Summary of Contents for DigiTech MonoNeon Whammy

  • Page 3: Table Of Contents

    Gaffer’s Tape - Neon Yellow & Neon Orange Guided Tour Mini Permanent Marker Connections Effects If anything is missing, please contact the Mothership MIDI at digitech.com at once. If nothing is missing, visit us Calibration anyway to check out our other products. Info PAGE 1...

  • Page 4: Welcome

    From MonoNeon Hey y’all, it’s MonoNeon here. I’m so excited to share with you my latest junt...the new DIgiTech MonoNeon Signature Whammy pedal!! It was a blast collaborating with the guys at DigiTech... creating a twist aesthetically and sonically on the classic Whammy pedal with a ton of new features that I love so much, mane...!!

  • Page 6: Guided Tour

    GUIDED TOUR - Whammy Controls 1. Expression Pedal This pedal is used to control the amount of pitch 2 3 4 bending of the selected Whammy, Harmony, Octaver or Detune effect. Rocking it forward (toe down) increases the amount of pitch bending while rocking it backward (toe up) decreases the amount of pitch bending.
  • Page 7 GUIDED TOUR - Whammy Controls 7. Octaver 4. Whammy LEDs One of these three LEDs will light when an Octaver One of these ten LEDs will light indicating which effect is selected. Octaver effects work well with Whammy effect is selected. Whammy effects playing chords and add octaves above or below to let you bend the pitch of your guitar/bass up or your original signal.
  • Page 8 GUIDED TOUR - Inputs & Outputs 1. Instrument Input Connect your guitar, bass, or any other instrument to this jack. 2. MIDI Input Connect an external MIDI control device to this jack for the purpose of controlling the Whammy remotely. 3.

  • Page 9: Connections

    CONNECTIONS The Whammy pedal is easy to set up and use. Follow these steps to get set up and get creating. 4.Connect the included power supply to an AC outlet and the other end to the 1.Connect your instrument to the Whammy’s Whammy’s Power Input.

  • Page 10: Effects

    EFFECTS - Whammy Whammy Effects This group of effects will bend your incoming 2 OCT UP Bends input note two octaves up. signal either up or down depending upon the effect setting you have chosen. As the 1 OCT UP Expression Pedal is rocked back and forth, the Bends input note one octave up.
  • Page 11 EFFECTS - Detune & Hypersonic Detune Effect This effect mixes your original signal with a moderately detuned copy of your signal creating a thick layered effect. As the Expression Pedal is rocked back and forth, the level of this detuned signal is changed.
  • Page 12 EFFECTS - Harmony Harmony Effects This group of effects adds a pitch-shifted harmony 4TH UP / 5TH UP to your incoming signal. Both the harmony note Bends the harmony between a fourth (toe up) and the input signal are mixed together as if two and a fifth (toe down) above the input note.
  • Page 13 EFFECTS - Octaver Octaver Effects These effects will add an octave-shifted signal to OCT UP / 2 OCT UP your incoming signal. As the Expression Pedal is Morph between a Dry+ Octave up tone rocked back and forth you can morph between to a Dry+ 2 Octave up tone.

  • Page 14: Midi - Channel Selection

    MIDI - Channel Selection The Whammy features a MIDI Input for receiving incoming MIDI data. MIDI messages can select a Whammy effect and set whether CHANNEL 1 the effect is in an active or bypassed state. CHANNEL 2 MIDI CC messages can then be used to control CHANNEL 3 the Whammy Expression Pedal position.
  • Page 15 MIDI - Continuous Control Using MIDI continuous control commands, the Whammy’s Expression Pedal position can be remotely controlled. MIDI CC11 adjusts the Expression Pedal position. A value of 0 on MIDI CC11 corresponds to a toe up position and a value of 127 corresponds to a toe down position.
  • Page 16 MIDI - PROGRAM CHANGE MAPPING - Classic Mode The Whammy uses MIDI Program Change commands for effect selection. Effects can be selected in either an active or bypassed MIDI PROGRAM CHANGE NO. state. The following illustrations show the MIDI Program Change mappings for Classic mode and Chords mode.
  • Page 17 MIDI - PROGRAM CHANGE MAPPING - Chords Mode CHORDS MODE When set to Chords mode, the following illustration outlines the Program Change MIDI PROGRAM CHANGE NO. commands recognized by the Whammy and the corresponding effect setting and its status. MIDI program changes override the physical position of the classic/chords switch.

  • Page 18: Calibration

    CALIBRATION In the unlikely event that the Expression Pedal 1.Disconnect the power from the does not respond properly or that the note Whammy pedal. does not bend or return to the correct pitch, 2.Press and hold the Whammy Effect it may need to be re-calibrated. The following Footswitch while reconnecting the power.

  • Page 19: Info

    INFO - Specifications Instrument Input Type: Unbalanced ¼” TS phone jack Max Input Level: +5 dBu Input Impedance: 1 M� MIDI Input: 5-Pin DIN Unbalanced ¼” TS phone jack Output Type: Max Output Level: +10 dBu Output Impedance: 1 k� Frequency Response: 20 Hz to 20 kHz Signal to Noise Ratio:...
  • Page 20 We know the road can be an unforgiving place and hard on your gear. Replacement parts are available from www.digitech.com. 1. SCRW-0102 Grounding Bracket Screw 2. NUTT-0100 Treadle Nut 3. SCRW-0101 Chassis Screw 4. SCRW-0100 MIDI Screw 5. MCCA-0202 Antiskid Pad 6.
  • Page 21 Warning Electromagnetic Compatibility To minimize potential electronic interference For your protection, please read the following: radiated to other electronic equipment, this Important Safety Instructions product includes two clip-on ferrite cores 1. Read these instructions. that should be clamped around the INPUT 2.

  • Page 22: Electromagnetic Compatibility

    ELECTROMAGNETIC COMPATIBILITY This device complies with part 15 of the FCC Rules and the Product Specifications noted on the Declaration of Conformity. Operation is subject to the following two conditions: These symbols are internationally accepted symbols that warn of potential •...
  • Page 23 BS / EN 55032:2015+A11:2020 Murray, UT 84107 BS / EN 50130-4:2011+A1:2014 BS / EN 55035:2017+A11:2020 BS / EN IEC 61000-3-2:2019 Contact: Your local DigiTech sales office, or visit the DigiTech website at BS / EN 61000-3-3:2013+A1:2019 www.digitech.com, or contact: EN 61000-3-3:2013+A1:2019 EN 61000-4-2:2009 CORTEK Corp.

  • Page 24: Warranty

    DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect, provided the product is returned to an authorized DigiTech location, where all parts and labor will be covered up to a period of one year from date of purchase.

  • Page 25: Special Thanks

    SPECIAL THANKS MonoNeon artistic inspiration and drive artist management and production Matt Anderson Logan Schaal artist photography ideas, drive, and hypersonic DSP, etc. ideas, parts, and more parts Roger Brent code and recode ideas, stickers, manual Brittany Kiki’s Art Service musician marginals :-) production test Isaac...
  • Page 28 Copyright © 2024 LITP-0004 Rev B DigiTech 6132 S 380 W Murray, UT 84107, USA www.digitech.com...
