GP00 GP01 GP03 GP10 GP11 GP30
Size
<ligne>
Height
<mm>
Accuracy
<per Month>
Battery
Life
Battery consumption could be minimum
by pulling out the stem (=Power-Saving)
Balance
Weight
<μN.m>
Clearance
Original
Package
12'''
4.40
±20
sec
3
years
1.00
Minute
0.08
Second
0.07
Retro-24H
0.14
Small
case
0.3-0.4mm
Hand
Movement
0.20mm
500
pcs
Setting the Date
DO NOT set Date between 9:00pm – 2:00am
Setting the Dual Time
Turn crown counter-clockwise
Setting the Time
065-992
Attached
Stem
Φ27.0
SR920SW
24
26
DT
Date
Retrograde
24 Hour
Dual Time
GP00
26
DT
GP03
26
24
DT
GP11
26
Small-Second
GP01
26
DT
GP10
26
GP30
26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Citizen GP00

Summary of Contents for Citizen GP00

  • Page 1 GP00 GP01 GP03 GP10 GP11 GP30 Size 12’’’ 065-992 <ligne> Attached Stem Height 4.40 Φ27.0 SR920SW <mm> ±20 Accuracy <per Month> Battery years Life Date Retrograde 24 Hour Small-Second Dual Time GP00 GP01 Battery consumption could be minimum by pulling out the stem (=Power-Saving) Balance 1.00...
  • Page 2 HAND FITTING MANUAL GP00/01 GP50/52 http://www.citizen.co.jp/miyota_mvt/manual/swf/main.swf http://www.citizen.co.jp/miyota_mvt/manual/swf/gp50_52_eg.swf...
  • Page 3 MIYOTA MOVEMENT SPECIFICATIONS CAL. GP SERIES ANALOG QUARTZ MOV'T BY CITIZEN WATCH CO., LTD. DUAL TIME / BIG DATE / SMALL SECOND / DOUBLE RETROGRADE MANUFACTURED IN JAPAN 1.BASIC SPECIFICATION (1) CAL. NO. GP00 GP00 GP00 GP00 GP01 GP01 GP01...
  • Page 4 : Pull out the crown to the first click position, turn crown clockwise. *If the date is set beween 9:00 PM and 2:00 AM, the date may not change on the following day. 2nd time(GP00/GP01/GP50) : 24 hour hand at 6H (by Retrograde)
  • Page 5 2nd time correction( 〃) : Pull out the crown to the first click position, turn crown counter-clockwise. Power conservation switch : Pull out the crown to the second click position Second hand stopping devise : Pull out the crown to the second click position 2.
  • Page 6 5.Setting Instructions (1) Setting the date (Quick change function) Pull the crown out to the first click position and set the date by rotating the crown backyard. If the date is set beween 11:00 PM and 3:00 AM, the date will not change correctly. (2) Setting the normal time Pull the crown out to the second click position when the second hand reaches the 12 o'clock position so that the second hand stops there.
  • Page 7 Hands Fitting Manual ◆Hand Fitting ◆Hand Fitting ◆Hand Fitting ◆Hand Fitting GP00　Date Dial 12H　　　GP01　Date Dial ３H 1） PULL THE CROWN TO 2ND CLICK POSITION AND TURN CLOCKWISE (RIGHT) TO CHANGE THE DATE. 　　　　　・ ROTATING CALENDAR 　　　　　　EXP.） ５TH→６TH 　　　　 　 　 　 CAUTION CAUTION ：...
  • Page 8 装针事项 装针事项 装针事项 装针事项 ◆ ◆ ◆ ◆ 装针方法 装针方法 装针方法 装针方法 GP00　12点位日历窗　　GP01　3点位日历窗 把柄头拉到2段位置 顺时针转动调整日历。 　　　　　・ 日历调整 　　　　　　比如. 5日→ 6日 　　　　 　 　 　 注意事项 注意事项 注意事项 注意事项 一旦日历板完成换日后 立刻停止 转日历。因为如果多转的话 会引起今后的 把柄头拉到2段位 　　　　　 换历早于正常时间。 后 带动日历工作 把柄头拉到1段位置 快调24小时飞返指针 使之回到 位置。...
  • Page 12 ***** CALL. GP00/01/30/10/11/50/03/52 MOV'T PARTS LIST ***** ORIGINAL PARTS, MADE IN JAPAN PART NAME GP00 GP01 GP30 GP10 GP11 GP50 GP03 GP52 BATTERY 280-3104 280-3104 280-3104 280-3104 280-3104 280-3104280-3104 280-3104 BATTERY CLAMP 234-A87 234-A88 234-A89 234-B00 234-B01 234-B03 234-B06 234-B07...

