Table 6-11 shows the equivalent AT commands for setting the
secondary rate option. Network throughput is shown in Table 6-12.
Front Panel
1=OFF
2=75
3=150
4=300
5=600
6=1.2K
7=2.4K
61202011L1-1

Table 6-11. Auxiliary Port AT Commands

AT Command Description
_Y0
_Y1
_Y2
_Y3
_Y4
_Y5
_Y6

Table 6-12. DSU III AR Network Throughput

Loop Rate
2.4k
4.8k
9.6k
19.2k
38.4k
56k No Scrambler
56k Scrambler
DSU III AR User Manual
Chapter 6. Configuring DTE Options
No secondary channel selected
Secondary channel rate: 75 bps
Secondary channel rate 150 bps
Secondary channel rate: 300 bps
Secondary channel rate 600 bps
Secondary channel rate 1200 bps
Secondary channel rate: 2400 bps
Secondary Channel Throughput
78
156
312
627
1.25k
1.83k
2.4k
6-17
