Summary of Contents for DigiTech Mosaic 12 String Effect

  • Page 2: Warranty

    The consumer forfeits the bene ts of this warranty if the product’s main assembly is opened and tampered with by anyone other than a certi ed DigiTech technician or, if the product is used with AC voltages outside of the range suggested by the manufacturer.
  • Page 3 INTRODUCTION Thanks for choosing the DigiTech Mosaic 12-string e ect pedal. The Mosaic creates a lush, shimmering ® chordal e ect reminiscent of a 12-string guitar and can be used with both acoustic and electric instruments. And thanks to a true bypass design, your tone remains una ected when the e ect is bypassed.
  • Page 4 USER INTERFACE 1. Power Connector Connect the provided power adapter to this jack. Do not use any power adapter other than the one supplied. 2. Level Knob Adjusts the level of the e ect signal. 3. Tone Knob As this knob is raised, the tone becomes brighter and more enhanced. 4.

  • Page 5: Making Connections/Applying Power

    MAKING CONNECTIONS/APPLYING POWER To connect the Mosaic pedal to your rig: Turn down the ampli er’s master volume control. Make all audio connections to the Mosaic as shown below. Connect the included power supply to the POWER input connector and connect the other end to an available AC outlet.

  • Page 6: Example Settings

    EXAMPLE SETTINGS Try these settings to get started. Thickener Thickener Arpeggio Thickener Arpeggio Chords Arpeggio Chords Chords Thickener Arpeggio w/Electric Chords w/Acoustic w/Electric w/Electric w/Acoustic w/Electric w/Acoustic w/Acoustic Guitar Guitar Guitar Guitar Guitar Guitar Guitar Guitar LEVEL TONE LEVEL LEVEL TONE LEVEL TONE...

  • Page 7: Specifications

    SPECIFICATIONS Electronic Sample Rate: 44.1 kHz Frequency Response: 20 Hz-11 kHz (E ect Enabled) Signal to Noise Ratio: > -105 dB (A weighted); ref = max level, 22 kHz bandwidth THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain A/D/A Conversion: 24-bit Input...
  • Page 8 WEB: digitech.com SUPPORT: support@digitech.com Mosaic Owner’s Manual 5044262-C © 2022 CORTEK Corp. All rights reserved. DigiTech is a registered trademark of CORTEK Corp.
