2007 Utopia / Aquatic Melodies
Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure the
safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for delivery
and set-up of your new spa. Specifically covered are site selection, delivery access, ground preparation, and electrical
requirements.
Remember to carefully read the Owner's Manual that accompanies your spa and to complete the warranty card within ten
days of delivery. These items, along with other valuable information, included in the Owner's Package which can be
located in the equipment compartment of your spa. You will also find your serial number, in the equipment compartment.
Watkins Manufacturing Corporation reserves the right to change features, specifications and design without notification
and without incurring any obligation.
DATE PURCHASED: ________________________________________________________________________
DATE INSTALLED: __________________________________________________________________________
DEALER: ____________________________________________________________________________________
ADDRESS: __________________________________________________________________________________
TELEPHONE: ______________________________________________________________________________
In most cities and counties, permits will be required for the installation of electrical circuits or the construction of exterior
surfaces (decks and spa enclosures). In addition, some communities have adopted residential barrier codes which may
require fencing and/or self-closing gates on the property to prevent unsupervised access to a pool (or spa) by children
under 5 years of age. Your Caldera
Safety Covers and as a result, is usually exempt from most barrier requirements. As a general practice, your local Building
Department will inform you of any applicable barrier requirements at the time a permit is obtained for the installation of
an electrical circuit. Your Caldera dealer can provide information on which permits may be required.
Pre-Delivery Instructions
®
spa is equipped with a locking cover that meets the ASTM F1346-91 Standard for
®
/ Paradise
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CalderaSpas Utopia
Summary of Contents for CalderaSpas Utopia
- Page 1 ® 2007 Utopia / Aquatic Melodies / Paradise Pre-Delivery Instructions Please take the time to read this booklet carefully, as it will provide you with the information you will need to ensure the safe, secure, and timely installation of your new spa. The following sections are guidelines on how to prepare for delivery and set-up of your new spa.
-
Page 2: Site Selection
• Leave access to the entire front of the spa (the removable panel provides access to the spa’s equipment) for periodic spa care and maintenance. • Note that on the Utopia and Aquatic Melodies ® Series spas, the SpaGlo ®... -
Page 3: Ground And Spa Leveling Preparation
ROUND AND EVELING FOUNDATIONS FOR SPAS ONLY (No gazebo) REPARATION Your Caldera spa has been engineered to perform on several types of common yard surfaces. While a concrete slab is best for long-term PEA GRAVEL use*, other foundations are acceptable so long as a level base is OR CRUSHED ROCK prepared prior to delivery. - Page 4 Pre-Delivery Instructions NOTE: It may be necessary to allow for additional over-head clearance if the spa will be rolled up or down an incline or moved up or down a short flight of stairs. Use the information in the picture below to determine the requirements for access to your desired location. It may be necessary to remove a gate, part of a fence, or other movable obstructions in order to roll the spa to its installation site.
- Page 5 Geneva and Niagara ® ™ Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation requires that the Geneva and Niagara be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WARNING: The Geneva and Niagara must not be shimmed in any manner.
- Page 6 Pre-Delivery Instructions Tahitian , Aspire and Hawaiian ® ® ® (Aspire is an Aquatic Melodies model only) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation recommends that the Tahitian, Aspire, and Hawaiian be installed on a minimum 4”...
- Page 7 Elation ® ® (Aquatic Melodies model only) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation requires that the Elation be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WARNING: The Elation must not be shimmed in any manner.
- Page 8 Pre-Delivery Instructions Moorea (Paradise model only) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation requires that the Moorea be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WARNING: The Moorea must not be shimmed in any manner.
- Page 9 Martinique ® (Paradise model only) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation recommends that the Martinique be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WARNING: The Martinique must not be shimmed in any manner.
- Page 10 Pre-Delivery Instructions Kauai ® (Paradise model only) Dimensions NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions. NOTE: Watkins Manufacturing Corporation recommends that the Kauai be installed on a minimum 4” thick reinforced concrete pad or structurally sound deck able to support the “dead weight” found in the spa specification chart. WARNING: The Kauai must not be shimmed in any manner.
-
Page 11: Electrical Requirements
ELECTRICAL REQUIREMENTS To ensure you will have an opportunity to use your spa soon after delivery, it is very important that the required electrical service has been installed. Unless otherwise stipulated by your dealer, THIS IS YOUR RESPONSIBILITY. IMPORTANT: All electrical circuits must be installed by a qualified, licensed electrician. 230 Volt Permanently Connected WARNING! THE EXACT PHYSICAL LOCATION OF THE TERMINALS ON THE GFCI BREAKER... -
Page 12: Power Connection
IMPORTANT: The following must be followed to properly install the equipment compartment door. • Place top of door or panel directly below bartop against the frame of the spa. For Utopia and Aquatic Melodies spas, first lift the fiber optic cable out of the way. - Page 13 ® DDITIONAL PRODUCTS AVAILABLE FROM YOU ALDERA EALER ® • Monarch CD Ozone Generator • Monarch Silver Ion Purifier Cartridge • Monarch MPS non-chlorine oxidizer • Monarch MPS test strips • Retractable cover system with clearance requirements ® • ProLift - 14”...
- Page 14 Pre-Delivery Instructions OTES Page 14...
- Page 15 OTES Page 15...
- Page 16 Pre-Delivery Instructions ® TOPIA QUATIC ELODIES ARADISE PECIFICATIONS 38" 4,300 5,915 230 volt, 30 or 50 Geneva 7'5"x 7'5" (97cm) sq ft gallons lbs. lbs. lbs/sq ft amp Single phase (226cm x (10 sq m) (1,798 l) (417 kg) (2,683 (560 GFCI 226cm)
