Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YXC70VPXG B85-F8199-7A...
Page 2 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold. EC Declaration of Conformity conforming to Directive 2006/42/EC We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product YXC700E (YXC70VPXG) (5Y4AMC4W0E0500101–)
Page 3 Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of crafts- manship and reliability that have made Yamaha a leader in these fields.
Page 4 EBU31080 IMPORTANT MANUAL INFORMATION EBU31070 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI- OUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to poten- tial personal injury hazards.
Page 5 It is illegal to operate this vehicle on public lands where vehicles its size are prohibited. EBU33130 YXC70VPXG OWNER’S MANUAL ©2015 by Yamaha Motor Co., Ltd. 1st edition, May 2015 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.
Page 6 EBU31120 Parking brake lever ......4-13 CONTENTS Drive select lever ........ 4-14 Fuel tank cap........4-14 LOCATION OF THE WARNING AND Doors..........4-15 SPECIFICATION LABELS ....... 1-1 Seats ..........4-15 Adjusting the driver seat position..4-16 SAFETY INFORMATION ......2-1 Seat belts ...........
Page 7 Differential gear oil........ 5-6 PERIODIC MAINTENANCE AND Accelerator pedal ......... 5-7 ADJUSTMENT .........8-1 Seat belts ..........5-7 Owner’s manual and tool kit....8-2 Passenger handhold ......5-7 Periodic maintenance chart for the Steering ..........5-7 emission control system .....8-4 Fittings and fasteners ......5-8 General maintenance and lubrication Instruments, lights and switches..
Page 8 Checking the front and rear brake Headlight beam adjustment ....8-55 pads..........8-36 Tail/brake light bulb replacement ..8-56 Checking the parking brake pads ..8-37 Troubleshooting........8-57 Checking the brake fluid level .... 8-37 Troubleshooting charts.......8-59 Brake fluid replacement ..... 8-39 CLEANING AND STORAGE ....9-1 Checking the brake pedal ....
Page 9 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
Page 10 For Europe 3 2 10 11 6 13 15 16...
Page 11 22 23...
Page 12 YXC700E WARNING 2015 34.5 kW YAMAHA MOTOR CO.,LTD. Do not rest hands or arms on door or shoulder bolster. 769 kg 2500 SHINGAI,IWATA,JAPAN B85-F155A-00 To avoid Injury, keep hands and arms completely Inside the vehicle by holding the steering wheel or handhold.
Page 13 WARNING AVERTISSEMENT Keep hands, body, and other people away from pinch points when lowering bed. Do not hold the cage/frame while closing bed. YAMAHA 5B4-K7764-00 Toute partie du corps (bras, jambes, tête) se trouvant hors de l’habitacle risque d’être é...
Page 14 Poids nominal brut du véhicule (PNBV) : 1400 kg (3087 lbs) passengers, accessories, cargo, and (if applicable) maximum, y compris le poids du véhicule, du conducteur, trailer tongue weight. du passager, des accessoires, de l’équipement, et (le cas échéant) du timon. YAMAHA B85-F1696-10 YAMAHA B85-F1696-20...
Page 15 2PG-F151F-00 les repose-pieds et agripper le volant ou la poignée de maintien. Ne jamais agripper l’arceau de protection. Ne jamais tenter d’empê cher un capotage à l’aide du bras ou de la jambe. YAMAHA 1XD-K7762-10...
Page 16 (50 kgf)/110 lbf tongue weight on towing bracket. • Do not tow more than 6664 N(680 kgf)/1500 lbf rolling weight (trailer plus cargo). • Tow or pull only from hitch bracket. • Read Owner’s Manual before loading, towing, or pulling objects. YAMAHA 1XD-F151K-00...
Page 17 MAX 7.3 INCH capotage ou autre accident. • Attacher solidement le (185MM) chargement afin de l’immobiliser. YAMAHA 5UG-F151J-00 • Ne jamais dépasser le poids en flèche de 490 N(50 kgf)/110 lbf du dispositif d’attelage. • Ne pas remorquer une...
Page 18 Pieds Sur le plancher ou les repose-pieds, prêts à encaisser le choc; portière fermée. Any part of your Any part of your YAMAHA 2PG-F1558-10 body (arms, legs, body (arms, legs, or head) outside of or head) outside of...
Page 19 R e ad T i p s G u i d e fo r t h e Re cr ea t i o n a l O f f- Hi g hway Ve h i cl e Dr i ve r Fol l ow A l l In st r uct i o n a nd Wa r n i n g s YAMAHA 2PG-F1568-00 B e P r e p a r e d A d j u s t , l o ck a n d n eve r r e m o ve h a n d h o l d .
Page 20 à plat sur le plancher et qu’ils sont assis le dos contre le dossier du siège. encaisser le choc; portière fermée. • Demeurer entièrement dans l’habitacle du véhicule. YAMAHA 1XD-F1558-10 Conduire de façon responsable Prévenir la perte de contrôle ou les roulades : •...
Page 21 – Éviter les pentes et les terrains accidentés. Lire le Manuel du propriétaire avant de charger le véhicule, • Read Owner’s Manual before loading, towing, or pulling de tirer ou de remorquer une charge. objects. YAMAHA 2PG-F4897-11 YAMAHA 2PG-F4897-01 1-13...
Page 22 For Oceania 1-14...
Page 23 1-15...
Page 24 To avoid Injury, keep hands and arms completely when lowering bed. Do not hold Inside the vehicle by holding the steering wheel or handhold. the cage/frame while closing bed. YAMAHA 1XD-K8483-00 YAMAHA 5B4-K7764-00 1HP-F2259-21 1-16...
