P9415-R-EVK Evaluation Kit
The P9415-R-EVK Wireless Power Evaluation Board serves to demonstrate the features and performance of the
9415-R 15W Wireless Power Receiver with WattShare™ mode. The P9415-R-EVK is designed for evaluation
purpose only. It must not be used for module or mass production purposes.
Contents
1.
Features ......................................................................................................................................................... 3
2.
Evaluation Kit Contents ............................................................................................................................... 3
3.
Overview ........................................................................................................................................................ 3
4.
Setup.............................................................................................................................................................. 4
4.1
Required or Recommended User Equipment ....................................................................................... 4
4.2
Required Software on Computer .......................................................................................................... 4
4.2.1.
Software Installation ............................................................................................................... 4
4.3
Usage Guide ......................................................................................................................................... 5
4.4
Kit Hardware Connections for Rx Mode................................................................................................ 5
4.4.1.
Start Guide for Rx Operation .................................................................................................. 5
4.5
Kit Hardware Connections for Wattshare (Tx) mode ............................................................................ 6
4.5.1.
Start Guide for Wattshare Tx mode Operation ....................................................................... 6
4.5.2.
5.
P9415-R Evaluation Board Test Point and Connector............................................................................... 8
5.1
P9415-R Evaluation Board Test Point Placement ................................................................................ 8
5.1.1.
J1 Dongle Connector Pin Descriptions ................................................................................... 8
5.1.2.
J5 Test Connector Pin Descriptions ....................................................................................... 9
6.
Hardware Connections-Renesas USB-I2C Dongle to Window GUI ......................................................... 9
6.1
Using the Windows GUI...................................................................................................................... 12
7.
TRx Wireless Power Coil ............................................................................................................................ 15
8.
Resonance Capacitors ............................................................................................................................... 15
9.
PCLAMP Connection .................................................................................................................................. 15
10. Transient Voltage Suppressors ................................................................................................................. 15
11. GPIO and GPOD Pins ................................................................................................................................. 16
11.1 OD0/SCL Pin ...................................................................................................................................... 16
11.2 OD1/SDA Pin ...................................................................................................................................... 16
11.3 OD2/INT Pin ....................................................................................................................................... 16
11.4 OD3/ALIGN_X Pin and OD4/ALIGN_Y Pin ........................................................................................ 16
11.5 GP0/PWRGD Pin ............................................................................................................................... 17
11.6 GP1/Q Main Pin and GP3/Q Offset Pin .............................................................................................. 17
11.7 GP2/ External Thermistor Pin ............................................................................................................. 18
11.8 GP4/I2C Address Select Pin ............................................................................................................... 18
11.9 GP5/INHIBIT Pin ................................................................................................................................ 18
May 27, 2021
Tx Mode Input Voltage ....................................................................................... 8
User Guide
Page 1
© 2021 Renesas Electronics

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P9415-R-EVK and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas P9415-R-EVK

Summary of Contents for Renesas P9415-R-EVK

  • Page 1: Table Of Contents

    User Guide P9415-R-EVK Evaluation Kit The P9415-R-EVK Wireless Power Evaluation Board serves to demonstrate the features and performance of the 9415-R 15W Wireless Power Receiver with WattShare™ mode. The P9415-R-EVK is designed for evaluation purpose only. It must not be used for module or mass production purposes.
  • Page 2 12.2 FOD Parameters in Transmitter Mode ....................20 13. I2C Function ..............................20 14. P9415-R TRX Demo PCB v1.1 Schematic ....................21 15. Bill of Materials (P9415-R-EVK Demo Board Rev1.1) ................22 16. P9415-R-EVK PCB Layout .......................... 23 17. Ordering Information ..........................25 18.

  • Page 3: Features

    P9415-R Evaluation Board assembled with Coil 3. Overview The P9415-R-EVK Wireless Power Evaluation Board serves to demonstrate the features and performance of the 9415-R 15W Wireless Power Receiver with WattShare™ mode. Renesas P9243-GB-EVK Evaluation Board or any other Qi certified Extended Power Profile (EPP) transmitter can be used as the power transmitter for P9415- R-EVK Evaluation Board testing.

  • Page 4: Setup

    Required Software on Computer Visit the P9415-R-EVK webpage and download latest version of the P9415-R Wireless Power Pro GUI, and USB drivers from the Renesas website. The Window GUI software provides an intuitive graphical user interface for reading and writing to P9415-R registers and program custom user configurations to internal MTP memory.

