gone through the first burn, turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local Enviro dealer.
Page 6: Rating Label Location
Figure 1. Dimensions of the Firebox. ating abeL ocation The Rating and Lighting instruction label is located below the door frame, underneath the firebox attached to a chain. To access the label, slide the plate forward out from under the firebox. Always return it when finished.
Page 7: Rating Label
DO NOT REMOVE THIS LABEL / N'ENLEVEZ PAS CETTE ETIQUETTE C-14447   VENTED GAS FIREPLACE HEATER ENVIRO MODEL: FOYER AU GAZ A EVACUATION MODELE ENVIRO: 3151093 NAT: (Gaz naturel) LPG (Propane) Certified for use in Canada & USA Certifié pour installation au Canada et aux Etats-Unis.
Page 8: Planning Your Installation
This illustration applies to any and all installations for the Q4 and should be used as the first reference before any others. Failure to comply with this requirement can lead to elevated operating temperatures, degradation of materials or even result in fire. If you are unclear about any details contained here, consult with your retailer prior to installation.
Page 9: Typical Framing - Internal Chase
lanning nStallation ypicaL Raming nteRnaL hase Figure 5. Typical Framing for Internal Chase - General. Figure 6. Typical Framing for Internal Chase - Detailed.
Page 10 lanning nStallation ypicaL Raming xteRnaL hase Figure 7. Typical Framing for External Chase - General. Figure 8. Typical Framing for External Chase - Detailed.
Page 11 lanning nStallation ypicaL Raming oRneR Figure 9. Typical Framing for Corner - General. Figure 10. Typical Framing for Corner - Detailed.
Page 12 lanning nStallation ypicaL Raming idewaLL and anteL The mantel’s maximum overhang is 10” (254mm) at the minimum height of 52¼” (1327mm) measured from the base of the fireplace. The mantel can extend 1” (25.4mm) further for every 1” (25.4mm) of height it is installed over the minimum height, as shown in Figure 12.
Page 13 lanning nStallation ypicaL Raming aised eaRth Warning: Failure to follow these guidelines may result in elevated operating temperatures, an inability to remove or install the door, or install the optional fronts that are available for this unit. non-combustible Hearth Insulation Board is required (supplied) installed between any non-combustible...
Page 14 There are a number of optional fronts available for use with the Q4. These fronts lift on and off of the fireplace, providing access to the fireplace for regular maintenance and service. You have 3 possible scenarios...
Page 15 lanning nStallation Figure 18. Option 2 - Fireplace Facing More Than 1” Figure 19. Option 3 - Any Fireplace Facing Without (25.4mm) Thick With Optional Fronts Installed. Optional Front Installed. nstaLLation oF ptionaL acing The Optional Facing Trim supplied with your fireplace is designed to fit between the supplied non-combustible board and the fireplace drywall flange.
Page 16 lanning nStallation nStallation of eceiver Figure 22. Receiver Installation. The Receiver is the heart of the remote control system. You need to access this receiver after installation to change the batteries (for operation during a power failure), to program a new remote / receiver combination and to operate a manual override should you lose your remote control or the batteries in the remote control lose their power.
Page 17 lanning nStallation * Horizontal Vent Sections rise ”/ft (21mm/m) * 40’ (12.19m) 35’ (10.67m) 30’ (9.14m) Only restrictors supplied with this appliance. Table 1: Vent Restrictor Sizes. Ø of Flue 25’ (7.62m) Restriction Restrictor 3.878” (98.5mm) 3.540” 20’ (6.10m) (89.9mm) 3.166”...
Page 18 Planning Your Installation eRmination estRictions QUALIFIED INSTALLERS ONLY Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Restriction Zone Gas Meter (Termination not allowed) Figure 24. Vent Termination Restrictions, refer to Table 2. Table 2: Vent termination clearances, refer to Figure 24. Letter Canadian Installation US Installation...
