Kamvas RDS-220
1. Working Area Setting
Define the pen display area that will be mapped to the monitor. Three modes on the driver
can be chosen:
[1] Full Area: The entire active area of the pen display will be mapped to the monitor. It is the
default setting.
[2] Screen Ratio: The ratio of the active pen display area depends on that of the display
device. In Screen Ratio mode, these two ratios keep the same. For example, if you choose the
screen ratio and draw a circle on the pen display, then a circle appears on the monitor that
has been connected to the pen display, in this case some parts of the pen display may not
work. But if you don't choose the screen ratio and draw a circle, then the circle may change
into an oval on the monitor.
[3] Custom Area:
1> Enter coordinate values.
2> Users can adjust the working area of the pen display by changing the outlines of the
smaller rectangle (see picture 1). Users can also drag the two blue rectangles to select the
active areas of the digital pen on the screen and the pen tablet. (see picture 2 and 3).
