4.8.4.2 Egress Bandwidth Control

This page provides to select the egress bandwidth preamble. The Egress Bandwidth Control Setting and
Status screens in Figure 4-8-18 and Figure 4-8-19 appear.
Figure 4-8-18 Egress Bandwidth Control Settings Page Screenshot
The page includes the following fields:
Object
Port
State
Rate (Kbps)
Buttons
: Click to apply changes.
Figure 4-8-19 Egress Bandwidth Control Status Page Screenshot
The page includes the following fields:
Object
Port
Egress Rate Limit (Kbps)
NS3503-16P-4C User Manual
Description
Select port number for this drop down list
Enable or disable the port rate policer. The default value is "Disabled".
Configure the rate for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000.
Description
The switch port number of the logical port
Display the current egress rate limit
