S3510PD15
Single Handle Pull-Down Kitchen Faucet
Operation and Maintenance Manual
Model Numbers
☐
S3510MBPD15
Single Handle Pull-Down Kitchen
Faucet, Matte Black
☐
S3510STSPD15 Single Handle Pull-Down Kitchen
Faucet, Stainless Steel
☐
S3510PD15
Single Handle Pull-Down Kitchen
Faucet, Polished Chrome
Compliance
- ASME A112.18.2-2020/CSA B125.2-20
WARNING: This product can expose you to chemicals
including lead, which is known to the state of
California to cause cancer, birth defects, or other
reproductive harm. For more information, go to
www.P65Warnings.ca.gov.
RECOMMENDED TOOLS
Adjustable Wrench
Symmons Industries, Inc.
Copyright © 2022 Symmons Industries, Inc.
Dia
c
2.5mm Hex Key
Measuring Tape
■
■
31 Brooks Drive
Braintree, MA 02184
■
®
Feature Highlights
•
Single hole mount
•
Quarter turn ceramic cartridge
•
Pull-down spray wand with 2 mode selector
•
3/8 inch supply hose compression connnections
•
1.5 gpm (5.7 L/min) aerator comes standard
•
Metal construction plated in polished chrome finish
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Phillips Head Screwdriver
Soft Jaw Pliers
■
Phone: (800) 796-6667
■
symmons.com
gethelp@symmons.com
Safety Glasses
Silicone
■
Fax: (800) 961-9621
■
■
ZV-3253 REV E
071922
