Figure 4-14-2: RMON Event Configuration Page Screenshot
The page includes the following fields:
Object
Select Index
Index
Type
Community
Owner
Description
Buttons
: Click to apply changes.
NS3503-16P-4C User Manual
Description
Select index for this drop down list to create new index or modify index
Indicates the index of the entry. The range is from 1 to 65535
Indicates the notification of the event, the possible types are:
none: The total number of octets received on the interface, including framing
characters.
log: The number of uni-cast packets delivered to a higher-layer protocol.
SNMP-Trap: The number of broad-cast and multi-cast packets delivered to a
higher-layer protocol.
Log and Trap: The number of inbound packets that are discarded even the
packets are normal.
Specify the community when trap is sent, the string length is from 0 to 127,
default is "public".
Indicates the owner of this event, the string length is from 0 to 127, default is a
null string
Indicates description of this event, the string length is from 0 to 127, default is a
null string
