5.3.3 Counter of Received Messages (30004)

The 32-bit register with the number of valid Modbus messages received by the device
from last powering up. The value is reset after a power cycle or after changing
transmission parameters (speed, stop bits, parity, etc.).

5.3.4 Counter of Error Messages (30006)

The 32-bit register with the number of error Modbus messages received by the device
from last powering up. The value is reset after a power cycle or after changing
transmission parameters (speed, stop bits, parity, etc.).

5.3.5 Counter of Sent Messages (30008)

The 32-bit register with the number of Modbus messages sent by the device from last
powering up. The value is reset after a power cycle or after changing transmission
parameters (speed, stop bits, parity, etc.).

5.3.6 Hardware_Version (30130)

This 16-bits register contains the module hardware version multiplied by 10.

5.3.7 MAC_Address (30131)

This 32-bits register contains the module MAC address information.

5.3.8 Device Actions (40001)

Setting the 40001 register according to the table below will enable 1 of 4 available
actions: reset module, reload settings, set to default, and enter bootloader.
Value
511
767
1023
1279

5.3.9 Baud Rate (40136)

If sections 1, 2, and 3 of the S3 DIP switch are in off position, the baud rate is determined
in accordance with this register. Baud rate is determined by the following formula:
Baud rate
1 115200
Table 7. Setting baud rate and protocol
Reset
Reload settings
Set to default
Enter Bootloader
Table 8. Device actions
