- Page 1 Waist Level Finder N English Instructions...
- Page 2 Names of Parts Sports Finder Mask 2) Sports Wire Frame 4) Sports Finder Eyepiece Attaching Latches 6) Alignment Dot Finder Lock Release Button 7) Finder Hood Opening Tongue 8) Magnifier Release 9) Finder Lock Button Introduction The Waist Level Finder N an easy-to-use enclosed type Finder Hood which can be opened and...
- Page 3 Raising and Lowing the Magnifier To raise the magnifier, slide the Magnifier Release to the left and the Magnifier will pop up into position. To lower the magnifier, gently push the Magnifier’s base plate all the way down until clicks into place. Removing the Finder Push the finder’s Lock Release Button (5) while pushing down on the Down Arrow Button at the opposite side and lift up.
- Page 4 Folding the Hood After lowering the Magnifier, gently squeeze the right and left panels of the Hood together, and then release and the Hood will close. Using the Sports Finder With the Waist Level Finder N in the closed position, pull out the Sports Finder’s eyepiece until it stops. Next, raise both the Sports Finder’s wire frame and eyepiece to a vertical position.
