Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM3663SC-2PK-VN

ASSEMBLY RATING

Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Rev : 19-01-16
