80mm Macro C Lens

English Instructions

Need help?

Do you have a question about the 645 and is the answer not in the manual?

Page 1 80mm Macro C Lens English Instructions...
Page 2 Names of Parts Filter Mounting Ring 2) Magnification Selector Button Magnification Selector Ring 4) Distance Scale 6) Exposure Meter Coupler Aperture Ring 7) Alignment Dot for Lens Coupling 8) Lens Release Button 9) Knurled Ring 10) Coupler Ring 11) Diaphragm Actuating Lever 12) Aperture Ring Coupler 13) Diaphragm Actuating Pin 14) Alignment Red Line for Camera Body...
Page 3 In this floating system, a portion of lens elements moves back and forth in accordance with the photographing distance to obtain the optimum lens performance. Although this lens does not feature a hood, it provides a sufficient hood effect. I f it is absolutely necessary to use a hood, you can use one which is designed for the 80mm f l 1.9 lens, 67mm ¢...
Page 4 necessary.) When the Auto Macro Spacer and the lens have been aligned and fitted, rotate the lens clockwise until it stops. When the lens is rotated up to the stop position, t he lens release button (8) pops out to lock it. When attaching the Macro Spacer combined with the lens to the camera body, attach them after aligning the alignment line (14) with the alignment dot (A) of the camera body, and rotate the lens clockwise until it stops.
Page 5 Removing the Auto Macro Spacer When removing the lens, remove the Auto Macro Spacer from the camera body with lens. To remove the Macro Spacer, rotate it counterclockwise until it stops, while depressing the Release Button (B) on the camera body.