  • Page 5: Usage Guide

    1. Set up the P9243-GB Evaluation Board (or other transmitter board) according to the board’s user manual and apply power. 2. Place the P9415-R-EVK Board on the transmitter coil surface with the coil back facing upwards. P9415-R- EVK PCB boards act as a spacer between Tx surface and Rx coil.

  • Page 6: Kit Hardware Connections For Wattshare (Tx) Mode

    1. Supply power on P9415-R-EVK VOUT with DC power supply (7.0V). 2. Connect USB dongle on P9415-R-EVK J1 connector. USB dongle black line (GND) should be on J1 Pin3. 3. Send Tx mode command with P9415-R Wireless Power Pro GUI (write 0x01 on 0x0076 register).
  • Page 7 P9415-R-EVK Evaluation Kit Figure 4. TRx Mode Digital Ping Waveform 4. Place WPC compliant Receiver on P9415-R-EVK TRx coil. P9415-R will detect Rx device and start power transfer right after WPC ID and Configuration packet. Probe Rx VRECT and Rx VOUT and check if charging is functional.

  • Page 8: Wattshare Tm Tx Mode Input Voltage

    P9415-R-EVK Evaluation Kit 4.5.2. Wattshare Tx Mode Input Voltage The P9415-R can transfer up to 5W of power in TRx mode. It follows the WPC 1.2.4 BPP protocol to transfer the power to other Qi-certified receivers such as Mobile devices, wearables and hearables. The maximum power delivered in TRx mode is dependent on the input voltage on VOUT pin, coil characteristics such as AC resistance, and the friendly metal around the coil.

  • Page 9: J5 Test Connector Pin Descriptions

    Power Dongle power supply from USB dongle (optional). 6. Hardware Connections–Renesas USB-I2C Dongle to Window The P9415-R firmware provides great flexibility to customize operating parameters for custom applications. Default values of the P9415-R operating parameters such as output voltage, FOD parameters, and current limit are set in the firmware programmed into the internal multi-time programmable (MTP) memory.
  • Page 10 1. Ensure the USB drivers and P9415-R Wireless Power Pro GUI tool are installed successfully in PC. 2. Place P9415-R-EVK on WPC TX or apply 5V DC from GND connection to the VOUT test point without Tx. 3. Connect WPD-USB-DONGLE to J1 of P9415-R-EVK.
  • Page 11 P9415-R-EVK Evaluation Kit Figure 10. Initial Screen of P9415-R GUI Figure 11. Successful Connection GUI Screen R16UH0015EU0100 Rev.1.0 Page 11 May 27, 2021...

  • Page 12: Using The Windows Gui

    GUI. First select the target FW to update and click Program MTP, then FW will be updated Note: For programming the new firmware to the P9415-R device, remove the P9415-R-EVK from the transmitter pad. Power the device from an external 5V–7.5V power source on VOUT test point of P9415-R- EVK.
  • Page 13 P9415-R-EVK Evaluation Kit Figure 13. Configuration Parameter Table 3. RX Mode FOD Data. This function displays FOD gain and offset data on GUI. Click Get All button to view FOD parameters in running Rx mode. Rx BPP and EPP mode may have different FOD parameters. You can change FOD parameter values during running FOD test.
  • Page 14 P9415-R-EVK Evaluation Kit 4. Test Command. Use the command script to read and write data to P9415-R register. There are several command script examples. For example, if you want to read 2byte data from register address 0x0068, please type in ‘regRead:0068 2’ in blank command block and click Send cmd button, then GUI will return read value in window.

  • Page 15: Trx Wireless Power Coil

    P9415-R-EVK Evaluation Kit 7. TRx Wireless Power Coil The TRx coil is dependent on customer requirements and most are custom designs. Renesas recommends the following TRx coil as it was installed in P9415-R demo board. ■ Ls = 8 to 10µH ■...

  • Page 16: Gpio And Gpod Pins

    P9415-R-EVK Evaluation Kit Table 4. Transient Voltage Suppressors (TVS) Recommendations = 12V MLDO D24V0L1B2LP VRWM = 24V maximum VBR = 26V minimum at 1mA VCL = 42V maximum at 1A pp 11. GPIO and GPOD Pins The P9415-R has general-purpose input-output (GPIO) pins. The OD0-OD4 and GP0-GP6 pins are all multi- functional.OD0-OD4 pins have an open-drained structure and GP0-GP6 pins have a push-pull structure.

