Phoenix Mecano OKIN REFINED RF54 Instructions

Issue Department：Bedding Division Date： 2017-8-15
System Instruction Author：
Instruction of RF54 Edition： 1.1
Page 1 of 5
Instruction of RF54
Figure 1 button ofremote
1.1 ZG button（button 10 in figure 1）
Click the ZG button, the actuator moves to ZG position, stop when click any button during the
movement;
Press and hold the ZG button for 5s, timer LED of remote flashes, the control box records
current position as ZG position;
When in the process of moving to memory positions, the head and foot actuators move first,
1 / 5
