Section 07: TRANSMISSION
DTC
P2812 Pressure Control Solenoid 6 (PCS6) Control Circuit Open
P2814 Pressure Control Solenoid 6 (PCS6) Control Circuit Low
P2815 Pressure Control Solenoid 6 (PCS6) Control Circuit High
U0001 Hi Speed CAN Bus Reset Counter Overrun (IESCAN)
U0010 CAN BUS Reset Counter Overrun
U0100 Lost Communications with ECM/PCM (J1587)
Lost Communication with Gear Shift Module
U0103
(Shift Selector) 1
U0115 Lost Communication with ECM
Lost Communication with Gear Shift Module
U0291
(Shift Selector) 2
U0304 Incompatible Gear Shift Module 1 (Shift Selector) ID
U0333 Incompatible Gear Shift Module 2 (Shift Selector) ID
Invalid Data Received From Gear Shift Module
U0404
(Shift Selector) 1
Invalid Data Received From Gear Shift Module
U0592
(Shift Selector) 2
10. ZF-ASTRONIC TRANSMISSION SYSTEM
FAULTS AND ERROR MESSAGES

10.1 SYSTEM FAULTS (ERROR MESSAGES)

If the "SM" symbol appears in
the display, a system error has
occurred.
• Stop the vehicle
• Vehicle may no longer be
driven
07107
Error messages and the reactions resulting from
these errors can be deleted with the vehicle at a
standstill and the "Ignition OFF". (Wait until the
display goes out). If the display does not go out
once the ignition has been turned "OFF", set the
battery master switch to the OFF position.
Switch the ignition back on. If the error message
is still in place, the transmission has to be
repaired. The transmission is inoperative. The
vehicle will have to be taken to a service point.
PA1217
Description
22
CHECK
Inhibited Operation
TRANS
Light
Yes DNS, SOL OFF (hydraulic default)
Yes DNS, SOL OFF (hydraulic default)
Yes DNS, SOL OFF (hydraulic default)
No Use default values, inhibit SEM
No Use default values, inhibit SEM
Yes Use default values
Maintain range selected, observe
Yes
gear shift direction circuit
Yes Use default values
Maintain range selected, observe
Yes
gear shift direction circuit
Yes Ignore shift selector inputs
Yes Ignore shift selector inputs
Maintain range selected, observe
Yes
gear shift direction circuit
Maintain range selected, observe
Yes
gear shift direction circuit
The error number(s) must be specified when the
service point is contacted.
Calling up error numbers
Description