  • Page 17: Gp0/Pwrgd Pin

    P9415-R-EVK Evaluation Kit 11.5 GP0/PWRGD Pin The GP0 pin is a digital output referenced to LDO1P8. The AP can use the power good signal to turn on the charging connection indicator or other system functions. Power good (PWRGD) pin is pulled low by default. In BPP mode, the power good pin is pulled high when MLDO is enabled.

  • Page 18: Gp2/ External Thermistor Pin

    P9415-R-EVK Evaluation Kit 11.7 GP2/ External Thermistor Pin The GP2 pin is connected to the internal ADC and can measure the voltage of the thermistor connected to measure the external temperature on either the receiver coil or the PCB. The P9415-R sends interrupts to the AP if the voltage reaches below the threshold level (0.6V default, configurable) to allow the AP an opportunity to...

  • Page 19: Fod Parameters In Receiver Mode

    P9415-R-EVK Evaluation Kit In the Extended Power Profile, there are two methods of foreign object detection (FOD). One is by measuring the system quality factor before entering the power transfer phase, and the other is to measure the power loss difference between the received power and the transmitted power during the power transfer phase.

  • Page 20: Fod Parameters In Transmitter Mode

    P9415-R-EVK Evaluation Kit Section 0 current is the point where the internal rectifier changes bridge configuration from half-bridge to full- bridge. In the default configuration, If VOUT is set to less than 7V, section0 current is 288mA. If Voutset is higher than 7V, section0 current is 384mA, section2 is not used and section3 starts from 384mA.

  • Page 21: P9415-R Trx Demo Pcb V1.1 Schematic

    P9415-R-EVK Evaluation Kit 14. P9415-R TRX Demo PCB v1.1 Schematic R16UH0015EU0100 Rev.1.0 Page 21 May 27, 2021...

  • Page 22: Bill Of Materials (P9415-R-Evk Demo Board Rev1.1)

    P9415-R-EVK Evaluation Kit 15. Bill of Materials (P9415-R-EVK Demo Board Rev1.1) R16UH0015EU0100 Rev.1.0 Page 22 May 27, 2021...

  • Page 23: P9415-R-Evk Pcb Layout

    P9415-R-EVK Evaluation Kit 16. P9415-R-EVK PCB Layout Figure 19. Top Layer Figure 20. Layer2 (GND Layer) Figure 21. Layer4 (POWER/Signal/GND Layer) R16UH0015EU0100 Rev.1.0 Page 23 May 27, 2021...
  • Page 24 P9415-R-EVK Evaluation Kit Figure 22. Bottom Layer Figure 23. Top Silkscreen Layer R16UH0015EU0100 Rev.1.0 Page 24 May 27, 2021...

  • Page 25: Ordering Information

    P9415-R-EVK Evaluation Kit 17. Ordering Information Part Number Description P9415-R-EVK P9415-R Evaluation board WPD-USB-DONGLE USB to I2C don required to connect with P9415-R Windows GUI. It is not included in the P9415-R- EVK evaluation kit and needs to be ordered separately.

