Hatco GR2BW-24 Installation & Operating Manual
Glo-ray designer heated shelf & buffet warmer gr2s & gr2bw series
Hide thumbs
Also See for GR2BW-24:
- Replacement parts list manual (9 pages) ,
- Operating manual (16 pages)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Operating Manual
Designer Heated Shelf & Buffet Warmer
This manual contains important safety information
concerning the maintenance, use and operation
of this product. Failure to follow the instructions
contained in this manual may result in serious injury.
If you are unable to understand the contents
of this manual, please bring it to the attention
of your supervisor. Do not operate this equipment
unless you have read and understood the contents
of this manual.
GLO-RAY
GR2S & GR2BW Series
Installation &
Operating Manual
I&W #07.05.079.00
®
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso
y operación de este producto. Cualquier falla
en el seguimiento de las instrucciones contenidas
en este manual puede resultar en un serio daño.
Si usted no puede entender el contenido de este
manual por favor pregunte a su supervisor. No opere
este equipo al menos que haya leído y comprendido
el contenido de este manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hatco GR2BW-24
Summary of Contents for Hatco GR2BW-24
- Page 1 GLO-RAY Designer Heated Shelf & Buffet Warmer GR2S & GR2BW Series Operating Manual This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you are unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
Glo-Ray Designer Foodwarmers in the spaces below. Please have this information available when calling Hatco for service assistance. Model No. ____________________________________ Serial No. ____________________________________... -
Page 3: Important Safety Instructions
414-671-6350; fax 800-690-2966 or International fax 414-671-3976. This product has no “user” serviceable parts. To avoid damage to the unit or injury to personnel, use only Authorized Hatco Service Agents and Genuine Hatco Parts when service is required. IMPORTANT SAFETY INSTRUCTIONS... -
Page 4: Model Descriptions
MODEL DESCRIPTIONS ALL MODELS The Glo-Ray Designer Heated Shelves and Buffet Warmers are ideal for holding hot food on a buffet line or at temporary serving areas. All Designer models are constructed of sturdy aluminum extrusions with decorative plastic bullnose corners. GR2S MODELS The Glo-Ray Designer GR2S Heated Shelves are available in sizes from 30"... -
Page 5: Specifications
ELECTRICAL RATING CHART – GR2S MODELS Model Voltage GR2S-24 220-230 (CE) 230-240 (CE) GR2S-30 220-230 (CE) 230-240 (CE) GR2S-36 220-230 (CE) 230-240 (CE) GR2S-42 220-230 (CE) 230-240 (CE) GR2S-48 220-230 (CE) 230-240 (CE) GR2S-54 220-230 (CE) 230-240 (CE) GR2S-60 220-230 (CE) 230-240 (CE) GR2S-66 220-230 (CE) -
Page 6: Electrical Rating Chart - Gr2Bw Models
SPECIFICATIONS ELECTRICAL RATING CHART – GR2BW MODELS Model Voltage GR2BW-24 120/208 120/240 220-230 (CE) 230-240 (CE) GR2BW-30 120/208 120/240 220-230 (CE) 230-240 (CE) GR2BW-36 120/208 120/240 220-230 (CE) 230-240 (CE) GR2BW-42 120/208 120/240 220-230 (CE) 230-240 (CE) GR2BW-48 120/208 120/240... -
Page 7: Plug Configurations
ELECTRICAL RATING CHART – GR2BW MODELS Model Voltage GR2BW-66 120/208 120/240 220-230 (CE) 230-240 (CE) GR2BW-72 120/208 120/240 220-230 (CE) 230-240 (CE) The electrical information in the shaded areas pertains to Export models only. PLUG CONFIGURATIONS Units are supplied from the factory with an electrical cord and plug installed. -
Page 8: Installation
If this unit cannot be sealed at the point of use, 4" (10 cm) legs are included to allow for proper cleaning access below unit. See Hatco Accessories for installation instructions. 3. Turn unit upright and position warmer in desired location. -
Page 9: Operation
ON/OFF Toggle Switch HIGH Indicator Light Infinite Control Figure 7. Operating Controls - GR2BW Form No. GR2S/2BWM-0203 OPERATION 200 F HATCO CORPORATION, Milwaukee, WI 93 C Thermostat Control 200 F 80 F HATCO CORPORATION, Milwaukee, WI 28 C 93 C... -
Page 10: Maintenance
Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn. -
Page 11: Accessories
ACCESSORIES 4" (10 CM) ADJUSTABLE LEGS Carefully lay unit on its side. Install legs and hardware to bottom of unit as shown in Figure 8. Tighten legs until snug. Do not overtighten. Return unit to the upright position. CAUTION Do not lay unit on the side with the control panel or damage to unit could occur. -
Page 12: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 13 NOTES Form No. GR2S/2BWM-0203...
- Page 14 NOTES Form No. GR2S/2BWM-0203...
- Page 15 NOTES Form No. GR2S/2BWM-0203...
-
Page 16: Authorized Parts Distributors
NEW YORK GCS Service Acme American Repairs, Inc. Indianapolis 317-545-9655 Brooklyn Parts & Service Fax (800) 690-2966 Printed in U.S.A. February 2003 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK (continued) Alpro Service Co. 319-323-1823 Brooklyn Appliance Installation Buffalo Northern Parts Dist.
