ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1865C21
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
2 PERSON RECOMMENDED
(Included)
(Not Included)
18.07.05
Advertisement
Related Manuals for Furniture of America YNJ-1865C21
Summary of Contents for Furniture of America YNJ-1865C21
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1865C21 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point Allen Wrench system that shows the degree of effort needed in assembling a specific (Included) product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
-
Page 6: Parts List
DRAWER CABINET ASSEMBLY INSTRUCTIONS MODEL # YNJ-1865C21 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 47.24" (W) X15.75" (D) X41.49" (H) 4PCS 4PCS... -
Page 7: Get Ready
DRAWER CABINET MODEL #YNJ-1865C21 Get Ready. Please group boards as below. Body 4PCS 4PCS 4PCS 4PCS 4PCS 4PCS 4PCS Drawer 2PCS Door /Shelf Page 7... - Page 8 ASSEMBLY INSTRUCTIONS STEP1 Hardware #1=9pcs Hardware #3=3pcs Hardware #7=1pc Hardware #8=2pcs front Align magnet (#7) to the holes of the panel (#A), then secure by using screws (#8). Use a dab of glue in dowel holes before inserting dowels (#3). Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=16pcs Hardware #3=8pcs This pin is spring assisted. Hardware #9=1pc Hardware #10=1pc Hardware #11=1set Hardware #12=1pc Hardware #13=1pc 90° Flip This pin is not spring assisted. Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP3 Hardware #2=2pcs Hardware #5=6pcs Please refer to page 5 on how to fasten cam locks(#2) to cam bolts (#1). Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP4 Hardware #14=12pcs Hardware #15=4pcs Hardware #16=16pcs The raised side is inward The feet of the table are inclined outward. Page 11...
- Page 12 ASSEMBLY INSTRUCTIONS STEP5 Hardware #2=7pcs Hardware #14=3pcs Hardware #17=1pc Hardware #18=4pcs Hardware #23=1pc Page 12...
- Page 13 ASSEMBLY INSTRUCTIONS STEP6 Hardware #2=16pcs Hardware #4=16pcs Hardware #12=4pcs Hardware #13=4pcs STEP7 Hardware #6=8pcs Place shelf pins to the desired height of the shelves (#G). Page 13...
- Page 14 ASSEMBLY INSTRUCTIONS Insert non-spring assisted pin of STEP8 Hardware #19=8pcs door (#F) first. Hardware #20=8pcs Hardware #21=8pcs Extend the two outer slides of the runners so that they could align with the sides of the drawer. Make sure the pre-drilled holes from the drawer align with the screw holes of the outer slides.