  • Page 26: Appendix A-List Of Registers

    P9415-R-EVK Evaluation Kit Appendix A–List of Registers Table 8. Chip ID (0x00, 0x01) Address Default Register Field Name Function and Description and Bit Value 0x00 [7:0] Chip_ID_L 0x15 Chip ID low byte 0x01 [7:0] Chip_ID_H 0x94 Chip ID high byte Table 9.
  • Page 27 P9415-R-EVK Evaluation Kit Table 16. Date Register (0x0C) Address Default Register Field Name Function and Description and Bit Value 12-byte string initialized with FW compile data code. The format of the string is: “Mmm DD YYYY”, where Mmm is a three letter Month code,...
  • Page 28 P9415-R-EVK Evaluation Kit Address Default Register Field Name Function and Description and Bit Value AP writes 1 to clear the corresponding Interrupt Registers’ bit. This bit is 0x29 [1] TXAUTHSUCCESS self-cleared to 0 (by M0) afterward. AP writes 1 to clear the corresponding Interrupt Registers’ bit. This bit is...
  • Page 29 P9415-R-EVK Evaluation Kit Table 21. System Status Register (0x2C, 0x2D, 0x2E, 0x2F) in Rx Mode Address Default Register Field Name Function and Description and Bit Value 0x2F [7:0] Reserved Reserved 0x2E [7] OVERCURRWARN 1 = Indicates the Iout is closed to Ilim value 1 = Indicates error condition happens in the communication channel.
  • Page 30 P9415-R-EVK Evaluation Kit Table 22. System Status Register (0x2C, 0x2D, 0x2E, 0x2F) in Tx Mode Address Default Register Field Name Function and Description and Bit Value 0x2F [7:0] Reserved Reserved 0x2E [7:0] Reserved Reserved 0x2D [7:1] Reserved Reserved 1 = Indicates the CSP packet is received.
  • Page 31 P9415-R-EVK Evaluation Kit Address Default Register Field Name Function and Description and Bit Value 1 = Indicates the backchannel packet is received by Tx 0x31 [3] BCSUCCESS 0 = No such condition 1 = Indicates the backchannel packet is sending failed.
  • Page 32 P9415-R-EVK Evaluation Kit Table 24. System Interrupt Register (0x30, 0x31, 0x32, 0x33) in Tx Mode Address Default Register Field Name Function and Description and Bit Value 0x33 [7:0] Reserved Reserved 0x32 [7:0] Reserved Reserved 0x31 [7:1] Reserved Reserved 1 = Indicates the CSP packet is received.
  • Page 33 P9415-R-EVK Evaluation Kit Address Default Register Field Name Function and Description and Bit Value 1 = Corresponding interrupt is enabled. 0x35 [5] IDAUTHSUCCESS 0 = Corresponding interrupt is disabled. 1 = Corresponding interrupt is enabled. 0x35 [4] IDAUTHFAILED 0 = Corresponding interrupt is disabled.
  • Page 34 P9415-R-EVK Evaluation Kit Table 26.System Interrupt Enable Register (0x34, 0x35, 0x36, 0x37) in Tx Mode Address Default Register Field Name Function and Description and Bit Value 0x36 [7:0] Reserved Reserved 0x36 [7:0] Reserved Reserved 0x35 [7:1] Reserved Reserved 1 = Corresponding interrupt is enabled.
  • Page 35 P9415-R-EVK Evaluation Kit Table 29. Charge Status Register (0x3A) Address Default Register Field Name Function and Description and Bit Value In RX mode the AP writes this register with the value intended to be sent as payload to the Charge Status Packet. The FW does not verify or modify the value in any way.
  • Page 36 P9415-R-EVK Evaluation Kit Table 33. Vrect ADC (0x40) Address Default Register Field Name Function and Description and Bit Value 12 LSB of current Vrect ADC value. Vrect = ADC_Vrect 0x40 [15:0] Vrect ADC – Value/4095*10*2.1 (V). Table 34. External Temperature Register ADC (0x42)
  • Page 37 P9415-R-EVK Evaluation Kit Table 40. System Mode Register (0x4D) Address Default Register Field Name Function and Description and Bit Value – Indication P9415 is powered by Vrect or Vout, but Tx function is not 0x4d [7] BACKPOWERED enabled. 0x4d [6:4] Reserved –...
  • Page 38 The seventh pair calibrates the internal DC Load. The set values of the FOD registers are found with the help of a Renesas developed calibration procedure using the nok9 tester. The firmware initializes the FOD registers for BPP mode. The correct set is loaded at the completion of the ID and Configuration Phase.
  • Page 39 P9415-R-EVK Evaluation Kit Table 45. End Power Transfer Reason Register (0x74) Address Default Register Field Name Function and Description and Bit Value 1 = Indicates over current protect during digital ping 0x75 [7] EPT_POCP 0 = No such error 1 = Over current error...

  • Page 40: Bi-Di Communication Registers

    P9415-R-EVK Evaluation Kit Table 47. Over Voltage Threshold Register in Tx Mode (0x98) Address Default Register Field Name Function and Description and Bit Value 0x98 [15:0] OVpThd 0x2AF8 Over-voltage threshold in Tx mode, value in mV. Table 48. Over Current Threshold Register in Tx Mode (0x9A)
  • Page 41 P9415-R-EVK Evaluation Kit Table 54. Write Data Register for WPC 1.3 (0x1A4~0x39F) Address Default Register Field Name Function and Description and Bit Value 0x1A4[508] WrData Raw data which is intended to send to Tx Table 55. Read Data Register for WPC 1.3 (0x3A4~0x59F)

  • Page 42: Appendix B-Wireless Power Coil Key Specifications From Luxshare (Ictr-Qs5858031L-Mw034)

    P9415-R-EVK Evaluation Kit Appendix B–Wireless Power Coil Key Specifications from Luxshare (ICTR-QS5858031L-MW034) R16UH0015EU0100 Rev.1.0 Page 42 May 27, 2021...
  • Page 43 P9415-R-EVK Evaluation Kit R16UH0015EU0100 Rev.1.0 Page 43 May 27, 2021...