Page 25 (if applicable) trailer tongue weight. Do not exceed maximum vehicle load. Gross Vehicle Weight Rating: 1400 kg (3087 lbs) maximum including vehicle, weight of operator, passengers, accessories, cargo, and (if applicable) trailer tongue weight. YAMAHA B85-F1696-10 1-17...
Page 26 MAX 7.3 INCH accidents. • Secure load to prevent it (185MM) from shifting. YAMAHA 5UG-F151J-00 • Never load more than 490 N (50 kgf)/110 lbf tongue weight on towing bracket. • Do not tow more than...
Page 27 Hands Inside vehicle and holding the handhold. On floor or footrests, Feet ready to brace, and door closed. Any part of your Any part of your YAMAHA 2PG-F1558-00 body (arms, legs, body (arms, legs, or head) outside of or head) outside of...
Page 28 Re a d T i p s G ui d e fo r th e R e cre a ti o na l O ff -H i g h way Veh i cl e D r ive r Fo l l ow Al l I n str u cti o n a n d Wa r n i ng s YAMAHA 2PG-F1568-00 B e P r e p a r e d A d j u s t , l o ck a n d n eve r r e m o ve h a n d h o l d .
Page 29 Feet On floor or footrests, other accidents. ready to brace, and door closed. YAMAHA 1XD-F1558-00 Maximum Load in Cargo Bed: 600 lbs (272 kg) Maximum Vehicle Load: 1309 lbs (594 kg) • Load or trailer may affect handling and stability.
Page 30 EBU33180 Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Yamaha Viking VI. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 7 before operating your Yamaha Viking VI.
Page 31 DRIVER UNDER • This vehicle is designed to carry the driver and five passengers. Never carry passengers in the cargo bed. • The driver and passengers should wear seat belts properly. • The driver and passengers must be able to put both feet flat on the floorboard while seated upright with their backs against the backrests.
Page 32  Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be thrown forward and strike occupants. While using your Yamaha Viking VI  Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel.
Page 33  Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, including rollovers. The Viking VI has higher ground clearance and other features to handle rug- ged terrain, and, as a result, can overturn in situations where some other vehicles may not. ...
Page 34  If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: • Brace yourself by pressing your feet firmly on the floorboard and keep a firm grip on the steering wheel or passenger handhold.
Page 35 Many companies with no connection to Yamaha manufacture parts and accessories or offer oth- er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
Page 36 Aftermarket parts, accessories, and modifications While you may find aftermarket products similar in design and quality to genuine Yamaha Acces- sories, recognize that some aftermarket accessories or modifications are not suitable because of potential safety hazards to you or others. Installing aftermarket products or having other mod- ifications performed to your Viking VI that change any of the vehicle’s design or operation char-...
Page 37 EBU31170 DESCRIPTION EBU31180 Left view 12 11 1. Radiator cap 11.Spark plug 2. Brake fluid reservoir 12.Cargo bed release lever 3. Driver seat 13.Door 4. Shoulder bolster 14.Storage compartment 5. Driver seat belt 15.Front shock absorber assembly 6. Air filter 7.
Page 38 EBU31190 Right view 5 6 7 1. Tail/brake light 2. Engine oil dipstick 3. Passenger seat belt 4. Passenger seat 5. Battery 6. Fuses 7. Headlight 8. Coolant reservoir 9. Storage compartment 10.Fuel tank cap 11.Oil filter cartridge...
Page 39 EBU31200 Controls and instruments 11 10 1. Light switch 13.Front passenger handhold 2. On-Command drive knob 14.Glove compartment 3. Steering wheel 15.Auxiliary DC jack 4. Main switch 16.Storage compartment 5. Parking brake lever 6. Helmet indicator light 7. Seat belt indicator light 8.
Page 40 1. Rear passenger handhold 2. Auxiliary DC jack The vehicle you have purchased may differ slightly from those shown in the figures of this man- ual.
Page 41 EBU31212 EBU31230 INSTRUMENT AND CONTROL “ ” (on): FUNCTIONS All electrical circuits are supplied with power. The key cannot be removed. EBU31220 Main switch The helmet indicator light comes on and stays on while the key is turned to “ ”...
Page 42 EBU31261 Indicator lights and warning lights 1. Helmet indicator light “ ” 2. Seat belt indicator light “ ” 1. On-Command differential gear lock indicator light “DIFF. EBU31270 LOCK” Low-range indicator light “L” 2. Low-range indicator light “L” This indicator light comes on when the drive 3.
Page 43 The On-Command differential gear lock EBU31290 Neutral indicator light “N” indicator “ ” and the On-Command differen- This indicator light comes on when the drive tial gear lock indicator light “DIFF. LOCK” select lever is in the “N” position. come on when the On-Command drive knob “2WD/4WD/DIFF LOCK”...
Page 44 When this occurs, be checked by turning the key to “ ” (on). If have a Yamaha dealer check the self-diagno- the warning light does not come on initially sis system. (See page 4-10 for an explanation when the key is turned to “...
Page 45 If the steering load is too heavy (i.e., exces- the indicator light remains on after the driver sive steering use when the Viking VI is travel- seat belt is properly latched, have a Yamaha ing at a slow speed), the power assist is dealer check the electrical circuit.
Page 46  a clock EBU31380 Multi-function meter unit  an hour meter (which shows the total time the engine has been running)  a voltage display (which shows the battery voltage)  a fuel meter  a self-diagnosis device Odometer and tripmeter modes 1.
Page 47 Pushing the “SELECT” button switches the Clock, hour meter and voltage display display between the odometer mode “ODO” modes and the tripmeter modes “TRIP A” and “TRIP B” in the following order: ODO → TRIP A → TRIP B → ODO To reset a tripmeter, select it by pushing the “SELECT”...
Page 48 To set the clock Voltage display mode 1. Set the display to the clock mode. 2. Push the “SELECT” button and “RESET” button together for at least three sec- onds. 3. When the hour digits start flashing, push the “RESET” button to set the hours. 4.
