- Page 1 FSP2000 User Manual VA.1 MEMS dual pressure sensors Sold in North America by: Servoflo Corporation 75 Allen Street Lexington, MA 02472 www.servoflo.com/info@servoflo.com 781-862-9572 ©2021 Siargo Ltd.
- Page 2 MEMS Dual Pressure Sensors with thermal and piezo sensing technology FSP2000 Series User Manual Document No. 07‐2021‐FP2 EN Issue date: 2021.07 Revision: VA.1 Siargo Ltd. 3100 De La Cruz Boulevard, Suite 210 Santa Clara, California 95054 USA Tel: +1(408)969.0368 Email: info@siargo.com © Copyright 2021 and Liability Disclaimer Siargo Ltd. and its subsidiaries reserve the right to change the specifications and/or descriptions without prior notice. Siargo and its subsidiaries shall not assume any inaccuracy or errors in this manual. For further information and updates, please visit www.Siargo.com. ...
- Page 3 Only the trained or qualified personnel shall be allowed to perform product services. Use with caution ! Be cautious for electrical safety, and even it operates at a low voltage, any electrical shock might lead to some unexpected damages. The gas to be measured should be clean and free of particles, as even light particles may be accumulated inside the tiny pressure port that may result in inaccuracy in metrology, clogging, or other irrecoverable damage. Do not apply for any unknown or non‐specified gases that may damage the product. www.Siargo.com FSP2000 User Manual 3 ...
-
Page 4: Table Of Contents
Precautions for the best performance of the product .......... 13 8.2.1 Particle contamination .................... 13 8.2.2 Altitude changes ...................... 13 8.2.3 Excessive humidity or condensation ................ 13 Warranty and Liability ................ 1 4 Service contact and information ...............16 Appendix I: Sensor evaluation kit .............. 1 7 Appendix II: Document history .............. 18 www.Siargo.com FSP2000 User Manual 4 ... -
Page 5: Overview
The designed combination of the differential and gauge pressure sensing capability in a small footprint is for the sensing and control in a CPAP (continuous positive airway pressure) equipment that is trending for the miniaturization, where the differential pressure sensing is used for the flow measurement while the gauge pressure provides the necessary feedback for the system. This package allows the CPAP maker to save the space and cost for the required sensing data. While the current packages are best for medical and consumer applications, the manufacturer also offers alternative customized packages. Please contact the manufacturer for additional information. www.Siargo.com FSP2000 User Manual 5 ... -
Page 6: Receipt / Unpack Of The Products
Please check immediately for the integrity of the product and the power and data cable; if any abnormality is identified, please notify the distributor/sales representative or manufacturer as soon as you can. If any defects are confirmed, an exchange shall be arranged immediately via the original sales channel. This user manual shall also be included in the packing box or via an online link for an electronic version which should be sent by your sales agent. In most cases, this manual shall be made available to the customer before the actual order. Please note that the sensor has a pinout that is designed to be directly placed onto a printed circuitry board. Therefore, the power and data cable is an option that will not come with the order automatically. www.Siargo.com FSP2000 User Manual 6 ... -
Page 7: Knowing The Products
3.2 Power and data pinout description Table 3.2: FSP6000 pin assignment. PIN DEFINITION 1 SDA, I C data 2 GND, ground 3 VCC, power supply (3.0~5.5 Vdc) 4 SCL, I C clock FSP2000 electrical interface has 4 pins providing I C digital data with a 3.0~5.5 Vdc power supply. The pins can be directly soldered onto a control printed circuitry board (PCB) or via a data cable, which can be ordered from the manufacturer or made by the user. The sensor runs with a minimal current source of 10 mA. A slightly higher current will ensure the proper operation. www.Siargo.com FSP2000 User Manual 7 ... -
Page 8: Mechanical Dimensions
3.3 Mechanical dimensions Note: for differentia pressure (flow) measurement, Port P1 should be placed upstream, unless a bi‐directional model is ordered. Figure 3.3.1. FSP2000 mechanical dimensions. 4. Installation Do not open or alter any part of the product, which would lead to malfunction and irrecoverable damage. There are no other special requirements for the installation. But it is recommended that the user should make sure no leakage of the connections and all electrical pins are properly engaged. www.Siargo.com FSP2000 User Manual 8 ... -
Page 9: Basic Operation
5. Basic operation 5.1 I C interface connection diagram 5.2 I C interface read/write sequences www.Siargo.com FSP2000 User Manual 9 ... -
Page 10: I 2 C Interface Command Description
The 8‐bit CRC checksum transmitted after each two data bytes (int 16) is generated by a CRC algorithm. Its properties are listed in the table below. To calculate the checksum, only these two previously transmitted data bytes are used. Property Value Name CRC‐8 Protected data C read and write Width 8 bits Polynomial 0x07 (x8 + x2 + x + 1) Initialization 0x00 Reflect input False Reflect output False Final XOR 0x00 Example CRC(0x4E20) = 0x6D www.Siargo.com FSP2000 User Manual 10 ... -
Page 11: Product Selection And Order Information
Note: 1. Example: FSP2000‐500D‐500‐5G100‐E: the differential pressure range will be ±500Pa, and gauge pressure range ‐5 to 100 cmH O. 2. Gauge pressure full scale at the current offer is 100 cmH O, reserved for future upgrade. 6.2 Order contact and customer support The sales offices and the sales distributors/representatives are listed at the end of this document. For small quantities, the order can be placed either through the Siargo website: www.siargo.com or the sales office. For large quantities, please contact the sales office, distributors, or sales representatives. Siargo is making every effort to ensure the quality of the products. In case of questions and/or product supports, please contact the customer service listed at the end of the document. www.Siargo.com FSP2000 User Manual 11 ... -