Page 19 The Q4 fireplace has been tested and certified for use with AMERICAN METAL PRODUCTS “AMERIVENT DIRECT”, SIMPSON DURAVENT TYPE GS PIPE FOR GAS STOVES. SECURITY CHIMNEY’S “SECURE VENT DIRECT VENT SYSTEM”, SELKIRK “DIRECT-TEMP VENT SYSTEM”, and EXCELDIRECT “ICC“...
Page 20 lanning nStallation Table 4: Approved Vent Manufacturers Manufacturer Trade Name Nominal Sizes 5” x 8” American Metal Products AmeriVent Direct 5” x 8” Security Chimneys International LTD Secure Vent 5” x 8” Selkirk Metalbestos Direct-Temp 5” x 8” Co-axial Vent Simpson Dura-Vent Direct Vent GS 5”...
Page 21 During the development of the Q4, we took into consideration that in some installations TV’s or flat panel monitors may be located above the mantel. Although we can not anticipate every possible installation variable, we took time to evaluate the suitability of the installation of a TV or Plasma display above the mantel. We carried out testing to evaluate what possible operating temperatures that may be experienced when the appliance was installed in an internal chase.
Page 22: Assembly Of The Unit
nStallation QUALIFIED INSTALLERS ONLY Lanning nstaLLation Prior to starting your venting installation, refer to the section on Allowable Vent Configurations to make sure your plans fall into the allowable limits of horizontal and vertical installations. When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements.
Page 23: Installation Of Non-Combustible Wall And Hearth Board
nStallation QUALIFIED INSTALLERS ONLY nstaLLation combustibLe eaRth oaRd Install the non-combustible wall board and hearth protector provided with the unit. The side boards are interchangeable and are secured with drywall screws (¾” screws provided), three (3) to each side of the unit and three (3) to each side frame member.
Page 24: Horizontal Installation
nStallation Read all instructions carefully before starting the installation. Failure to follow these instructions may create a fire or other safety hazard, and will void the warranty. INSTALLATION PRECAUTIONS: • Do not install any damaged venting or vent components. • Do not modify any vent or termination component. •...
Page 25 nStallation (1) Any horizontal run of vent must have a ¼ inch (6mm) rise for every 1 foot (305mm) of run towards the termination. Never allow the vent to run downward. This could cause high temperatures and may present the possibility of a fire.
Page 26 nStallation vent pipe into the vent cap assembly. It is important that the vent pipe extend ” (32mm) into the vent cap sufficient distance so as to result in a minimum pipe overlap of 1¼ inches (32mm). Secure the connection between the vent pipe and the vent cap.
Page 27 nStallation Step 3. To install the Ceiling Firestop in a flat ceiling, cut a square hole in the ceiling 11”x11” (280x280mm) square for 8” x 5” pipe, centered on the hole drilled in Step 2. Frame the hole as shown in Figure 40. Step 4.
Page 28: Door Removal And Installation
nStallation however minimum allowable clearances between the outside of the vent pipe must be maintained. Do not fill any of the required air spaces with insulation. Table 5: Minimum ‘H’ for Figure 44. Roof Pitch Minimum Height (H) Feet Meters Flat to 7/12 Over 7/12 to 8/12 0.46...
Page 29: Gas Hook-Up
Figure 49: Top Door Hook. Figure 48: Door Latch Locations. The Q4 is equipped from factory with a ½” SAE 45° male gas fitting. This fitting will fit commonly used flexible gas supply lines. If your local code requires you to use only rigid pipe for gas supply, remove the flare fitting provided.
Page 30: Electrical Hook-Up
See Figure 54 for help to identify these parts. The orifice size is stamped into the orifice. The correct orifice sizes for the Q4 are LPG - 35 and NG - 62. 8. Install the correct orifice and replace the pilot hood. The pilot hood has an indexing notch which must be align with the pilot base.
Page 31 (Figure 55). 10. Use only the gas orifices that were included in the LP gas conversion kit supplied by the manufacturer. The correct orifice sizes for the Q4 are shown in Table 6. Table 6: Correct Orifice Sizes for the Q4...
