- Page 1 TOOLS REQUIRED Phillips Screwdriver (Not Included) Hammer (Not Included) 2 - Persons Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. 1 / 15...
- Page 2 Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available and can help with assembly questions as well as, if necessary, replacing damaged or missing parts.
- Page 3 3 / 15...
-
Page 4: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 5 5 / 15...
-
Page 6: Coffee Table
COFFEE TABLE PARTS 2PCS 2PCS 2PCS HARDWARE ACCESSORIES 21PCS 21PCS 14PCS 4PCS 2PCS 1.97" 4PCS 26PCS 0.61" 0.59" 6 / 15... -
Page 7: Get Ready
GET READY Please group boards as below. 2PCS 2PCS 2PCS Body 7 / 15... - Page 8 Hardware x11PCS Hardware x12PCS OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 8 / 15...
- Page 9 Hardware x10PCS Hardware x2PCS OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). Part x1PC Part x1PC Part x1PC Hardware x2PCS Front Please refer to page 5 for detailed instructions on how to fasten cam locks (#2) to cam bolts (#1).
- Page 10 Part x1PC Hardware x3PCS Front The hole of panel back (#C) facing panel (#D). Part x1PC Hardware x5PCS Hardware x1PC Accessory x1PC Front 10 / 15...
- Page 11 Part x2PCS Part x2PCS Hardware x4PCS Front Hardware x4PCS Accessory x4PCS Front 11 / 15...
- Page 12 Part x1PC Hardware x3PCS Accessory x2PCS Front Use the provided stickers (#A3) to cover exposed locks. Part x1PC Part x1PC Part x2PCS Align and hook the springs to the hinges. 12 / 15...
- Page 13 Part x1PC Hardware x4PCS Front Hardware x16PCS Align hinges to the unit, then secure by using screws (#6). Front 13 / 15...
- Page 14 Part x1PC short Hardware x10PCS long Long and short is determined by the distance of the farthest holes to the end of the panel (#A). Front Align hinges to the holes of the top panel (#A), then secure by using screws (#6). 14 / 15...
- Page 15 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
