ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-18702C1
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
2 PERSON RECOMMENDED
(Included)
(Not Included)
18.11.12
Advertisement
Related Manuals for Furniture of America YNJ-18702C1
Summary of Contents for Furniture of America YNJ-18702C1
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-18702C1 Tools Required for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point Allen Wrench system that shows the degree of effort needed in assembling a specific (Included) product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Page 5...
-
Page 6: Parts List
BUFFET ASSEMBLY INSTRUCTIONS MODEL # YNJ-18702C1 Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 47.25" (W) X15.75" (D) X40.31" (H) 4PCS 2PCS 4PCS... -
Page 7: Get Ready
BUFFET MODEL #YNJ-18702C1 Get Ready. Please group boards as below. 2PCS 2PCS 2PCS Body 4PCS Feet 4PCS 2PCS 2PCS Door Page 7... - Page 8 ASSEMBLY INSTRUCTIONS Use a dab of glue in dowel holes STEP1 before inserting dowels (#3). Hardware #1=12pcs Hardware #3=6pcs Hardware #20=1pc Hardware #21=4pcs Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP2 Hardware #6=3pcs Hardware #7=1pc Hardware #8=2pcs Hardware #9=2pcs Hardware #10=12pcs 10 10 Fold panel (#I) to a 90 degree angle to secure handle (#7) onto panel (#I). Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP3 Hardware #2=6pcs Hardware #4=8pcs Please refer to page 5 on how to fasten cam locks(#2) to cam bolts (#1). Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP4 Hardware #2=2pcs Hardware #11=12pcs Hardware #12=4pcs Hardware #14=16pcs HIGH Secure leg to panel (#B) with screws (#14).The lower point of the leg attachment (#12) should face the corners of panel (#B). Page 11...
- Page 12 ASSEMBLY INSTRUCTIONS STEP5 Hardware #11=3pcs Hardware #13=1pc Hardware #14=4pcs Hardware #15=1pc STEP6 Hardware #2=2pcs Back panels (#K) slides to the thin lined gaps of the panels. The wine glass rack (#20) is on this half side of panel (#A) on the other side.
- Page 13 ASSEMBLY INSTRUCTIONS STEP7 Hardware #2=2pcs Hardware #5=4pcs Do not tighten up screws. Page 13...
- Page 14 ASSEMBLY INSTRUCTIONS STEP8 Slide panels (#E) to the V-grooves of the unit. Page 14...
- Page 15 ASSEMBLY INSTRUCTIONS STEP9 Hardware #4=8pcs Insert panels (#H) to the other panel (#H) in the unit then secure by using screws (#4). Page 15...
- Page 16 ASSEMBLY INSTRUCTIONS STEP10 Hardware #22=10pcs Make sure to tight up all screws before putting product in right position. Use the provided stickers (#22) to cover exposed locks. Page 16...
- Page 17 ASSEMBLY INSTRUCTIONS STEP11 Insert the top door pins on the door panels (#J,I) first before the bottom door pin. STEP12 Hardware #14=8pcs Secure back panels (#K) by using screws (#14). Page 17...
- Page 18 ASSEMBLY INSTRUCTIONS STEP13 Hardware #17=1pc Hardware #18=1set Hardware #19=1pc Wall For safety,please use the strap to secure the uniton the wall. Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
- Page 19 Page 19...