Page 32: Firebox Liner Installation
nStallation f. Check your manifold pressure by measuring the pressure at the Manifold test manifold pressure tap on the valve. The manifold pressure with the Inlet test pressure point pressure point appliance operating at its high setting should be between 9.5” WC and 10.5”...
Page 33 nStallation 1. Prior to installing the firebox liners, you will need to ensure the Rear Brick Rear Brick Panel Support is in the correct position. The support Panel Support is located at the back of the firebox (see Figure 61) and can (in lower position) be installed in two (2) positions.
Page 34: Log Burner / Ember Bed Installation
nStallation uRneR mbeR nstaLLation 1. Use the two (2) T-20 screws provided; install the rear burner shield onto the back of the burner. The mounting holes are just above the mixing tubes at the rear of the burner, refer to Figure 67.
Page 35: Log Set Installation
nStallation Slot Grate Tab Figure 72: Slot for Firebox Grate. Figure 73: Tab on Firebox Grate. 4. Install the burner accent pieces as shown in Figure 71. There are a left, a right and a front ceramic trim. On each side of the burner and on the inside of each burner side accent pieces there is a slot, which should be aligned in order to position the log grate correctly (see Figure...
Page 36 nStallation Figure 77: Log 3 in Place. Figure 78: Log 4 in Place. 2. Install Left Rear log with the right side on the grate, using a groove on the bottom of the log to index itself to the grate (see Figure 76). The right side self locates on the first log.
Page 37: Porcelain Panel Kit Installation
nStallation Figure 82: Log 8 in Place. Figure 83: Log 9 in Place. 8. Situate Log 8 between the right grate finger, the right firebox liner and the grate cross bar (see Figure 82). On the back of the log near the top end is a ceramic pin, this pin sits into a groove on the top of Log 9.
Page 38 nStallation Figure 98: Rear & Left Porcelain Panels in Place. Figure 99: Top Porcelain Panel in Place. 4. Install the Left Firebox Liner Panel; it sits on the bottom front edge of the firebox (see Figure 98), a support bracket at the lower rear of the firebox, and is held in by a retainer at the top of the firebox. Adjust the panel retainers as required.
Page 39: Safety Screen Installation
afety creen nStallation The safety screen included with this stove can be removed for cleaning. Removal and re-installation is show in the steps below. Warning: The safety screen becomes hot when the unit is operating; ensure that the unit is turned off, and that it has cooled to room temperature before begining this installation.
Page 40: Wiring Harness
iring arneSS Caution: Label all wires prior to disconnectton when servicing controls, Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.
Page 41: Diagnostic Flash Codes
iagnoStic laSH codeS 1. Fail to ignite: If there is no positive ignition, the board will go into lock out and the LED will blink 3 times in intervals until the system is reset. 2. Low battery condition (<4V): the LED indicator will blink one (1) time in intervals. 3.
Page 42: Troubleshooting
roubleSHooting Problem Possible Cause Solution The pilot flame has gone out Thermostat · Turn it ON does not The On/Off switch is turn to OFF work The thermostat is set too high · Set the thermostat to a lower temperature ·...
Page 43 roubleSHooting Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again. · In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.
Page 44 The Q4 can be installed with the reduced ceiling height as shown in this diagram. If you are limited by ceiling heights, particularly when installing a raised hearth, you can install the unit observing the clearances outline in this diagram. The main difference is the install depth is changed to 26½” (673mm) to compensate for the reduced vertical clearances.
Page 45: Parts Diagram
artS iagram...
Page 46 50-2010 Pilot Assembly 50-2032 Light Bulb Cover (Specify Colour) 50-2218 Burner Accent Kit - Common Brick 50-634 Dual Bulb Door Gasket (10ft) 50-2011 Vent Restrictor Set 20-034 Halogen Cycle (Pin Socket) 50-2012 Fireplace Facing Kit 50-1935 Enviro Heat Distribution Kit...
Page 47: Warranty
Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...
Page 48: Installation Data Sheet
NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc _________________________________________ MAIN BURNER ORIFICE:__________# DMS PHONE:___________________________________ PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 March 2, 2015 www.enviro.com C-14516...
