Operating Instructions & Parts Manual
Model Number
ATD-7452
ATD-7453
ATD-7454
ATD-7455
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Leer, comprender, y seguir las instrucciónes antes de utilizar el aparato.
El manual de instrucciónes y la información de seguridad deben estar comunicado en lengua del operador
antes del uso.
No seguir estas indicaciónes puede causar daños personales o materiales.
WARNING: This product may contain chemicals, including lead, known to the State of California to cause cancer,
Bench Press
Shop Presses
(Bench Press)
(ATD-7454 shown)
!
ADVERTENCIA
birth defects or other reproductive harm. Wash hands after handling.
Visit us at www.atdtools.com
Capacity
12 Ton
12 Ton
20 Ton
25 Ton
(ATD-7455 shown)
ATD7452-ATD7455_rev_0417
Printed in China
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ATD Tools 7452
Summary of Contents for ATD Tools 7452
- Page 1 Bench Press Shop Presses Operating Instructions & Parts Manual Capacity Model Number ATD-7452 12 Ton (Bench Press) ATD-7453 12 Ton ATD-7454 20 Ton ATD-7455 25 Ton (ATD-7455 shown) (ATD-7454 shown) This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
-
Page 2: Safety And General Information
Manuals are available from manufacturer. PRODUCT DESCRIPTION ATD Tools Bench Press & Shop Press are designed for automotive, truck, implement, eet, and industrial repair shops where pressing, bending, straightening and forming, is required. Typical applications include installation and removal of alternator and power steering pump bearings, axle bearings, transmission bearings, seals, u-joints and others. It... - Page 3 PREPARATION Before Use 1. Verify that the product and application are compatible, if in doubt call for Technical Assistance (888) 332-6419. 2. Before using this product, read the operator's manual completely and familiarize yourself thoroughly with the product, its components and recognize the hazards associated with its use. 3.
- Page 4 Assembly Size of Hardware Kits Model ATD-7454: (Refer to Figure 3) bolt M10x25 lock washer Note: Do not tighten any bolts unless told to do so. 1. Attach base legs (1) to upright channels (2) with bolts, lock washers and nuts (3). Hand tighten only. 11 bolt M16x150 2.
- Page 5 Hydraulic Couplers (1/4" NPT) Upper Cross Member Hydraulic Hose Bearing Punch Pump Handle Release Valve Hand Pump Bed Frame Oil Filler Screw Support Pin Pump Bracket Arbor Plate Upright Channel Support Link Base Leg Lower Cross Member Figure 4 - Shop Press components (ATD-7455 shown) Assembly Model ATD-7455: (Refer to Figure 5)
-
Page 6: Operation
WARNING Study, understand, and follow all printed materials provided with/on this product before use. Always use an adequately rated, calibrated load cell with digital indicator to monitor pressing force! Do not exceed rated capacity. Use the device only on a hard, level surface. Always wear safety goggles when working on or near this equipment. -
Page 7: Maintenance
Periodically, lightly oil all moving parts, including the pump piston and ram. Adding/Changing oil to bottle jack For Bottle Jack models ATD-7452, ATD-7453 & ATD-7454: Important: Use only good grade hydraulic jack oil. Avoid mixing different types of... - Page 8 Base Leg T060-03000-000 T125-02000-000 Bead Frame T060-01000-100 T184-00006-000 Lower Cross Member T184-00007-000 T125-00007-000 Arbor Plates (pair) T126-01000-000 Head Plate T060-06000-000 T126-04000-000 Hardware Kit Figure 7 - Replacement Parts Illustration for ATD-7452 and ATD-7453 Figure 8 - Replacement Parts Illustration for ATD-7454...
- Page 9 Replacement Parts Illustration for model ATD-7455 Item Part# for model: Description T125-00001-000 Upper Cross Member T125-00003-000 Punch T125-00007-000 Arbor Plates (pair) T125-02000-000 Bed Frame T125-01000-000 Support Pin T125-00002-000 Upright Channel T184-00006-000 Lower Cross Member T184-00004-000 Support Link T184-00005-000 Base Leg T184-00003-000 Pump Bracket F100-90004-K01...
-
Page 10: Troubleshooting
When ordering parts, give model number, part number and description. Call your distributor for current pricing. ATD Tools, Inc. 160 Enterprise Drive www.atdtools.com... -
Page 11: One-Year Limited Warranty
ONE YEAR LIMITED WARRANTY For a period of one (1) year from date of purchase, ATD Tools, Inc. will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship, or which fails to conform to any implied warranty not excluded hereby. - Page 12 Notes ATD Tools, Inc. 160 Enterprise Drive Wentzville, MO 63385 www.atdtools.com...
