FOR FASTER SERVICE ON PARTS, PLEASE GO TO OUR WEBSITE AT
OR CALL TOLL FREE 1.888.ADEPTUS (1.888.233.7887) FOR ASSEMBLY QUESTIONS.
IF WE ARE BUSY HELPING OTHER CUSTOMERS, PLEASE LEAVE YOUR NAME AND NUMBER
YOUR RETAILER MAY ALSO PROVIDE SERVICE OR PARTS.
SAVE THESE INSTRUCTION SHEETS AND THE BOX UNTIL YOU ARE SATISFIED WITH THE ASSEMBLY.
DO NOT GLUE THE PARTS OF THE UNIT TOGETHER UNLESS YOU HAVE TESTED THE ASSEMBLY FIRST.
PERFORM THE ASSEMBLY ON A CLEAN HARD SURFACE USING THE FLATTENED CARTON OR A TOWEL
TO PROTECT THE SURFACE AND THE FINISH OF THE UNIT. DO NOT ASSEMBLE ON CARPET.
NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED.
ASSEMBLY INSTRUCTIONS
#
56114 WHITE FINISH
#
53314 PECAN FINISH
MON- FRI 10 A.M. TO 4 P.M. E.S.T., CLOSED HOLIDAYS.
PRODUCT NAME AND STOCK NUMBER
WHEN AND WHERE THE UNIT WAS PURCHASED
P.O. NUMBER FROM THE BOTTOM OF THIS PAGE
TO RECEIVE A RETURN CALL.
NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED.
NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED.
1-15
B
00000000000
Advertisement
Related Manuals for adeptus 56114
Summary of Contents for adeptus 56114
- Page 1 56114 WHITE FINISH 53314 PECAN FINISH FOR FASTER SERVICE ON PARTS, PLEASE GO TO OUR WEBSITE AT OR CALL TOLL FREE 1.888.ADEPTUS (1.888.233.7887) FOR ASSEMBLY QUESTIONS. MON- FRI 10 A.M. TO 4 P.M. E.S.T., CLOSED HOLIDAYS. PRODUCT NAME AND STOCK NUMBER WHEN AND WHERE THE UNIT WAS PURCHASED P.O.
- Page 2 This is a product: We inspect all wood and follow quality assurance guidelines that pass third-party inspections. Note: Real wood has knots, small cracks, and what may look like blemishes. These characteristics are expected when producing furniture from natural material. We take extra care with our drawer parts: 1.
- Page 3 Perform assembly on a clean, hard surface using the attened box or a towel to protect the surface & the unit's nish. DO NOT assemble on carpet. Carpet creates too much bounce making assembly di cult and could lead to damage of the parts. Safety and Care Advice ·...
- Page 4 Right Side Panel Left Side Panel Back Panel Right Front Foot Left Front Foot Back Foot Top Crossbar Back Crossbar Front Crossbar Drawer Back Drawer Bottom Drawer Front Right Drawer Side Left Drawer Side A = 43 B = 53 C = 12 D = 06 E = 31...
- Page 5 PREPARE PARTS FOR ASSEMBLY INSERT DOWELS INTO THE PARTS, AS SHOWN. A = 43 Dowel 8x30mm 5-15 NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED. NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HERE IN ARE COPYRIGHTED.
- Page 6 ATTACH SIDES PANELS AND BACK FEET PLACE THE DOWELS FITTED IN THE HOLES ON THE SIDE, TAKE CARE OF THE FOOT DIRECTION AND FIX IT WITH PART B. BACK OF UNIT BACK OF UNIT B = 06 Screw 3.5x30mm 6-15 NOTICE: THE WRITTEN INSTRUCTIONS CONTAINED HEREIN ARE COPYRIGHTED.
- Page 7 ATTACH SIDE PANELS AND FRONT FEET FIT FOOT SIDE THROUGH CHANNEL, TAKE CARE OF FOOT DIRECTION, INSERT PART I AND FIX WITH PARTS D AND F AS SHOWN. 1° 2° 3° BACK OF UNIT BACK OF UNIT D = 06 F = 06 I = 06 Screw...
