Object
Chassis ID Subtype
Chassis ID
System Name
System Description
Capabilities Supported
Capabilities Enabled
Port ID Subtype
Figure 4-12-8 Port Status Page Screenshot
The page includes the following fields:
Object
Interface
LLDP Status
LLDP MED Status

4.12.5 LLDP Remove Device

This page provides a status overview for all LLDP remove devices. The displayed table contains a row
for each port on which an LLDP neighbor is detected. The LLDP Remove Device screen in Figure 4-12-9
appears.
NS3503-16P-4C User Manual
Description
Display the current chassis ID subtype
Display the current chassis ID
Display the current system name
Display the current system description
Display the current capabilities supported
Display the current capabilities enabled
Display the current port ID subtype
Description
The switch port number of the logical port.
Display the current LLDP status
Display the current LLDP MED Status
