Summary of Contents for adeptus 78104
- Page 3 B=95 C=02 D=49 E=06 F=06 G=06 L=01 M=02 H=24 I=02 J=01 N=01 O=04...
- Page 4 A=66 PREPARE PARTS BY INSERTING DOWELS ATTACH FEET TO LEGS O=04...
- Page 5 L=01 D=01 C=01 ATTACH ANTI-TIP SAFETY STRAP ATTACH LEGS TO RIGHT SIDE PANEL RIGHT PANEL B=10...
- Page 6 ATTACH LEGS TO THE LEFT SIDE PANEL LEFT PANEL B=10 ATTACH LEFT DRAWER RUNNERS ( TO LEFT SIDE PANEL LEFT PANEL H=12...
-
Page 7: Left Panel
ATTACH RIGHT DRAWER RUNNERS H=12 ) TO RIGHT SIDE PANEL RIGHT PANEL ATTACH CROSSBARS TO LEFT SIDE PANEL B=08 LEFT PANEL... -
Page 8: Right Panel
ATTACH RIGHT SIDE PANEL TO CROSSBARS RIGHT PANEL B=08 TOP PANEL ATTACH THE TOP PANEL B=04... - Page 9 ATTACH BACK PANEL Before attaching the back panel, make sure the unit is assembled squarely. Use an "L" Square tool, if necessary, as shown. ATTACH THE ANTI-TIP SCREWS AND COVERS M=02 I=02 J=01...
- Page 10 ASSEMBLE THE LARGE DRAWER B=09 E=01 F=01 D=06 G=01 Make sure the opposite end is all the way forward touching the drawer front (part 14), as shown.
- Page 11 ASSEMBLE THE SMALL DRAWER B=09 E=01 F=01 D=06 G=01 Make sure the opposite end is all the way forward touching the drawer front (part 15), as shown.
- Page 12 ASSEMBLE THE MEDIUM DRAWERS (4X) B=36 E=04 F=04 D=24 G=04...
- Page 13 ANCHOR THE UNIT TO A WALL B=01 C=01 N=01 INSTALL THE DRAWERS X6 A=12...
- Page 14 ADJUST DRAWER ALIGNMENT D=12...
