For more information contact our team: service.ec@foagroup.com
CM3663 T -VN
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Rev : 19-01-16
Page 1 of 5
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3663T-VN
Summary of Contents for Furniture of America CM3663T-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3663 T -VN ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List Parts List #A x 12 pcs #1 x 1 pc Bolt 5/16”x2” Table Top #B x 12 pcs #2 x 1 pc Lock Washer...
- Page 4 Turn right (clockwise) to tighten #A x 4 pcs #B x 4 pcs #C x 4 pcs Align the 2 table bases (#5) with the pre-drilled holes on the pedestal (#3). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 5 Carefully turn the completed table upright. Make sure the table is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened. To insert the table leaf (#2) unlock the latches located under the table top (#1).