Page 49 (empty) as the fuel level decreases. When the charging circuit or the battery may be “E” segment disappears and the fuel level faulty. If this occurs, have a Yamaha dealer warning indicator flashes, refuel as soon as check or repair the vehicle.
Page 50 Set the switch to “ ” to turn on the low code, note the code number, and then have a beam and the taillights. Yamaha dealer check the vehicle. Set the switch to “ ” to turn on the high beam and the taillights.
Page 51 EBU31400 Set the switch to “ ” to turn off the head- On-Command drive knob lights and taillights. “2WD/4WD/DIFF LOCK” ECB02060 NOTICE Do not use the headlights with the engine turned off for an extended period of time. The battery may discharge to the point that the starter motor will not operate properly.
Page 52  “DIFF LOCK” (four-wheel drive with the dif- EBU31410 Accelerator pedal ferential gear locked): Power is supplied to Press the accelerator pedal down to increase the rear and front wheels with the differen- engine speed. Spring tension returns the ped- tial gear locked.
Page 53 1. Brake pedal 1. Parking brake lever 2. Release button EBU34750 Parking brake lever The parking brake lever is located at the right  Spring tension helps return the lever to the side of the steering wheel. Setting the parking released position.
Page 54 EBU31440 EBU31450 Drive select lever Fuel tank cap The drive select lever is used to shift the vehi- cle into the low, high, neutral, and reverse po- sitions. (Refer to page 6-3 for the drive select lever operation.) 1. Fuel tank cap To open Remove the fuel tank cap by turning it coun- terclockwise.
Page 55 Rear door EBU31460 Doors To open a door, pull the latch outward. To close a door, push or pull the door inward un- til it is securely latched. Be sure the door is SECURELY LATCHED AFTER CLOSING IT. Front door 1.
Page 56 1. Driver seat cushion EBU31480 2. Passenger seat cushion Adjusting the driver seat position To install a seat cushion, insert the projec- The driver seat can be adjusted to one of tions on the rear of the seat cushion under the three positions to suit the driver’s preference.
Page 57 Adjust the driver seat position as follows. 1. Remove the driver seat cushion. (See the previous section “Seats”.) 2. Remove the bolts. 4. Install the bolts, and then tighten the bolts to the specified torque. Tightening torque: Driver seat bolt: 1.
Page 58 Front seat belts EBU31501 Glove compartment This vehicle is equipped with a glove com- partment. When storing any documents in the glove compartment, be sure to wrap them in a plas- tic bag so that they will not get wet. When washing the vehicle, be careful not to let any water enter the glove compartment.
Page 59 1. Unlock. 1. Storage compartment 2. Open. EBU31512 Storage compartments The storage compartments are located under the multi-function meter, under the driver seat, under the front passenger seats, and under the rear right passenger seat. To ac- cess an under-seat storage compartment, re- move the seat cushion (see page 4-15).
Page 60 To use the front center storage compartment, remove the storage compartment cover. WARNING! Fuel vapors can be a fire or ex- plosion hazard. To avoid injury or death, never store fuel or flammable liquids in this NOTICE: Do storage compartment. [EWB03230] not exceed the specified maximum load limit for this storage compartment.
Page 61 1. Storage compartment cover 1. Front center storage compartment 2. Pull up. 2. Drain plug The front center storage compartment is EBU31520 Cup holders equipped with a drain plug. If any water col- Be sure to tightly close the cap of any plastic lects in the storage compartment, remove the bottle before placing it in a cup holder.
Page 62 ers may be thrown about and break, and Rear cup holders possibly injure people in the vehicle dur- ing sudden braking or an accident.  Do not place any other items than seal- able plastic containers in the cup hold- ers;...
Page 63 Opening and closing the tailgate 1. Tailgate 2. Cargo hook 1. Tailgate 3. Cargo bed 2. Latch ECB02100 Maximum load limit: 272.0 kg (600 lb) NOTICE The tailgate is not designed to hold heavy For additional loading information, see page loads when open.
Page 64 To close To lower Lift the tailgate to the original position, and With hands and fingers clear of pinch points, then hook the latches. lower the cargo bed slowly to its original po- sition and be sure it is locked into place. Lifting and lowering the cargo bed WARNING! Keep hands, body, and other people away from pinch points when low-...
Page 65 Trailer towing equipment the multi-function meter, and the other is lo- can be obtained at a Yamaha dealer. (See cated in front of the rear right passenger seat. page 6-7 for precaution information.) The auxiliary DC jacks can be used for suit- able work lights, radios, etc.
Page 66 ECB02110 NOTICE  The combined load of the accessories connected to the front and rear auxiliary DC jacks must never exceed the stated maximum capacity. Exceeding the maxi- mum capacity may overload the circuit and cause the fuse to blow. ...
Page 67 Maximum rated capacity for the auxiliary DC jack: DC 12 V, 10 A (120 W) 5. Turn the accessory on. 6. When the auxiliary DC jack is not being used, cover it with the cap. 4-27...
Page 68 Do not operate the vehicle if you find any problem. If a problem can- not be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
Page 69 ITEM ROUTINE PAGE • Check coolant level in reservoir. Coolant 5-6, 8-20 • Fill with coolant if necessary. Final gear oil/Differen- • Check for leakage. 5-6, 5-6, 8-16, 8-18 tial gear oil Accelerator pedal • Check for proper accelerator pedal operation. Seat belts •...
Page 70 Apply the brakes firmly for one minute. If there  Check that there is no free play in the brake is any leakage, have the vehicle inspected by pedal. If there is free play, have a Yamaha a Yamaha dealer. dealer check the brake system. (See page 8-39.)
Page 71 Your Yamaha engine has been designed to lights of water heaters and clothes dry- use regular unleaded gasoline with a research ers.
