Commercial
Dimmer Pack
Installation &
Operation Guide
2408CD - DIMMER PACK
2408CR - RELAY PACK
DI-400-N2408-00D
1
2
3
4
5
6
7
8
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
O
20
O
20
O
20
O
20
CIRCUIT BREAKERS
O
20
O
20
O
20
O
20
OFF
2408 CD
COMMERCIAL DIMMER PACK
2400 WATTS PER CHANNEL
LEVITON MANUFACTURING CO.
TUALATIN, OREGON
MADE IN U.S.A.
