Loading the Dishwasher
Before placing the dishes in the dishwasher, remove the large food
particle to the prevent the filter from becoming clogged, which re-
sults in reduced performance.
If the pots and pans have baked-on food that is extremely hard to
remove, we recommend that they be allowed to soak before they
are washed. This will eliminate the need for extra wash cycles.
Pull out the rack to facilitate loading the dishwasher.
How to Use the Lower Rack
We recommend that you place the most difficult to clean items on
the bottom rack: pots, lids, serving dishes and bowls, as shown in
the figure to the right.
It is preferable to place serving dishes and lids on the sides of the
racks in order to avoid blocking the rotation of the top spray arm.
- Pots, serving bowls, etc. must always be placed top down.
- Deep pots should be slanted to allow the water to flow out.
- The silverware basket can be doubled (see fig. A) so that only
one section may be used when the silverware load is light. this
also makes space for additional pots and pans, and it can also
be placed in the upper rack.
- Silverware should be placed in the silverware basket with the
handles at the bottom; if the rack has side baskets, the spoons
should be locaed individually into the appropriate slots. Espe-
cially long utensils should be placed in the horizontal position at
the front of the upper rack.
How to Use the Upper Rack
The upper rack is designed to hold more delicate and lighter
dishware, such as glasses, coffee and tea cups and saucers, as
well as plates, small bowls and shallow pans (as long as they are
not too dirty).
Position the dishes and cookware so that they do not get moved
by the spray of water.
The upper rack can be adjusted for height by using the knobs
located on the sides of the rack itself (see fig. B).
Warning
Important wiring instructions for plug UK only
WARNING: THIS APPLIANCE MUST BE BARTHED
The cords in this mains lead are coloured in accordance with the
following code: (see fig.C)
*Green/Yellow
*Earth
*Blue
*Neutral
*Brown
Connecting instructions
As the colours of the cores in the mains lead of this appliance
may not correspond with the coloured markings indentifying the
terminals in your plug proceed as follows:
Lower Rack
Upper Rack
Load for 12 Standard Settings
1
3
fig.A
Green/Yellow
Green/Yello
Brown
Blue
L
N
fig.C
* The core which is coloured GREEN/YELLOW must be connected
to the terminal which is marked with the letter E or by the earth sym-
bol or coloured GREEN/YELLOW.
* The core which is coloured BLUE must be connected to the termi-
nal which is marked with the letter N.
* The core which is coloured BROWN must be connected to the
*Live
terminal which is marked with the letter L.
If the terminals of your 3 pin plug are unmarked or if your
installation is fitted with a 2 pin plug, consult a qualified
electrician.
If a 10 AMP plug is fitted, fit 13 AMP fuse.
.5.
Turning on the Appliance
Starting a wash cycle
- Make sure that the plug for the appliance is inserted into the wall
socket.
- Make sure that the water supply is turned on to full pressure.
- Load the dishwasher (see the section entitled, "Loading the
Dishwasher").
- Pour in the detergent (see the section entitled, "Salt, Dergent
and Rinse Aid").
- Turn the knob located on the right of the control panel in the
clockwise direction until the number or symbol for the cycle set-
ting is aligned with the reference mark (see the section entitled,
"Wash Cycle Table").
- Press the ON-OFF button, and the ON-OFF light will turn on. At
this point, the wash cycle will begin.
If you forget to load some of the dishes
2
The wash cycle can be interrupted by pressing the ON-OFF button.
You can then load additional dishes and turn the appliance back
on. The cycle will start where it left off.
4
At the end of the wash cycle
fig.B
When the knob stops turning and is aligned with a STOP mark
(see figure), the cycle has finished. Turn off the appliance using
the ON-OFF button, turn off the water supply and open the door
of the dishwasher.
GB
GB
Wait a few minutes before unloading the dishwasher to avoid
handling the dishes and utensils while they are still hot and more
susceptible to breakage. They will also dry better.
1
4
2
STOP
3
Cancelling or modifying a wash cycle setting
Premise: A cycle that is underway can only be modified if it has
only been running for a short time. Otherwise, the detergent may
have already been used, and the appliance mayhave already
drained the wash water If this is the case, the detergent dis-
penser must be refilled (see the paragraph entitled, "Loading
the Detergent").
Press the ON-OFF button, and the ON light will turn off. Rotate
the knob in the clockwise direction to the desired cycle setting
(see the section entitled: Starting a wash cycle
the dishwasher back on using the ON-OFF button.
.6.
. Then, turn
