Ellisys SerialTek Gen5 POD M.2 Assembly page 3

Gen5 POD M.2 Edition Assembly Reference
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the M.2 Device PCBA into the connector on
the DEVICE side of the POD Unit and secure in position on the Host/Device
Cable Adaptor Tray with M3 Captive Screws.
Fix M.2 Card into the connector on the M.2 Device PCBA using the M3
Unthreaded Spacer and M3 Pan Head Screw
M3 x 10mm Pan Head Screw
M.2 Card
M.2 Device PCBA
M3 Unthreaded Spacer
0004648 - R1
Page 3 of 5
M3 Captive Screw
Host/Device Cable Adaptor Tray
POD Main Unit
