Tacacs+ Server - Interlogix NS3503-16P-4C User Manual

Priority
Dead Time
Usage Type
Modify

4.9.3 TACACS+ Server

This page is to configure the RADIUS server connection session parameters. The RADIUS Settings
screens in Figure 4-9-13, Figure 4-9-14 and Figure 4-9-15 appear.
Figure 4-9-13 Guest VLAN Setting Page Screenshot
The page includes the following fields:
Object
Key String
Timeout for Reply
Buttons
: Click to apply changes.
NS3503-16P-4C User Manual
Display the current priority
Display the current dead time
Display the current usage type
Click to edit login authentication list parameter.
Click to delete login authentication list entry.
Description
The secret key - up to 63 characters long - shared between the TACACS+
server and the switch.
Retransmit is the number of times, in the range 1 to 30, a TACACS+ request is
retransmitted to a server that is not responding. If the server has not
responded after the last retransmit it is considered to be dead.
199
