Summary of Contents for Yealink CP930W

  • Page 1: Table Of Contents

    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Video Tutorial 3 Requirements 3.1 Identifying phone model 3.2 Phone firmware 3.3 DHCP server 3.4 PBXware version 4 Installation 4.1 Power adapter 4.2 Power over Ethernet (PoE) 4.3 Find the phone IP address 4.4 Reset to factory settings...

  • Page 2: Video Tutorial

    To start and successfully complete registration of your Yealink phone you need to know which phone model you will setup. From the back of each Yealink phone there are exact model information that you should check. Although different phone models can have exactly the same requirements and installation...

  • Page 3: Phone Firmware

    Make sure that your phone is loaded with appropriate firmware version, 77.83.0.25. To find out the firmware version of your Yealink phone model open a new browser window and enter your phone IP address in order to access the phone web administration interface login screen.

  • Page 4: Power Over Ethernet (Poe)

    Do not unplug or remove power to the phone while it is updating firmware and configurations. Registering phone This chapter describes how to identify Yealink phone model, requirements that must be met and how to register the phone using manual configuration or auto provisioning.

  • Page 5: Manual Configuration

    UAD settings Navigate to Settings:UAD. Make sure Yealink UAD is enabled. To check the UAD status click on the edit icon corresponding to your Yealink phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
  • Page 6 Department to which extension will belong to. Example: Sales. Click on the Save button. Registering Phone This chapter describes how to register Yealink phone using Hostname or IP Address, or DNS SRV. The following topics are covered: Hostname or IP Address...
  • Page 7 Click on Account. Enter or set the following details into the respective fields. REQUIRED FIELDS: Account Active Make sure the On radio box is selected. Register Name PBXware extension number. Example: 1003 User Name Usually the same number as the Phone Number. Password The Secret of the extension as received in the e-mail associated with this extension.
  • Page 8 factory default login details are username: admin and password: admin. Click on Account. Enter or set the following details into the respective fields. REQUIRED FIELDS: Account Active Make sure the On radio box is selected. Register Name PBXware extension number. Example: 1003 User Name Usually the same number as the Phone Number.

  • Page 9: Auto Provisioning

    UAD settings. Navigate to Settings:UAD. Make sure Yealink UAD is enabled. To check the UAD status click on the edit icon corresponding to your Yealink phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
  • Page 10 Enter Yealink phone MAC address. Example: 001565FF1536. MAC address can be found at the back of the phone. Click on the Save button. Registering Phone This chapter describes how to register Yealink phone using DHCP, TFTP, HTTP & HTTPS or DNS SRV. The following topics are covered: DHCP TFTP or HTTP &...
  • Page 11 Make sure your DHCP router is configured to use option 66 to automatically instruct phones with the URL for auto provisioning. For more information refer to your router documentation or contact your network administrator. Phone first boot or user initiated reboot Auto provisioning process will start during phone first boot or after reboot process has been initiated by user.

  • Page 12: Using Tls

    Example for IP Address USING HTTPS: https://192.168.1.10/prov Enter Auto Provisioning username and password into User Name and Password fields. If you choose to use server type TFTP enter tftp:// followed by Hostname or IP Address Example for Hostname: tftp://voip.bicomsystems.com Example for IP Address: tftp://192.168.1.10 Click on Autoprovision Now button.
  • Page 13 Auto Provisioning. Login to phone web administration interface If there is no DHCP in your network, you can still auto provision your Yealink phone. Please refer to your Yealink phone model User Guide for instruction about setting static IP address.

  • Page 14: Additional Configuration Template

    PBXware. Dial *123 to verify registration. Additional Configuration Template If You want to include some additional UAD configuration for Yealink CP930W, just add fields to User Agent General Auto Provisioning Template in Settings -> UAD -> Yealink W60B menu, or add them directly to the extension in UAD Auto Provisioning Template section.
