Related Manuals for PCchips M939LU

Summary of Contents for PCchips M939LU

  • Page 1 This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. The information in this document is subject to change without notice.
  • Page 2 Notice: Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certified yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pop out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1: Introduction..............1 Key Features................2 Package Contents..............5 Static Electricity Precautions...........6 Pre-Installation Inspection............6 Chapter 2: Mainboard Installation...........7 Mainboard Components ............8 I/O Ports...................8 Installing the Processor............9 Installing Memory Modules ..........10 Setting Jumper Switches............11 Install the Mainboard.............12 Connecting Optional Devices..........13 Install Other Devices .............15 Expansion Slots ..............17 Chapter 3: BIOS Setup Utility............18...

  • Page 5: Chapter 1: Introduction

    Chapter 1 Introduction This mainboard has a Socket-478 processor socket for Intel Pentium 4/Hyper Threading Technology processors with front- side bus (FSB) speeds up to 533 MHz. Hyper Threading Technology, designed to take advantage of the multitasking features in Windows XP, gives you the power to do more things at once.

  • Page 6: Key Features

    Key Features The key features of this mainboard include: Socket-478 Processor ♦ The PGA Socket 478 ♦ Supports Intel Pentium 4 series CPU with/without Hyper Threading Technology ♦ Supports up to 533 MHz Front-Side Bus Chipset There are SiS650GX/651 Northbridge and SiS962L Southbridge in this chipset in accordance with an innovative and scalable architecture with proven reliability and performance.
  • Page 7 Power Supply and Power Management ♦ ATX power supply connector ♦ Meets ACPI 1.0b and APM 1.2 requirements, keyboard power on/off ♦ Supports RTC Alarm, Wake On Modem, AC97 Wake-Up and USB Wake-Up Onboard VGA ♦ Supports AGP V2.0 Compliant ♦...
  • Page 8 ♦ One parallel port ♦ One VGA port ♦ Four back-panel USB2.0 ports and extra two USB2.0 ports (onboard USB header JUSB1) ♦ Audio jacks for microphone, line-in and line-out Hardware Monitoring ♦ Built-in hardware monitoring for CPU & System temperatures, fan speeds and mainboard voltages.

  • Page 9: Package Contents

    ♦ PC DJ is a dual-MP3 player that enables users to actually mix music right on their own personal computers. ♦ Adobe Acrobat Reader V5.0 is the software to help users read .PDF files. Dimensions ♦ Micro ATX form factor 244 x 190mm Package Contents Your mainboard package contains the following items: The mainboard...

  • Page 10: Static Electricity Precautions

    Static Electricity Precautions Components on this mainboard can be damaged by static electricity. Take the following precautions when unpacking the mainboard and installing it in a system. 1. Keep the mainboard and other components in their original static-proof packaging until you are ready to install them. 2.

  • Page 11: Chapter 2: Mainboard Installation

    Chapter 2 Mainboard Installation To install this mainboard in a system, please follow the instructions in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Verify that all jumpers or switches are set correctly Install the mainboard in a system chassis (case) Connect any extension brackets or cables to connecting headers on the mainboard...

  • Page 12: Mainboard Components

    Mainboard Components Use the diagram below to identify the major components on the mainboard. Note: Any jumpers on your mainboard not appearing in the illustration above are for testing only. I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard.

  • Page 13: Installing The Processor

    PS/2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS/2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. LPT1 Use LPT1 to connect printers or other parallel communications devices. COM1 Use the COM port to connect serial devices such as mice or fax/modems.

  • Page 14: Installing Memory Modules

    3. Push the locking lever down and hook it under the latch on the edge of socket. 4. Apply thermal grease to the top of the CPU. 5. Lower the CPU fan/heatsink unit onto the CPU and CPU socket, and then use the retention module clamps to snap the fan/heatsink into place.

  • Page 15: Setting Jumper Switches

    Installation Procedure These modules can be installed with up to 2 GB system memory. Refer to the following steps to install the memory module. 1. Push the latches on each side of the DIMM socket down. 2. Align the memory module with the socket. The DIMM sockets are keyed with notches and the DIMMs are keyed with cutouts so that they can only be installed correctly.

  • Page 16: Install The Mainboard

    Jumper JP2: Clear CMOS Memory This jumper can clear the contents of the CMOS memory. You may need to clear the CMOS memory if the settings in the Setup Utility are incorrect and prevent your mainboard from operating. To clear the CMOS memory, disconnect all the power cables from the mainboard and then move the jumper cap into the CLEAR setting for a few seconds.

  • Page 17: Connecting Optional Devices

    Connect the case switches and indicator LEDs to the SW1 header. Signal Signal HDD_LED_P FP ACPI LED HDD_LED_N FP ACPI LED RST_SW_N PW_BT_P RST_SW_P PW_BT_N RSVD_DNU Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: JUSB1 AUDIO2 EZJ1...
  • Page 18 JUSB1: Front panel USB Connector The mainboard has USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector USB3 to connect the front-mounted ports to the mainboard.

  • Page 19: Install Other Devices

    EZJ1: Easy-Watcher Interface Connector (optional) This connector is for use with EZ-Watcher interface only. The EZ- Watcher allows you to adjust the CPU frequency according to your desire. Signal Signal PCDAT PCREQ SCI# PCIRST# HDDN CDROM RSVD Install Other Devices Install and connect other devices in the system as steps below.
  • Page 20 IDE Devices IDE devices include hard disk drives, high-density diskette drives, and CD-ROM or DVD-ROM drives, among others. The mainboard ships with an IDE cable that can support one or two IDE devices. If you connect two devices to a single cable, you must configure one of the drives as Master and one of the drives as Slave.