Page 12: Technical Specifications
Warm‐up time (max) 10 sec Humidity 0~100 (no condensation) %RH Power supply, voltage 3.0~5.5 Vdc Power supply, minimal current 10 mA Pneumatic flow resistance <95 sccm@500Pa Output Linear, I C Storage temperature ‐20~70 °C Vibration 20g; MIL‐STD‐883E, Method 2002.4. Compliance RoHS; REACH Note: *FS = full scale at one direction. Customized differential pressure range is available upon request. 1 cmH O (4 °C) = 98.06 Pa = 0.014 PSI www.Siargo.com FSP2000 User Manual 12 ... -
Page 13: Technical Notes For The Product Performance
8.2 Precautions for the best performance of the product 8.2.1 Particle contamination It is critical to have the measured gas free of particle contamination. Since the data ports for both the gauge pressure and differential pressure is small, any particle's presence may create a deformed channel leading to large measurement errors. The particle deposition may also clog the channel, creating unstable data output and other instability, resulting in unpredictable measurement circumstances. 8.2.2 Altitude changes Unlike some other products on market, the design of the sensor has a built‐in pressure balancer that preventing membrane deformation due to altitude changes. Therefore, the sensor is intrinsically insensitive to the altitude change‐induced errors. 8.2.3 Excessive humidity or condensation The humidity change will not alter the performance of the sensor. However, if excessive humidity is present resulting in condensation, the measurement port or channel could be blocked or altered. This would result in a very unreliable data output. Please filter or other tools to prevent this situation to occur when using this product. www.Siargo.com FSP2000 User Manual 13 ... -
Page 14: Warranty And Liability
Siargo makes no warranty, representation, or guarantee and shall not assume any liability regarding the suitability of the products described in this manual for any purposes that are not specified in this manual. The users shall be held for full responsibility for validating the performance and suitability of the products for their particular design and applications. For any of the misusage of the products out of the scope described herein, the user shall indemnify and hold Siargo and its officers, employees, subsidiaries, affiliates, and sales channels harmless against all claims, costs, damages, and expense or reasonable attorney fee from direct or indirect sources. Siargo makes no other warranty, express or implied, and assumes no liability for any special or incidental damage or charges, including but not limited to any damages or charges due to installation, ... - Page 15 (2) Products that have been subject to chemical attacks, including exposure to corrosive substances or contaminants. In the case of battery usage, long term discharge or leakage induced damages; (3) Products that have been opened or dismantled for whatever reasons; (4) Products that have been subject to working conditions beyond the technical specification as described by this manual or related datasheet published by the manufacturer; (5) Any damages incurred by the incorrect usage of the products; (6) Siargo does not provide any warranty on finished goods manufactured by others. Only the original manufacturer's warranty applies; (7) Products that are re‐sold by unauthorized dealers or any third parties. ...
-
Page 16: Service Contact And Information
10. Service contact and information Siargo Ltd. is making every effort to ensure the quality of the products. In case of questions and or product supports, please contact customer service at the address listed below. We will respond to your request in a timely fashion and work with you toward your complete satisfaction. Customer service and all orders should be addressed to Siargo Ltd. 3100 De La Cruz Boulevard, Suite 210, Santa Clara, California 95054, USA Phone: +01(408)969‐0368 Email: info@Siargo.com For orders, please provide an accurate and full postal address. Siargo will not ship to P.O. Boxes or via a third party. Please contact info@siargo.com to obtain a Return Materials Authorization (RMA) before shipping the product back to the factory for returns or factory services such as calibration. Please specify as clear and detailed as possible in your email message the product's status that you intend to ship back to the factory. Be sure to write the RMA on the returned package or include a letter with the RMA information. For further information and updates, please visit www.Siargo.com. www.Siargo.com FSP2000 User Manual 16 ... -
Page 17: Appendix I: Sensor Evaluation Kit
Appendix I: Sensor evaluation kit Siargo offers a sensor evaluation kit, including a digital data converter, USB data cable, and a User Application software, that allows the user to evaluate the product performance on a Microsoft Windows‐based computer. The user can read and visualize the flow rate of the product, obtain the totalized values, and save the data for further analysis. It can read from up to 128 sensors with the C interface in serial. For further information and purchase of the evaluation kit, please contact the manufacturer or the sales representative. Each converter has a fixed cable that can be directly connected to the product. The USB ... -
Page 18: Appendix Ii: Document History
Appendix II: Document history 07.2021 VA.1 – Reformated and I C communication update. 02.2021 VA.0 ‐ First release www.Siargo.com FSP2000 User Manual 18 ...
