Pro-Form 765 TR User Manual page 7

5. Attach the Seat (9) to the Seat Bracket (11) with four
M6 x 16mm Button Screws (8) and four M6 Washers
(66).
6. Attach the Seat Back (106) and the Backrest (90) to
the Seat Bracket (11) with three M6 x 22mm Button
Screws (93).
7. Push down the handle (not shown) on the right side of
the Seat Carriage (10), slide the Seat Carriage into the
Frame Rail (81), and then pull the handle back up.
Attach a Bumper (82) to the Frame Rail (81) with an
M4 x 20mm Screw (101). Next, press the Frame Rail
Endcap (83) into the end of the Frame Rail.
5
9
11
66
6
7
81
7
66
8
8
90
106
11
101
82
10
83
93