  • Page 21: Expansion Slots

    Signal CD IN L CD IN R Expansion Slots This mainboard has one AGP and two 32-bit PCI slots. AGP1 PCI2 PCI1 Follow the steps below to install one AGP/PCI expansion card. 1. Locate the AGP or PCI slots on the mainboard. 2.

  • Page 22: Chapter 3: Bios Setup Utility

    Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information about your computer such as the date and time, the kind of hardware installed, and various configuration settings. Your computer uses this information to initialize all the components when booting up and functions as the basis for coordination between system components.

  • Page 23: Running The Setup Utility

    Running the Setup Utility Each time your computer starts, before the operating system loads, a message appears on the screen that prompts you to “Hit <DEL> if you want to run SETUP”. When you see this message, press the Delete key and the Main menu page of the Setup Utility appears on your monitor.

  • Page 24: Standard Cmos Setup Page

    Standard CMOS Setup Page Use this page to set basic information such as the date, the time, the IDE devices, and the diskette drives. If you press the F3 key, the system will automatically detect and configure the hard disks on the IDE channels.

  • Page 25: Advanced Setup Page

    Advanced Setup Page This page sets up more advanced information in the system. Be more carful with this page. Making changes can affect the operation of your computer. AMIBIOS SETUP – ADVANCED SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved Quick Boot Enabled Auto Detect DIMM/PCI Clk...
  • Page 26 S.M.A.R.T. for Hard Enable this item if any IDE hard disks Disks support the S.M.A.R.T. (Self- Monitoring, Analysis and Reporting Technology) feature. BootUp Num-Lock This item determines if the Num Lock key is active or inactive at system start- up time. Floppy Drive Swap If you have two diskette drives installed and you enable this item, drive A...
  • Page 27 Graphic Win Size This item defines the size of aperture if you use a graphic adapter. DRAM CAS# Latency This item determines the operation of DRAM memory CAS (column address strobe). It is recommended that you leave this item at the default value. The 3T setting requires faster memory that specifically supports this mode.

  • Page 28: Power Management Setup Page

    Power Management Setup Page This page sets some of the parameters for system power management operation. AMIBIOS SETUP – POWER MANAGEMENT SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved ACPI Aware O/S Power Management Enabled Suspend Time out Disabled Hard Disk Time out Disabled Resume On RTC Alarm...

  • Page 29: Pci/Plug And Play Setup Page

    LAN/Ring Power The system can be turned off with a software command. If you enable this item, the system can automatically resume if there is an incoming call on the Modem. You must use an ATX power supply in order to use this feature.

  • Page 30: Load Optimal Settings

    Allocate IRQ to If this item is enabled, an IRQ will be PCI VGA assigned to the PCI VGA graphics system. You set this value to No to free up an IRQ. PCI IDE BusMaster This item enables or disables the DMA under DOS mode.

  • Page 31: Features Setup Page

    Features Setup Page This page sets some of the parameters for peripheral devices connected to the system. AMIBIOS SETUP – FEATURES SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved OnBoard FDC Enabled OnBoard Serial Port 3F8h/COM1 OnBoard IR Port Disabled OnBoard Parallel Port 378h...

  • Page 32: Cpu Pnp Setup Page

    Parallel Port DMA Use this item to assign a DMA channel to the parallel port. The options are 0, 1 and 3. Onboard PCI IDE Use this item to enable or disable either or both of the onboard Primary and Secondary IDE channels.

  • Page 33: Hardware Monitor Page

    CPU Type/Core These items show the type, core voltage, Voltage/Ratio/ ratio and frequency of CPU installed in your Frequency system. CPU/DRAM These items decide CPU/DRAM Speed/Frequency speed/frequency installed in your system. Hardware Monitor Page This page sets some of the parameters for the hardware monitoring function of this mainboard.

  • Page 34: Change Password

    Change Password If you highlight this item and press Enter, a dialog box appears which lets you enter a Supervisor password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password. A second dialog box asks you to retype the password for confirmation.

  • Page 35: Chapter 4: Software & Applications

    Chapter 4 Software & Applications Introduction This chapter describes the contents of the support CD-ROM that comes with the mainboard package. The support CD-ROM contains all useful software, necessary drivers and utility programs to properly run our products. More program information is available in a README file, located in the same directory as the software.

  • Page 36: Installing Support Software

    Installing Support Software 1.Insert the support CD-ROM disc in the CD-ROM drive. 2.When you insert the CD-ROM disc in the system CD-ROM drive, the CD automatically displays an Auto Setup screen. 3.The screen displays three buttons of Setup, Browse CD and Exit on the right side, and three others Setup, Application and ReadMe at the bottom.
  • Page 37 Auto-Installing under Windows 98/ME/2000/XP If you are under Windows 98/ME/2000/XP, please click the Setup button to run the software auto-installing program while the Auto Setup screen pops out after inserting the support CD-ROM: 1. The installation program loads and displays the following screen.

  • Page 38: Bundled Software Insatllation

    Installing under Windows NT or Manual Installation If you are under Windows NT, the auto-installing program doesn’t work out; or you have to do the manual installation, please follow this procedure while the Auto Setup screen pops out after inserting the support CD-ROM: 1.

  • Page 39: Appendix

    Hyper Threading CPU You must update BIOS to initiate BIOS Hyper Threading Function and use HT CPU function under WinXP Operating System; if not, please disable this option. ♦ When BIOS detects the HT CPU, it shows the “Hyper Threading Function (default Disabled)” option, which you must set Enabled if you want to test HT CPU function.
