FOREWORD
This Operator's Manual for the PREVOST H3-41
and H3-45 coach has been prepared to
thoroughly acquaint you, the driver, with the
equipment and features of the coach in order for
you to fully appreciate and safely enjoy this
vehicle. Prevost Car Incorporated is committed
to the continuous improvement of coach quality,
reliability, durability and safety. With innovative
features, the H3 series coach was designed with
passenger and driver safety and comfort in mind.
This manual contains information available at the
time of publication.
optional equipment is covered in this manual,
some of the optional equipment described may
not apply to your coach. If in doubt, refer to the
technical documentation package provided with
the coach.
Driver's controls and instruments incorporate
advanced technology for enhanced driving ease
and security. This manual describes the main
features, instruments and controls, and servicing
requirements for both standard and optional
equipment. Read this manual carefully to take
advantage of the coach's advanced features and
to ensure optimum safety and passenger comfort.
Keep this manual in the coach at all times. Make
sure this manual is kept with the coach when
ownership is transferred.
appropriate card at the end of this manual to
promptly notify Prevost Car of any change of
address or transfer of ownership. This will ensure
we provide fast and reliable coach service to all
coach operators.
Warnings,
cautions
throughout this manual to emphasize important
points when necessary:
WARNINGS
call attention to instructions which
must be precisely followed to avoid personal
injury.
CAUTIONS
call attention to instructions which
must be followed to avoid damage to the coach
or to equipment.
NOTES
provide supplemental information and
call attention to instructions which make the job
easier.
The service life of the coach depends on the kind
of attention it receives. Pay close attention to the
warnings, cautions and notes. Read the various
Because standard and
Please use the
and
notes
are
used
notices and instructions posted throughout the
coach and attached to equipment.
Since continuous improvement is a primary focus
at Prevost Car, we reserve the right to make
changes anytime, without notice, and without
incurring any obligation.
Before reproducing or copying this manual, in
whole or in part, written consent must be
obtained
from
1
FOREWORD
Prevost
Car
Incorporated.
