FireplaceXtrordinair 94500975 Instructions Manual

Ho linear – interim driftwood log set
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual


Overview
The HO Linear line of gas fireplaces (3615, 4415, 6015) were recently changed to allow for mounting
hardware to be installed without templates & without removing the media tray. This change leads to
the following:
 The fireplace media tray has changed on new units to accommodate the new hardware.
 The old log hardware will not work with new units and vice-versa.
 The logs are exactly the same (new & old).
 This kit is intended to provide Driftwood logs for all HO linears, new or old. Eventually this kit
will be discontinued when all old-style fireplaces are sold & installed.
The directions below are broken into sections. You will need to determine whether you will use the
new style or old style hardware (see serial numbers under "Compatibility" below). Once you know
which style of hardware you are using, you will then need to follow the relevant directions. After the
hardware is installed you then install the logs. Log placement is the same for both old & new
hardware.
Compatibility
Use the tables below to determine which hardware should be used.
Old Style Hardware (uses templates)
3615 HO GSR2 (SN# 3213-003632 or before)
4415 HO GSR2 (SN# 3212-012114 or before)
6015 HO GSR2 (SN# 3214-007337 or before)

Table of Contents

Overview .................................................................................................................................................................................  1
Compatibility  . ..........................................................................................................................................................................  1
Packing List  . .............................................................................................................................................................................  2
10-Piece Log/Stone Set Details ...............................................................................................................................................  4
Preparing the Media Tray - 3615 New Style ..........................................................................................................................  5
Preparing the Media Tray - 4415 New Style ..........................................................................................................................  6
Preparing the Media Tray - 6015 New Style ..........................................................................................................................  7
Preparing the Media Tray - 3615, 4415, 6015 OLD Style .......................................................................................................  8
Log Installation - 3615 (New or Old Hardware) .....................................................................................................................  1 4
Log Installation - 4415 (New or Old Hardware) .....................................................................................................................  1 7
Log Installation - 6015 (New or Old Hardware) .....................................................................................................................  2 3
Crushed Glass Installation (see manual for additional details).  . .............................................................................................  2 9
Replacement Part Numbers  . ...................................................................................................................................................  3 0

Page 1 of 30
HO Linear - Interim Driftwood Log Set
Instructions sku# 94500975
- 11/13/19
17602100
New Style Hardware (no templates)
3615 HO GSR2 (SN# 3213-003633 or later)
4415 HO GSR2 (SN# 3212-012115 or later)
6015 HO GSR2 (SN# 3214-007338 or later)
© Travis Industries, Inc.
