Specification
Model
TR-D9151IR2
Image sensor
1/2.8" CMOS 5Mp
Resolution
5MP(2592x1944)
4MP(2592x1520)
3MP(2304x1296)
Frame rate
5MP@15fps
4MP@20fps
3MP@25fps
Electronic Shutter Speed
1/2 ~ 1/1 000 s
Day/Night Mode
Mechanical ICR
Sensitivity
0.003Lux (F1.8)
IR range
up to 25 m
Lens (mm)
Field of view (horiz./vert.)
180˚ / 180˚
WDR
Real WDR (120dB)
Digital noise reduction
Video compression
Н.265 / H.264
Bitrate
up to 8Mbps
Local storage
MicroSD up to 128Gb
Audio
Built-in microphone
AudioIn / AudioOut
Alarm In / Out
Corridor mode
Power supply
PoE (802.3af) / 12V DC
Class PoE
Power consumption
DC: 6.24W
PoE: 6.72W
Case material
Dimensions (mm)
Ø120 x 58
Weight Net/Gross (g)
380 / 550
Ingress protection
Lightning protection
TVS 4000V
Working temperature
-30°C ... +60°C
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
1.4
3D DNR
1 / 1
Yes
3
Metal
IP65
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D9151IR2
Fisheye Network Camera
H.265
HEVC
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
Advertisement
Related Manuals for TRASSIR TR-D9151IR2
Summary of Contents for TRASSIR TR-D9151IR2
- Page 1 380 / 550 H.265 Ingress protection IP65 HEVC Lightning protection TVS 4000V Working temperature -30°C … +60°C Data ___________________________ Stamp ___________________________ Here is the confirmation form for warranty assurance Note: read user manual before using Website: www.trassir.com For any inquiry: info@trassir.com...
- Page 2 ** Device must be grounded 2. Set up camera IP address using fast configuration utility that can be downloaded from www.trassir.com. 3. Change IP camera settings using TRASSIR professional software. Camera Package You can find detailed camera settings instructions in User Manual that can be downloaded from trassir.com.
