Leviton decora 6672-L Installation Instructions

WARNINGS AND CAUTIONS:
TO AVOID FIRE, SHOCK, OR DEATH; TURN OFF POWER AT CIRCUIT BREAKER OR FUSE AND
TEST THAT POWER IS OFF BEFORE WIRING!
a receptacle, fluorescent lighting, a motor- or a transformer-operated appliance.
Tools needed to install your Dimmer
Pencil Cutters
Installing Dimmer by itself or with other devices
If installing Dimmer in a single device application, proceed with the
INSTALLING YOUR DIMMER section. If installing Dimmer in a
multi-device application, proceed as follows:
MULTI-DEVICE APPLICATION:
In incandescent multi-dimmer installations, the reduction of the dimmer's
multi-dimmer installations.
MAXIMUM LOAD PER DIMMER FOR MULTI-DEVICE
Cat. No. Single Two Devices
6672 600W 500W
INSTALLING YOUR DIMMER
NOTE: Use check boxes when steps are completed.
WARNING:
TO AVOID FIRE, SHOCK, OR DEATH;
Step 1
TURN OFF POWER at circuit breaker or fuse and test that
power is off before wiring!
OFF ON OFF ON
OFF ON OFF ON
OFF ON OFF ON
OFF ON OFF ON
OFF ON OFF ON
OFF ON OFF ON
Removing existing switch:
Step 2
wallplate and switch mounting screws. Carefully pull switch
from wall box. DO NOT remove wires attached to the
switch at this time.
Cat. No. 6672-L (optional locator light)
600W Incandescent, 150W Dimmable LED & CFL
INSTALLATION INSTRUCTIONS
Identifying your wiring application
Step 3
(most common):
NOTE: If the wiring in the wall box does not resemble any of
Ruler
these configurations, consult an electrician.
More than 2 Devices
Disconnecting switch wires and preparing wires:
Step 4
400W
Quickwire™ slots (shown).
wall box are straight (cut if necessary).
wire in the wall box (shown).
Cut (if necessary)
Remove existing
Slide Dimmer
WARNINGS AND CAUTIONS:
Use with compatible dimmable LED, CFL bulbs, incandescent or 120V halogen fixtures only. For a
complete list of compatible LED and CFL bulbs refer to www.leviton.com.
Use this device with copper or copper clad wire only.
Single-Pole:
Look at the back of your switch.
If there are 2 wires connected
to two screw terminals (not
including a green or bare copper
wire used for grounding), you
have a Single-Pole switch.
Press in slot and
pull out wire
5/8"
Strip Gage
Single-Pole Wiring Application:
Step 5
Neutral
Black
Ground
Green
Black
Dimmer
Hot (Black)
Black Black
Line 120VAC, 60 Hz
Neutral (White)
Connect wires per WIRING DIAGRAM as follows:
Screw wire nuts on clockwise making sure no bare conductors show below
the wire connectors. Secure each connector with electrical tape.
Green dimmer Ground lead to Green or bare copper wire in wall box.
Black dimmer lead to any wall box wire removed from old switch.
Remaining Black dimmer lead to remaining wall box wire.
DI-000-06672-02A
Insert wires
straight
then twist
clockwise
Black
Load
Green
Ground
White