Page 72 If you carry a portable fuel container in the  In order to prevent clutch slippage (since bed of your Yamaha Viking VI, be sure to se- the engine oil also lubricates the clutch), cure it with the cap tightened before driving do not mix any chemical additives.
Page 73 EBU31760 EBU31770 Coolant Final gear oil Check the coolant level in the coolant reser- Make sure the final gear oil is at the specified voir when the engine is cold (the coolant level level. Add oil as necessary. (See page 8-16 will vary with engine temperature).
Page 74 It must operate smoothly and made as soon as possible. spring back to the idle position fully when re- leased. Have a Yamaha dealer repair as nec- EBU31810 Passenger handhold essary for proper operation.
Page 75 Tire and fasteners before a ride. Take the vehicle pressures must be equal on both sides. to a Yamaha dealer or refer to the Service WARNING! Operation of this vehicle with Manual for correct tightening torque.
Page 76 Recommended tire pressure: Vehicle load: 0 kg – maximum (0 lb – maximum) Front: 145.0 kPa (1.450 kgf/cm², 21.0 psi) Rear: 165.0 kPa (1.650 kgf/cm², 24.0 psi) Minimum tire pressure: Vehicle load: 0 kg – maximum (0 lb – maximum) Front: 1.
Page 77 1. Tire wear limit 5-10...
Page 78 If any abnormality is noticed EBU31890 during this period, consult a Yamaha dealer. Engine break-in There is never a more important period in the 0–10 hours:...
Page 79 If the neutral indi- cator light does not come on, ask a After break-in: Yamaha dealer to inspect the electric The vehicle may now be operated normally. circuit.  The engine can be started in any gear if...
Page 80 2. Apply the brake pedal, then shift by mov- Do not turn the key to the “ ” (start) position ing the drive select lever along the shift with the engine running; otherwise, damage guide. Make sure that the drive select le- to the electric starter may result.
Page 81 5. Check behind the vehicle for people or light should be on. If the light does not obstacles, and then release the brake come on, ask a Yamaha dealer to in- pedal. spect the reverse indicator light electri- 6. Press the accelerator pedal gradually and cal circuit.
Page 82 EBU31921 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF LOCK”). For example, the vehicle requires more effort to turn in “DIFF LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
Page 83  When the knob is set to “DIFF LOCK” or “4WD”, the differential gear lock indicator and indica- tor light will flash until the differential gear is completely locked or unlocked.  When the indicator and indicator light are flashing, turning the steering wheel back and forth will help the differential gear lock to engage or disengage.
Page 84  Do not exceed the Maximum Loading EBU31930 Parking Limits for the vehicle (see “MAXIMUM When parking, stop the engine and shift the LOADING LIMIT” in this section and ve- drive select lever into the neutral position. Ap- hicle labeling). ply the parking brake to help prevent the ve- ...
Page 85 Choose a trailer hitch drawbar designed for Operating when loaded with cargo or tow- use with a 5 cm (2 in) receiver. (See page 4-25 ing a trailer for more information.) Drive more slowly than you would without a load. The more weight you carry, the slower You can measure tongue weight with a bath- you should go.
Page 86 Pulling something other than a trailer Yamaha recommends that loads be trans- ported in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.
Page 87 EBU31950 EBU33210 KNOW YOUR VEHICLE BASIC GUIDE FOR SAFE USE This off-road vehicle will handle and maneuver differently from cars, ATVs, go-carts, golf-cars EBU31960 and grounds-keeping vehicles. The Viking VI As a Viking VI owner you are responsible for has higher ground clearance and other fea- the safe and proper operation of this vehicle.
Page 88  The driver must be able to place both feet has many features, including a protective structure and seat belts, to help protect occu- flat on the floorboard while seated upright pants, but the best way to avoid injuries is to with his/her back against the backrest.
Page 89 Passenger requirements Occupant protection system This vehicle is designed for the operator and EWB03350 WARNING five passengers. Allowing passengers to ride Do not make changes to the occupant pro- improperly can lead to serious injury or death. tection system. If you install aftermarket As the operator, you are responsible for your products or have your vehicle modified, passengers.
Page 90 1. Seat belt 1. Rear passenger handhold 2. Shoulder bolster The Viking VI comes with a variety of features 3. Door to help reduce the risk of driver and passen- 4. Front passenger handhold ger injury. These features work together, and when properly used, these features will help protect the occupants in the event of an acci- dent.
Page 91  Be sure that each occupant’s seat belt of injury in accidents. The protective structure will not protect occupants in all rollovers or latch plate is inserted into the appropriate accidents. buckle.  Be sure the seat belt is not twisted, is close- Body parts outside of vehicle can be struck by passing objects or crushed during vehicle fitting across the hips and chest, and is...
Page 92 A crash can damage the restraint systems in Rear seat belts your vehicle. A damaged restraint system may not properly protect the person using it, resulting in serious injury or death in a crash. To help make sure your restraint systems are working properly after a crash, have them in- spected and any necessary replacements made as soon as possible.
Page 93 along its long edges in order to more eas- ily adjust its location up or down along the length of the belt. 1. Buckle 2. Latch plate 3. Release button 4. Put the lap portion of the belt low on your 3.
Page 94 6. Check if the seat belt shoulder position Doors suits the size of the driver and passen- The doors are designed to reduce the likeli- gers. hood that you will stick your leg out to stop To lower the belt, insert the belt into the the vehicle from tipping over or for any other seat belt height adjuster slot as shown.
Page 95 Passenger handhold The passenger handhold is provided to grip during operation to maintain proper position and balance. Holding onto the handhold helps to reduce the likelihood that the pas- sengers put a hand outside the vehicle if the vehicle begins to tip. The driver should make sure the passengers are holding onto the handhold with both hands before operating the vehicle.
