Quick Setup Guide
1.3 Ports and Connectors
1.3.1 PS/2 Mouse and PS/2 Keyboard Ports
J1
Mouse
(Green)
KB
(Purple)
1.3.2 RJ45 Fast-Ethernet Port
J2
RJ45
LAN
10
PS/2 Mouse
PS/2 Keyboard
Make sure to turn off your
computer prior to connecting or
disconnecting a mouse or keyboard.
Failure to do so may damage the
system board.
RJ45 LAN