  • Page 13: Setting The Time

    MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT INSTRUCTION MANUAL FOR MIYOTA WATCH MOVEMENT CALIBER NO. GP01 BATTERY: SR920SW A) DISPLAYS B) SETTING THE TIME C) SETTING THE DATE D) SETTING THE 2nd TIME (24 Hours) Hour hand Minute hand 1st position 2nd position...
  • Page 14 MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT ミヨタウォッチムーブメント取扱説明書 キャリバー番号: GP01 電池: SR920SW A) 表示部 B) 時刻の合わせ方 C) 日付の合わせ方 D) 第二時刻の合わせ方（２４時間） 時針 分針 リューズ一段引き リューズ二段引き 通常リューズ位置 日付 秒針 第二時刻 (0時間〜24時間) 時刻の合わせ方 1. リューズを二段引きます。 2. リューズを回して時針と分針を合わせます。 3. リューズを通常位置に戻すと、秒針が動き始めます。 C) 日付の合わせ方 1. リューズを一段引きます。 2.
  • Page 15 MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT BEDIENUNGSANLEITUNG FÜR MIYOTA UHRWERK KALIBER NR. GP01 BATTERY: SR920SW A) DISPLAY B) EINSTELLUNG DER ZEIT C) EINSTELLUNG DES DATUMS D) EINSTELLEN DER ZWEITZEIT (24H) Stundenzeiger Minutenzeiger Erste Position Zweite Position Normale Kronenposition Datums Sekundenzeiger...

  • Page 16: Réglage De L'heure

    MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT MODE D'EMPLOI DU MOUVEMENT DE MONTRE MIYOTA CALIBRE: GP01 PILE: SR920SW A) INDICATIONS B) RÉGLAGE DE L'HEURE C) RÉGLAGE DE LA DATE D) RÉGLAGE DE LA 2nde HEURE (24 H) Aiguille Aiguille des minutes des heures...

  • Page 17: Ajustando La Hora

    MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT MANUAL DE INSTRUCCIONES DEL RELOJ MIYOTA N˚ DE CALIBRE: GP01 PILA: SR920SW A) VISUALIZACIÓN B) AJUSTE DE LA HORA C) AJUSTE DE LA FECHA D) AJUSTE DEL 2do. HORARIO Manecilla de la hora Manecilla de los minutos...

  • Page 18: Impostazione Dell'orario

    MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT MANUALE DI ISTRUZIONI PER IL MOVIMENTO DELL’OROLOGIO MIYOTA CALIBRO NO: GP01 PILA: SR920SW A) VISUALIZZAZIONI B) IMPOSTAZIONE DELL’ORARIO C) IMPOSTAZIONE DELLA DATA D) IMPOSTAZIONE DELL’ORARIO SECONDARIO (24 H) Lancetta Lancetta dei minuti delle ore posizione...

  • Page 19: Definição Da Data

    MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT MANUAL DE INSTRUÇÕES PARA MOVIMENTO DO RELÓGIO MIYOTA CALIBRE Nº: GP01 PILHA: SR920SW A) MOSTRADOR B) DEFINIÇÃO DA HORA C) DEFINIÇÃO DA DATA D) DEFINIÇÃO DA 2ª HORA (24 Horas) Ponteiro das horas Ponteiro dos minutos...
  • Page 20 MIYOTA 誕生於日本的驚世傑作 日本製造 金屬機芯 MIYOTA手錶使用說明書 CALIBER NO. GP01 電池: SR920SW A) 顯示幕 B) 時間的調整 C) 日期的調整 D) 第二時間的設定（24H） 時針 分針 位置 1 位置 2 錶冠的原位 日期 秒針 第二時間 (0小時至24小時) B) 時間的調整 1. 將錶冠拉出至位置2。 2. 轉動錶冠調整時針及分針。 3. 將錶冠按回原位時，秒針將開始轉動。 C) 日期的調整 1. 將錶冠拉出至位置1。 2.
  • Page 21 MIYOTA UNIVERSAL MASTERPIECE BORN IN JAPAN MADE IN JAPAN METAL MOVEMENT MИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ ЧАСОВ «МИЁТА» КАЛИБР № : GP01 БАТАРЕЯ: SR920SW А) ЦИФЕРБЛАТ Б) ВЫСТАВЛЕНИЕ ВРЕМЕНИ В) ВЫСТАВЛЕНИЕ ЧИСЛА Г) ВЫСТАВЛЕНИЕ 2-ГО ВРЕМЕНИ (24 Ч) часовая минутная стрелка стрелка 1-е...