-
Page 8: Front Of Unit
ATTACH DRAWER RUNNERS ON THE CABINET RIGHT SIDE PANEL WITH THE WHEEL END OF THE RUNNER TOWARD THE FRONT (FINISHED) EDGE OF THE PANEL, ALIGN THE PRE-DRILLED HOLE ACOORDING TO THE DIAGRAM AND TIGHTEEN WITH PART L. FRONT OF UNIT L = 10 O = 05 (Right Side) Screw (Drawer Runner... - Page 9 ATTACH CROSSBARS TO THE SIDE PANELS 1. ALIGN THE DOWELS IN THE CROSSBARS WITH THE DOWEL HOLES IN THE RIGHT SIDE PANEL. THEN PUSH PARTS TOGETHER UNTIL FLUSH. 2. SECURE EACH CROSSBAR WITH ONE PART B. 3. REPEAT THE PROCESS ON THE LEFT SIDE. FRONT OF UNIT FRONT OF...
- Page 10 ATTACH MINIFIX TO THE TOP PANEL CAREFULLY CHECK THE HOLES INDICATED AND FIX PART H AS SHOWN. DO NOT FORCE OR OVER-TIGHTEN THE SCREWS. DOING SO CAN DIFICULT THE ASSEMBLE H = 06 Mini x Screw ATTACH THE TOP PANEL WITH SIDE PANELS ALIGN THE DOWELS AND MINIFIX IN THE SIDE PANELS WITH THE PRE-DRILLED HOLES IN THE TOP PANEL, THEN THEY SHOW THE TOP OF MINIFIX IN THE HOLES ON THE SIDE, INSERT PART G AND PRESS AS SHOWN IN THE DIAGRAM.
- Page 11 ATTACH THE BACK PANEL 1. UNFOLD THE BACK PANEL AND POSITION IT ON THE UNIT. 2. MAKE SURE THE BACK PANEL FITS INTO THE GROOVE ON THE BACK OF THE TOP PANEL. 3. SECURE THE BACK PANEL WITH THE BACK PANEL NAILS OBSERVING THE SQUARE. J J J Use all back panels nails.
- Page 12 SECURE THE UNIT TO THE WALL WITH THE ANTI-TIP KIT 1. INSERT THE ANCHOR INTO THE WALL APPROXIMATELY 1189MM (46,8IN) FROM THE FLOOR (ADJUST FOR CARPET OR RUG THICKNESS IF APLICABLE). 2. FEED PART B THROUGH THE SMALLER HOLE IN THE BRACKET AND SECURE INTO THE WALL ANCHOR.
-
Page 13: Drawer Front
ASSEMBLE 5X DRAWER BOX IMPORTANT: MAKE SURE THE GROOVES IN THE DRAWER FRONT AND BOTH SIDES ALL ALIGN BEFORE TIGHTEENING THE SCREWS. 1. ALIGN THE DOWELS 2. USE THE DRAWER BACK 3. REMOVE THE DRAWER IN THE DRAWER SIDES TO SUPPORT THE DRAWER BACK. - Page 14 ATTACH 5X DRAWER RUNNERS 1. POSITION THE RIGHT DRAWER RUNNER “DR” WITH THE WHEEL TOWARD THE BACK OF THE DRAWER AND THE FRONT END ALL THE WAY FORWARD TOUCHING THE DRAWER FRONT. 2. FIRST SCREW GOES IN THE THIRD HOLE BACK FROM THE DRAWER FRONT. 3.
-
Page 15: Care Instructions
COMPLETED ASSEMBLY: THANK YOU FOR YOUR PURCHASE, AND WELCOME TO ADEPTUS! CARE INSTRUCTIONS: NORMAL USE: WIPE WITH A CLEAN CLOTH. WHEN NEEDED TO CLEAN SCUFFS: WIPE CLEAN WITH A SLIGHTLY DAMP CLOTH AND A MILD CLEANSER. THEN WIPE DRY WITH A CLEAN CLOTH. DO NOT USE HARSH CHEMICALS.
