ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-1886C1
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
Hammer
2 PERSON RECOMMENDED
(Included)
(Not Included)
(Not Included)
18.08.22
Advertisement
Related Manuals for Furniture of America YNJ-1886C1
Summary of Contents for Furniture of America YNJ-1886C1
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-1886C1 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point Allen Wrench system that shows the degree of effort (Included) needed in assembling a specific product (with 1 being easy and 5 being Phillips Screwdriver difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
- Page 6 BOOKSHELF ASSEMBLY INSTRUCTIONS MODEL # YNJ-1886C1 Please keep for future reference PARTS LIST 4PCS 4PCS 4PCS 2PCS 2PCS DIMENSIONS 33.31(W) X11.97" (D) X62.99" (H) Before you begin, please 2PCS read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions"...
-
Page 7: Get Ready
BOOKSHELF MODEL #YNJ-1886C1 Get Ready. Please group boards as below. 4PCS 4PCS 4PCS Body 2PCS Glass 2PCS 2PCS Feet Page 7... - Page 8 ASSEMBLY INSTRUCTIONS Please refer to page 5 on how to STEP1 Hardware #1=4pcs fasten cam locks(#2) to cam Hardware #2=4pcs bolts (#1). Hardware #3=8pcs REMOVE ALL STICKER LABELS ON PANELS (#A,B,C) BEFORE PROCEEDING TO STEP 2. Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP2 Hardware #4=32pcs Hardware #5=32pcs Hardware #6=32pcs Bolts (#6) with washers (#5) will be connecting to barrel nuts (#4). front Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP3 Hardware #6=4pcs Hardware #7=4pcs Hardware #8=8pcs Align panels (#D,E) to the bottom of panels (#F), then secure by tightening bolts (#6) to the bolt nuts (#7). Softly hammer in the floor protectors to panels (#D,E). Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP4 Hardware #9=1pc Hardware #10=1set Hardware #11=1pc Wall For safety,please use the strap to secure the uniton the wall. Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