Page 96 Adjusting the front passenger handhold posi- tion The front passenger handhold can be adjust- ed to one of three positions to suit the pas- sengers’ preference. 1. Front passenger handhold 2. Locking pin 2. Slide the handhold to the desired position and align the holes in the handhold bar with the holes in the handhold supports.
Page 97 1. Handhold bar 1. Wire loop 2. Handhold support Seat and shoulder bolsters 3. Insert the pins into the holes and secure The seats and shoulder bolsters are designed them with the wire loops. Make sure that to help keep you in the vehicle. Do not put the handhold is properly secured before your hand or arm on or outside of the shoul- riding.
Page 98 Floorboard The floorboard allows you to brace your feet, which helps you keep your body in the vehicle in the event of an accident or rollover. Keep your feet on the floorboard during operation. Steering wheel Keep both hands on the steering wheel. Do not hold the steering wheel with your thumbs inside the rim.
Page 99 EBU33352 LEARNING TO OPERATE YOUR VEHI- CORRECT GRIP EXAMPLE Personal protective equipment INCORRECT GRIP EXAMPLE 1. Approved motorcycle helmet 2. Eye protection 3. Long-sleeved shirt or jacket 4. Gloves 5. Long pants 6. Over-the-ankle boots The driver and passengers should wear the following to reduce risk of injury in an acci- dent: 7-13...
Page 100  Approved motorcycle helmet that fits prop- Practice for new Yamaha Viking VI users erly You should become familiar with the perfor-  Eye protection (goggles, helmet face shield, mance characteristics of the vehicle in a lar- or protective eyewear) ge, flat area that is free of obstacles and other ...
Page 101 Getting ready to ride Perform the Pre-Operation Checks on page 5-1. Follow the instructions starting on page 6-2 to start the engine. Turning Use care in turns – turning the steering wheel too far or too fast can result in loss of control or a rollover.
Page 102 If you think or feel that the vehicle may tip or Avoid higher speeds and sudden or hard ac- roll, keep your body completely inside the celeration until you are thoroughly familiar protective structure of the vehicle: with the operation of your vehicle. Avoid sud- ...
Page 103 the vehicle down after you take your foot off Parking on a flat area the accelerator. Engine braking is more no- When parking on a flat area, stop the engine ticeable in four-wheel drive. Application of ve- and shift the drive select lever into the neutral hicle brakes provides additional stopping position.
Page 104 5. Block the front and rear wheels with Your Yamaha Viking VI has higher ground rocks or other objects. clearance and other features to handle rug- ged terrain, and as a result, can overturn in Loading situations where some vehicles may not.
Page 105 to see far enough ahead of you. Use common side of a hill, which increases your risk of roll- sense and remember that some hills are too over. Practice first on gentle slopes before at- steep for you to climb or descend. Use proper tempting steeper hills.
Page 106 slow your descent. Release the brake and be- If you are sliding or skidding, try to steer in the gin to coast down the hill. Use engine braking direction the vehicle is sliding, to regain con- as much as possible, gently applying the trol.
Page 107 Pavement Wet brakes may have reduced effectiveness. This vehicle is designed for off-road use only. After leaving the water, test your brakes. If Avoid paved surfaces. Turn gradually and go necessary, apply the brakes several times to slowly if you must drive on pavement. let friction dry out the linings.
Page 108 If you feel the vehicle begin to slide sideways muffler or exhaust pipe, or next to other hot or the back wheels slide during a turn, steer parts. Check under the vehicle after operating into the direction of the slide if possible, to re- in areas where combustible materials may gain directional control.
Page 109 If there is any question about your ability to maneuver safely over the obstacle, you should turn around if the ground is flat and you have the room or back up until you find a less difficult path. 7-23...
Page 110 To avoid death during service or while using the ve- possible burns, let brake components cool hicle. If you are not familiar with vehicle before touching them. service, have a Yamaha dealer perform the service.
Page 111 EBU32020 Owner’s manual and tool kit You are recommended to put this owner’s manual in the vinyl bag and always carry it in the glove compartment as shown. Put the owner’s tool kit and tire pressure gauge under the rear right passenger seat. 1.
Page 112 If you do not have a torque wrench available during a service operation requiring one, take your vehicle to a Yamaha dealer to check the torque settings and adjust them as neces- sary.
Page 113 However, keep in mind that if the vehicle isn’t used for a long period of time, the month maintenance intervals should still be followed.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
Page 114 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours • Check for leakage. √ √ √ Exhaust system • Tighten if necessary. • Replace gasket(s) if necessary. √ √ √...
Page 115 EBU32112 General maintenance and lubrication chart INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours • Check coolant leakage. √ √ √ √ √ • Repair if necessary. Cooling system •...
Page 116 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours • Check operation and free play/brake pad wear. √ √ √ √ √ Parking brake • Correct if necessary. Replace pads if worn to the limit.
Page 117 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours Rear upper and √ √ √ 17 * lower knuckle • Lubricate with lithium-soap-based grease. pivots Drive shaft uni- √ √...
Page 118 • Every two years replace the internal components of the brake master cylinder and calipers, and change the brake fluid. • Replace the brake hoses every four years and if cracked or damaged.
Page 119 EBU32340 Hood To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Tab 2. Hood lock 2. Remove the hood. 1. Tab 1. Hood 8-10...
Page 120 To install EBU32350 Right rear panel 1. Insert the projections on the hood into the slots in the front grill, and then place the To remove hood in the original position. 1. Lift the cargo bed up. (See page 4-24 for cargo bed lifting and lowering proce- dures.) 2.
Page 121 To install 3. Lift the cargo bed up. (See page 4-24 for 1. Lift the cargo bed up. cargo bed lifting and lowering proce- 2. Place the panel in the original position, dures.) and then install the bolts and the quick 4.
