ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1878C21
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
Hammer
2 PERSON RECOMMENDED
(Included)
(Not Included)
(Not Included)
18.06.13
Advertisement
Related Manuals for Furniture of America YNJ-1878C21
Summary of Contents for Furniture of America YNJ-1878C21
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1878C21 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point Allen Wrench system that shows the degree of effort (Included) needed in assembling a specific product (with 1 being easy and 5 being Phillips Screwdriver difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
-
Page 6: Parts List
STORAGE RACK ASSEMBLY INSTRUCTIONS MODEL # YNJ-1878C21 Please keep for future reference PARTS LIST 2PCS 2PCS 2PCS DIMENSIONS 31.5" (W) X15.91" (D) X67.48" (H) Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions"... -
Page 7: Get Ready
STORAGE RACK MODEL #YNJ-1878C21 Get Ready. Please group boards as below. 2PCS 2PCS 1PCS 2PCS Page 7... - Page 8 ASSEMBLY INSTRUCTIONS STEP1 Use a dab of glue in dowel holes Hardware #1=6pcs before inserting dowels (#3). Hardware #3=12pcs Hardware #5=3pcs Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=20pcs Hardware #3=2pcs 180° Flip Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP3 Hardware #1=12pcs Hardware #3=12pcs Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP4 Hardware #1=4pcs Hardware #3=2pcs STEP5 Hardware #2=6pcs Please refer to page 5 on how to fasten cam locks. Page 11...
- Page 12 ASSEMBLY INSTRUCTIONS STEP6 Finished Side STEP7 Hardware #2=12pcs Page 12...
- Page 13 ASSEMBLY INSTRUCTIONS STEP8 Hardware #2=8pcs Page 13...
- Page 14 ASSEMBLY INSTRUCTIONS STEP9 Hardware #2=10pcs Hardware #4=6pcs Flip right side up when completed. Page 14...
- Page 15 ASSEMBLY INSTRUCTIONS STEP10 Hardware #2=6pcs Hardware #4=5pcs Hardware #6=4pcs Carefully lay until flat to the ground once this is completed. Carefully tap floor protectors (#6) to the bottom of the unit. Page 15...
- Page 16 ASSEMBLY INSTRUCTIONS STEP11 Hardware #7=8pcs Hardware #8=8pcs Hardware #10=1pc Hardware #11=1set Hardware #12=1pc Wall For safety,please use the strap to secure the uniton the wall. Align fixative plate (#7) to the grooves of the back panels (#W,Y), then secure by using screws (#8). Make sure the product is rested on a flat surface and does not feel loose or wobbly.
- Page 17 Page 17...
