- Page 1 ASSEMBLY INSTRUCTIONS 56142 WHITE FINISH NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED. 1-15 000000000000...
- Page 2 This is a product: We inspect all wood and follow quality assurance guidelines that pass third-party inspections. Note: Real wood has knots, small cracks, and what may look like blemishes. These characteristics are expected when producing furniture from natural material. We take extra care with our drawer parts: 1.
- Page 3 Perform assembly on a clean, hard surface using the attened box or a towel to protect the surface & the unit's nish. DO NOT assemble on carpet. Carpet creates too much bounce making assembly di cult and could lead to damage of the parts. Safety and Care Advice ·...
- Page 4 Right Side Panel Left Side Panel Back Panel Right Front Foot Left Front Foot Back Foot Top Crossbar Bottom Panel Front Crossbar Drawer Back Drawer Bottom Drawer Front Right Drawer Side Left Drawer Side A = 24 B = 14 C = 05 D = 04 E = 06...
- Page 5 PREPARE PARTS FOR ASSEMBLY INSERT DOWELS INTO THE PARTS, AS SHOWN. A = 24 Dowel 8x30mm 5-15 NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED. NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED.
- Page 6 ATTACH SIDES PANELS AND BACK FEET PLACE THE DOWELS FITTED IN THE HOLES ON THE SIDE, TAKE CARE OF THE FOOT DIRECTION AND FIX IT WITH PART B. BACK OF UNIT BACK OF UNIT B = 04 Screw 3.5x30mm 6-15 NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED.
- Page 7 ATTACH SIDE PANELS AND FRONT FEET FIT FOOT SIDE THROUGH CHANNEL, TAKE CARE OF FOOT DIRECTION, INSERT PART I AND FIX WITH PARTS D AND F AS SHOWN. 1° 2° 3° BACK OF UNIT BACK OF UNIT D = 04 F = 04 I = 04 Screw...
-
Page 8: Front Of Unit
ATTACH DRAWER RUNNERS ON THE CABINET RIGHT SIDE PANEL WITH THE WHEEL END OF THE RUNNER TOWARD THE FRONT (FINISHED) EDGE OF THE PANEL, ALIGN THE PRE-DRILLED HOLE ACOORDING TO THE DIAGRAM AND TIGHTEEN WITH PART L. FRONT OF UNIT L = 02 O = 01 (Right Side) Screw (Drawer Runner... - Page 9 ATTACH MINIFIX ON THE SIDES PANEL CAREFULLY CHECK THE HOLES INDICATED AND FIX PART H AS SHOWN. DO NOT FORCE OR OVER-TIGHTEN THE SCREWS. DOING SO CAN DIFICULT THE ASSEMBLE H = 04 Mini x Screw 9-15 NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED. NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED.
- Page 10 ATTACH RAILS ATTACH TOP CROSSBAR IN THE TOP PANEL USING THE PART C AND FRONT CROSSBAR IN THE BOTTOM PANEL USING THE PART C AND. C = 04 Screw 4.0x40mm ATTACH MINIFIX TO THE TOP PANEL CAREFULLY CHECK THE HOLES INDICATED AND FIX PART H AS SHOWN. DO NOT FORCE OR OVER-TIGHTEN THE SCREWS.
- Page 11 ATTACH BOTTOM PANEL TO THE SIDE PANELS 1. ALIGN THE DOWELS IN THE BOTTOM PANEL WITH THE DOWEL HOLES AND MINIFIX IN THE RIGHT SIDE PANEL. THEN PUSH PARTS TOGETHER UNTIL FLUSH. 2. SECURE EACH BOTTOM PANEL WITH ONE PART G AND B. 3.
- Page 12 ATTACH THE BACK PANEL 1. UNFOLD THE BACK PANEL AND POSITION IT ON THE UNIT. 2. MAKE SURE THE BACK PANEL FITS INTO THE GROOVE ON THE BACK OF THE TOP PANEL. 3. SECURE THE BACK PANEL WITH THE BACK PANEL NAILS OBSERVING THE SQUARE. Use all back panels nails.
-
Page 13: Drawer Front
ASSEMBLE DRAWER BOX IMPORTANT: MAKE SURE THE GROOVES IN THE DRAWER FRONT AND BOTH SIDES ALL ALIGN BEFORE TIGHTEENING THE SCREWS. 1. ALIGN THE DOWELS 2. USE THE DRAWER BACK 3. REMOVE THE DRAWER IN THE DRAWER SIDES TO SUPPORT THE DRAWER BACK. - Page 14 ATTACH DRAWER RUNNERS 1. POSITION THE RIGHT DRAWER RUNNER “DR” WITH THE WHEEL TOWARD THE BACK OF THE DRAWER AND THE FRONT END ALL THE WAY FORWARD TOUCHING THE DRAWER FRONT. 2. FIRST SCREW GOES IN THE THIRD HOLE BACK FROM THE DRAWER FRONT. 3.
-
Page 15: Care Instructions
COMPLETED ASSEMBLY: THANK YOU FOR YOUR PURCHASE, AND WELCOME TO ADEPTUS! CARE INSTRUCTIONS: NORMAL USE: WIPE WITH A CLEAN CLOTH. WHEN NEEDED TO CLEAN SCUFFS: WIPE CLEAN WITH A SLIGHTLY DAMP CLOTH AND A MILD CLEANSER. THEN WIPE DRY WITH A CLEAN CLOTH. DO NOT USE HARSH CHEMICALS.