Page 122 To change the engine oil (with or without oil filter cartridge replacement) 1. Park the vehicle on a level surface. 2. Start the engine, warm it up for several minutes, and then turn it off. 3. Lift the cargo bed up. (See page 4-24 for cargo bed lifting and lowering proce- dures.) 4.
Page 123 An oil filter wrench is available from a Yamaha dealer. 1. Engine oil drain bolt 2. Gasket Skip steps 7–9 if the oil filter cartridge is not 1. Oil filter cartridge being replaced. 2. Oil filter wrench 7. Remove the oil filter cartridge with an oil 8.
Page 124 1. O-ring 1. Torque wrench 9. Install the new oil filter cartridge with an 10. Install the engine oil drain bolt and its new oil filter wrench, and then tighten it to the gasket, and then tighten the bolt to the specified torque with a torque wrench.
Page 125  Make sure that no foreign material en- Recommended engine oil: ters the crankcase. See page 10-1. Oil quantity: 12. Start the engine, and then let it idle for Without oil filter cartridge replacement: several minutes while checking it for oil 2.20 L (2.33 US qt, 1.94 Imp.qt) leakage.
Page 126 Tightening torque: Final gear oil filler bolt: 22 Nm (2.2 m·kgf, 16 ft·lbf) Changing the final gear oil 1. Park the vehicle on a level surface. 2. Place an oil pan under the final gear case to collect the used oil. 3.
Page 127 4. Install the drain bolt and its new gasket, Tightening torque: and then tighten the bolt to the specified Final gear oil filler bolt: torque. 22 Nm (2.2 m·kgf, 16 ft·lbf) 8. Check for oil leakage. If oil leakage is Tightening torque: Final gear oil drain bolt: found, check for the cause.
Page 128 Tightening torque: Differential gear oil filler bolt: 23 Nm (2.3 m·kgf, 17 ft·lbf) Changing the differential gear oil 1. Park the vehicle on a level surface. 2. Place an oil pan under the differential gear case to collect the used oil. 3.
Page 129 4. Install the differential gear oil drain bolt Tightening torque: and its new gasket, and then tighten the Differential gear oil filler bolt: bolt to the specified torque. 23 Nm (2.3 m·kgf, 17 ft·lbf) 8. Check for oil leakage. If oil leakage is Tightening torque: Differential gear oil drain bolt: found, check for the cause.
Page 130 Changing the coolant EWB01891 WARNING Wait for the engine and radiator to cool be- fore removing the radiator cap. You could be burned by hot fluid and steam blown out under pressure. Always place a thick rag over the cap when opening. Allow any remaining pressure to escape before com- pletely removing the cap.
Page 131 1. Radiator cap 1. Coolant drain bolt 2. Gasket 6. Remove the coolant drain bolt and its 7. Place a container under the coolant res- gasket to drain the coolant from the en- ervoir to collect the used coolant. gine and radiator. 8.
Page 132 Tightening torque: Coolant drain bolt: 10 Nm (1.0 m·kgf, 7.2 ft·lbf) 12. Connect the coolant reservoir hose. 13. Pour the recommended coolant into the radiator until it is full. 14. Pour the recommended coolant into the reservoir to the maximum level mark, and then install the reservoir cap.
Page 133 Antifreeze/water mixture ratio: Recommended antifreeze: High-quality ethylene glycol antifreeze con- taining corrosion inhibitors for aluminum engines Coolant quantity: Radiator (including all routes): 3.24 L (3.42 US qt, 2.85 Imp.qt) Coolant reservoir (up to the maximum level mark): 1. Water pump air bleed bolt 0.28 L (0.30 US qt, 0.25 Imp.qt) 16.
Page 134 1. Cylinder head air bleed bolt ant leakage. 18. When coolant begins to flow out of the bolt hole, tighten the cylinder head air If any leakage is found, have a Yamaha dealer bleed bolt to the specified torque. check the cooling system. Tightening torque: 25.
Page 135 EBU32410 Spark plug inspection Removal 1. Lift the cargo bed up. (See page 4-24 for cargo bed lifting and lowering proce- dures.) 2. Remove the spark plug cap. 1. Front axle boot 1. Spark plug cap 3. Use the spark plug wrench in the tool kit to remove the spark plug as shown.
Page 136 and erode. If electrode erosion becomes ex- cessive, or if carbon and other deposits are excessive, you should replace the spark plug with the specified plug. Specified spark plug: NGK/CPR7EA-9 Measure the spark plug gap with a wire thick- ness gauge and, if necessary, adjust the gap to specification.
Page 137 EBU34821 Spark plug gap: Cleaning the air filter element 0.8–0.9 mm (0.031–0.035 in) The air filter element should be cleaned every 20–40 hours. It should be cleaned and lubri- Installation cated more often if the vehicle is operated in 1. Clean the surface of the spark plug gas- extremely dusty areas.
Page 138 1. Remove the rear center passenger seat cushion. (See page 4-15 for seat cushion removal and installation procedures.) 2. Lift up the rubber damper, and then re- move the rear center passenger seat by removing the bolts. 1. Quick fastener screw 2.
Page 139 6. While pushing the projections on the air filter frame inward, remove the air filter el- ement holder. 1. Air filter case cover holder 2. Air filter case cover 5. Remove the air filter element. 1. Air filter element holder 2.
Page 140 1. Air filter element holder 10. Wash the sponge material in warm soapy 2. Sponge material water to remove remaining solvent, then 3. Air filter frame rinse thoroughly with plain warm water. 8. Wash the sponge material gently but 11. Squeeze excess water out of the sponge thoroughly in parts cleaning solvent.
Page 141 13. Thoroughly apply Yamaha foam air filter 18. Install cover A, then cover B in their orig- oil or other quality liquid foam air filter oil inal positions by installing the quick fas- (not spray type) to the sponge material.
Page 142 EBU32430 Cleaning the air filter case/duct check hose There is a check hose at the bottom of the air filter case under the cargo bed and a check hose at the bottom of the air duct. The air duct check hose can be accessed under the vehicle.
Page 143 If water drains from the V-belt case after re- haust system. moving the drain plug, have a Yamaha dealer inspect the vehicle, as the water may affect 1. Remove the tailpipe bolts.
Page 144 1. Tailpipe bolt 1. Gasket 2. Spark arrester 2. Remove the tailpipe by pulling it out of 3. Tailpipe the muffler, and then remove the gasket. 4. Install the gasket, and then insert the tail- 3. Tap the tailpipe lightly, and then use a pipe into the muffler and align the bolt wire brush to remove any carbon depos- holes.
Page 145 Yamaha service technician. pad has worn to the point that the wear indi- cator grooves have almost disappeared, have EBU32470 a Yamaha dealer replace the brake pads as a Brakes set. Replacement of brake components requires The wheels need to be removed to check the professional knowledge.
Page 146 If a brake pad has worn to the level. Replenish the brake fluid if necessary. point that the wear indicator groove has al- most disappeared, have a Yamaha dealer re- place the brake pads as a set. 8-37...
Page 147  Clean the filler cap before removing. Use only DOT 4 brake fluid from a sealed container.  Use only the specified brake fluid; other- wise, the rubber seals may deteriorate, causing leakage.  Refill with the same type of brake fluid. Adding a brake fluid other than DOT 4 may result in a harmful chemical reac- tion.
Page 148 EBU32530 Parking brake lever free play adjust- Checking the brake pedal ment Have a Yamaha dealer check the brakes at Periodically check the parking brake lever the intervals specified in the periodic mainte- free play and adjust it if necessary.
Page 149 1. Shift the drive select lever into low gear “L”. 2. Check the parking brake lever free play. The maximum free play is equal to one click of the parking brake lever. If neces- sary, adjust the free play as follows. 1.
Page 150 (a). To make the brake light come on later, turn the adjusting nut in direction (b). Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: Yamaha cable lubricant or other suitable...
Page 151 Checking the stabilizer bushes with a grease gun. The stabilizer bushes must be checked for cracks or damage at the intervals specified in the periodic maintenance and lubrication chart. Have a Yamaha dealer replace the stabilizer bushes if necessary. 8-42...
Page 152 EBU32610 Recommended lubricant: Wheel removal Lithium-soap-based grease 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable EBU32600 Steering shaft lubrication stand under the frame. Lubricate the pivot points. 3. Remove the nuts from the wheel. 4. Remove the wheel. Recommended lubricant: Lithium-soap-based grease 8-43...
Page 153 Always use the same size and type of tires Size: recommended in this owner’s manual. The 25 x 8-12NHS tires that came with your Yamaha Viking VI Manufacturer/model: were designed to match the performance ca- MAXXIS/MU09 pabilities and to provide the best combination Rear tire: of handling, braking, and comfort.
Page 154 Wheel installation WARNING 1. Install the wheel and the nuts. Do not reverse the rims on your Yamaha Viking VI to widen the track width. Install- ing wheels improperly increases the risk of Tapered nuts are used for both the front and wheel failure and accidents.
Page 155 EWB03410 EWB03420 WARNING WARNING Avoid battery contact with skin, eyes, or Batteries may produce explosive gases. clothing. Shield eyes when working near Ventilate when charging or using in a batteries. Keep out of reach of children. closed space. Keep batteries away from You could be poisoned or severely burned sparks, flames, cigarettes, or other sourc- by the sulfuric acid in battery electrolyte.
Page 156 To charge the battery ing their bolt. NOTICE: When removing Have a Yamaha dealer charge the battery as the battery, the main switch must be soon as possible if it seems to have dis- off, and the negative lead must be dis- charged.
Page 157 To install the battery ECB00932 NOTICE To charge a VRLA (Valve Regulated Lead Be sure the battery is fully charged. Acid) battery, a special (constant-voltage) battery charger is required. Using a con- 1. Place the battery in its compartment. ventional battery charger will damage the 2.
Page 158 3. Hook the battery bands. 1. Turn the key to “ ” (off). 4. Install the air intake duct panel by install- 2. Remove the hood. (See page 8-10 for ing the quick fastener screws. hood removal and installation proce- 5.
Page 159 4. Connect the negative lead of the jumper disconnect the positive lead of the jump- cable to the negative terminal of the er cable from the charged battery and the charged battery and the other end of the battery in the vehicle. negative lead to an unpainted metal sur- 7.
Page 160 1 2 3 4 5 6 1. Fuse box 1. Backup fuse “BACK UP” (for clock) 2. Main fuse 2. Ignition fuse “IGNITION” 3. EPS fuse 3. Four-wheel-drive motor fuse “DIFF” 4. Fuel injection system fuse 4. Auxiliary DC jack fuse “TERMINAL” 5.
Page 161 ECB00641 Specified fuses: NOTICE Main fuse: To prevent accidental short-circuiting, 40.0 A turn off the main switch when checking or Fuel injection system fuse: replacing a fuse. 10.0 A Headlight fuse: 2. Remove the hood. (See page 8-10 for 15.0 A hood removal and installation proce- Ignition fuse: 10.0 A...
Page 162 ” (on) and turn on the ing it off. electrical circuit in question to check if the device operates. If the fuse blows again immediately, have a Yamaha dealer check the electrical system. 5. Install the hood. EBU32670 Replacing a headlight bulb If a headlight bulb burns out, replace it as fol- lows.
Page 163 5. Wait for the headlight bulb to cool before touching or removing it. Remove the burnt-out bulb by pulling it out. 6. Place a new headlight bulb into position, and then secure it with the bulb holder. NOTICE: Do not touch the glass part of the headlight bulb to keep it free from oil, otherwise the transparency of the glass, the luminosity of the bulb, and...
Page 164 EBU32681 Headlight beam adjustment ECB00691 NOTICE It is advisable to have a Yamaha dealer make this adjustment. To raise the beam, turn the headlight beam adjusting screw in direction (a). To lower the beam, turn the headlight beam adjusting screw in direction (b).
Page 165 EBU32690 Tail/brake light bulb replacement If a tail/brake light bulb burns out, replace it as follows: 1. Remove panel A (if replacing the left tail/brake light bulb) or panel B (if replac- ing the right tail/brake light bulb) by re- moving the quick fastener screws, nuts and bolts.
Page 166 If your vehicle 5. Install the bulb holder (together with the requires any repair, take it to a Yamaha deal- bulb) by turning it clockwise. 6. Install the panel. 8-57...
Page 167 Use only genuine Yamaha parts on your vehicle. Imita- tion parts may look like Yamaha parts, but they are often inferior. Consequently, they have a shorter service life and can lead to ex- pensive repair bills.
Page 168 Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
Page 169 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. If it is difficult to get the recommended coolant, tap water can be used temporarily, provided that it is changed to the recommended coolant as soon as possible.
Page 170 brakes may have reduced stopping EBU32720 CLEANING AND STORAGE ability, increasing the chance of an ac- NOTICE: Excessive wa- cident. EBU32730 [EWB03470] Cleaning ter pressure may cause water seepage Frequent, thorough cleaning of your vehicle and deterioration of wheel bearings, will not only enhance its appearance but will brakes, transmission seals and electri- improve its general performance and extend...
Page 171 1. Fill the fuel tank with fresh fuel and add cloth. the specified amount of Yamaha Fuel 6. Clean the seats with a vinyl upholstery Stabilizer and Conditioner or equivalent cleaner to keep the covers pliable and product.
Page 172 [less than 0 °C (30 °F) or more than 30 °C (90 °F)]. Use of fuel stabilizer and conditioner elimi- nates the need to drain the fuel system. Con- sult a Yamaha dealer if the fuel system needs to be drained.
Page 173 EBU32750 SPECIFICATIONS Dimensions: Cylinder arrangement: Single cylinder Overall length: Displacement: 3900 mm (153.5 in) 686 cm³ Overall width: Bore × stroke: 1570 mm (61.8 in) 102.0 × 84.0 mm (4.02 × 3.31 in) Overall height: Compression ratio: 1945 mm (76.6 in) 10.0 : 1 Wheelbase: Starting system:...
Page 174 Type: Quantity: SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W- 0.18 L (0.19 US qt, 0.16 Imp.qt) Coolant quantity: Coolant reservoir (up to the maximum level mark): 130 ˚F 0.28 L (0.30 US qt, 0.25 Imp.qt) Radiator (including all routes): SAE 5W-30 3.24 L (3.42 US qt, 2.85 Imp.qt) Air filter:...
Page 175 Secondary reduction ratio: Manufacturer/model: 41/21 × 17/12 × 33/9 (10.142) MAXXIS/MU10 Transmission type: Loading: V-belt automatic Maximum loading limit: Operation: 594.0 kg (1309 lb) Right hand operation (Total weight of operator, passengers, cargo, accessories, Reverse gear: and tongue) 23/14 × 28/23 (2.000) Tire air pressure (measured on cold tires): Low range: Recommended:...
Page 176 Rim size: Electrical system: 12 x 7.5AT Ignition system: Front brake: Type: Charging system: Disc brake AC magneto Operation: Battery: Unified brake Model: Specified brake fluid: U1-H11L DOT 4 Voltage, capacity: Rear brake: 12 V, 28.0 Ah Type: Headlight: Disc brake Bulb type: Operation: Halogen bulb...
Page 177 High-range indicator light: EBU33220 Low-range indicator light: For Europe only The figures quoted are emission levels and Differential gear lock indicator light: are not necessarily safe working levels. Whilst EPS warning light: there is a correlation between the emission and exposure levels, this cannot be used reli- Helmet/Seat belt indicator light: 14 V, 0.85 W ×...
Page 178 Record the vehicle identification number and model label information in the spaces provid- ed for assistance when ordering spare parts from a Yamaha dealer or for reference, in case the vehicle is stolen. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number The vehicle identification number is used to identify your vehicle.
Page 179 1. Model label 11-2...
Page 180 INDEX Differential gear oil, Pre-operation check ...... 5-6 Doors ................4-15 Driver seat position ............4-16 Drive select lever ............4-14 Accelerator pedal ............4-12 Drive select lever operation and reverse driving .... 6-3 Accelerator pedal, Pre-operation check ......5-7 Air filter case/duct check hose, cleaning .....8-33 Engine break-in ..............
Page 181 Parking brake pads, checking ........8-37 Passenger handhold, Pre-operation check ....5-7 Identification number records ........11-1 Indicator lights and warning lights ......... 4-2 Instruments, lights and switches, Pre-operation Rear knuckle upper and lower pivot, lubrication ..8-42 check ................5-8 Reverse indicator light ...........
Page 182 Vehicle identification number ........11-1 Wheel installation ............8-45 Wheel removal .............8-43 12-3...
Page 184 Original instructions PRINTED IN USA 2015.09-0.3×1 CR...

This manual is also suitable for:

Viking 700 vi 2016 Yxc70vpxg

Yamaha VIKING VI 2016 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Yamaha VIKING VI 2016

Summary of Contents for Yamaha VIKING VI 2016

This manual is also suitable for:
