- Page 1 WQP12-BFE Dishwasher Service Manual Models: WQP12-BFE WQP12-HFE WQP12-HFE ME Features A grade save energy Delay washing Conceal heater and avoid heater turf burning ● Half load washing Haier Group Manual code: 0120501663 Edition:2003.01.01...
-
Page 2: Table Of Contents
Contents 1. Product Code illumination and Series introduction …………………….………...3 2. Features………………………………………………… ……………………………….4 3. Specifications…………………………………………… ………………………………4-6 4. Safety Precaution………………………………………… ………………………….…7-8 5. Warning and Cautions………………………………… ……………………………….9-10 6. Net Dimension……………………………………………………………………………11 7. Installation and Accessory Parts…………………… ………………………………….11-12 8. Parts and Functions………………………………… ………….. ………………...…...13-17 9. Function Schedule………………………………………………………………………..18 10. -
Page 3: Product Code Illumination And Series Introduction
F: Freestanding/built –in/semi-built-in G: Mechnical/electronic H: The second series of factory design,code name delicatied./outter side material.. Example: WQP12-BFE It represents automatic spraying electronic freestanding dishwasher,the cavity capacity is 12 standard sets. WQP12-BFESS It represents automatic spraying electronic freestanding dishwasher,the cavity capacity is 12 standard sets,with stainless steel outter side. -
Page 4: Features
Half loading fashtion which the upper-rack only mode is available get saving electricity and water consumption,if the dishwares is not too mush. 3.Specifications DISH WASHER FREE STANDING Last update 2002-5-23 Supplier Type N°. WQP12-BFE Suppliers bar code N°. Sales Brand / Model GXCH Sales bar code N°. Key-features Energy efficiency Class Washing efficiency... - Page 5 Specifications Programs (incl. additional programme functions) n°. Programme selection single dial / electronic Washing temperatures °C 40/50/70 Spray levels n°. Certification's (CE / LGA / ISO 9001 / ISO 9002) CE / ISO 9001 Technical equipment Work top / -removable Decor frame / optional Water heating element hidden / open...
- Page 6 Specifications Programs Normal C° Intensive C° Economic C° Delicate or Light wash C° Rinse C° Mixed C° Rapid C° Pre-wash (soak) C° Cold water Additional program settings (optional function keys) Half load Economic Rapid Delicate glasses Technical data Voltage/frequency V/Hz 220-240V~50Hz Nominal power 2150...
-
Page 7: Safety Precaution
Safety Precaution 4. Safety Precaution - 7 -... - Page 8 Safety Precuation - 8 -...
-
Page 9: Warning And Cautions
Warning and Cautions 5. Warning and Cautions 1.Shelf(The container which dishes are put in is called shelf) 2.Put the shelf into the washing box 3.Put in detergent 4.End of cycle - 9 -... - Page 10 Warning and Cautions 5.Weekly maintenance - 10 -...
-
Page 11: Net Dimension
Net dimension / Installations and Accessory Parts Net dimension 7. Installations and Accessory Parts 7.1 Positioning the Appliance Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned on the right or the left to facilitate proper installation. - Page 12 Installationan and Accessory Parts appliance is level,it will help ensure proper performance. 7.3 Cold Water Connection Connect the cold water supply hose to a threaded 3/4(gas) connector and make sure that it is fastened tightly in place (see Fig 1). If the water pipes are new or have not been used for an extended period of time,let the water run to make sure that the water is clear and free of impurities.If this precaution is not taken,there is a risk that the water inlet can get blocked and damage the appliance.
-
Page 13: Parts And Functions
Parts and Functions 8. Parts and functions A ON-OFF Button G Cycle select button B ON-OFF Light H Cycle indicator light C 1/2 load Button I Start/Pause button D 1/2 load indicator light J Low Rinse Aid Indicator Light E Delay select Button F Display delay time K Low Salt Indicator Light A Upper Rack... - Page 14 Parts and functions Salt The hardness of the water varies from place to place. If hard water is used in the shwasher,deposits will form on the dishes utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.
- Page 15 hardness of the water being used. It is recommended that adjustments be made in accordance with the following scheme: Detergent Detergent specifically intended for use with dishwashers must be used.The dispenser must be refilled before the start of each wash cycle following the instructions provided in the "Wash Cycle Table."...
- Page 16 Parts and functions There are 6 different settings; the normal dosage setting is 3. Important Proper dosage of the rinse aid improves drying. If drops of water remain on the dishes or spotting occurs,the dosage adjustor should be turned to a higher setting. If the dishes have white streaks,turn the dosage adjustor to a lower setting.
- Page 17 Parts and functions Lower Rack Upper Rack Load for 12 Standard Settings - 17 -...
-
Page 18: Function Schedule
Function Schedule 9. Function Schedule Intensive wash 1、 Hot pre-wash 13min Cold rinse 10min 70℃Main-wash 30min Cold rinse 6 min Hot rinse 24min Drying 19min Normal wash 2、 Pre-wash 17min 50℃Main-wash 55min Cold rinse 15min Hot rinse 28min Drying 19min Rapid wash 3、... -
Page 19: Program Diagram
Program Diagram 10. Program Diagram - 19 -... -
Page 20: Maintenances Service And Trouble Shooting
Maintenances Services and Trouble Shooting 11.1Maintenances Services It may occur that the dishwasher does not function or does not function properly Before calling for assistance,Iet us see what can be done first :have you forgotten to press one of the buttons or to perfom an essential operation? 11.2 Trouble Shooting analysis of the common breakdowns Door switch trouble... - Page 21 Maintenances Services and Trouble Shooting analysis of the common breakdowns Water supply trouble Phenomenon: water level cannot reach the required location Whether water is flowing in the hose Turn on the stopcock Whether the stopcock is turned on Whether solenoid valve measure whether solenoid valve is working is electrified...
- Page 22 Maintenances Services and Trouble Shooting analysis of the common breakdowns Drain pump trouble Phenomenon: water cannot be drained Whether drain pump is working Whether drain pump is electrifyed circuit is damaged Drain pump is broken Drain hose is too high Whether pipeline is ok is ok Drain hose is too...
- Page 23 Maintenances Services and Trouble Shooting analysis of the common breakdowns Heating trouble Phenomenon: water cannot be heated Check: Whether socket connector is connected well Connect it well Check resistence Replace the heater between the heater resistor Check whether the circuit Replace the temperature limiting between the two teminals device...
- Page 24 Maintenances Services and Trouble Shooting analysis of the common breakdowns Water overflow trouble Phenomenon: drain pump keep on working Whether water is deposited is Whether water flows out of Bottom the bottom case the water overflow conduit case is leaking check water supply change the solenoid valve...
- Page 25 Maintenances Services and Trouble Shooting analysis of the common breakdowns Power supply trouble Phenomenon: water cannot be heated Check: check whether the power connector Connect it properly check whether the power connector is in position is in position change the power Measure whether power supply switch Supply switch is OK...
-
Page 26: Circuit Diagram
Circuit Diagram 12.Circuit Diagram Washing pump Inlet valve Overflow switch softer valve Washing valve Disepenser Drain pump - 26 -... -
Page 27: Exploded View
exploded View 13.Exploded View - 27 -... -
Page 28: List Of Parts
Exploded View / List of Parts 14.List of Parts Part Specialized Uint price Name of part QTY. Remark code (EURO) Complete top 0120800378 Shelf fastening small block 012G2150035 Upper front crosspiece 012G1310022 Painted right side pannel 012G1020068 Right upright assembly 012G9350003 Upper basket 0120800590... - Page 29 Lower rear crosspiece 012G1310028 Terminal box assembly 012G2150046 012G2150053 Wheel for lower basket 012G2150052 Wheel for upper basket 012G2160208 Wheel support pin 012G2150054 Basket rail stop Mobile rail for basket 012G1020069 Tub gasket 0120300248 Support frame for tub gasket 012G1020082 Right bseboard side plate 012G2130482 Baseboard...
- Page 30 Upper sprayer assembly 012G9381017 Support for float 012G2160206 012G2110049 Float for Acquastop 012G6050040 Micro switch Elbi Type S3 0120400026 Power supply cable 012G2160197 Air outlet Breather ring nut 012G2150044 Thermo limiter assembly 0120800379 Drain pump 012G5040004 O-Ring 012G4050158 Drain hose assembly 012G2140061 Pressure switch tube 012G2140067...
- Page 31 Connection pipe 012G4050244 1-level pressure switch 012G6050031 Complete cup assembly 012G2160191 Rubber coupling 012G4050152 012G2150040 Ring nut for cup fastening 012G4050151 Cup gasket Microfilter (polyesthere) 012G1040014 Cylindric stainless steel filter 012G1040013 Stainless steel extractable filter 012G1040012 Extractable glass filter 012G2160212 Connector 012G2140093 Acquastop device...
- Page 32 Shell sound-deadening 0120300108 Suction condenser group 0120200192 012G2140089 Door gasket guard strip 0120200219 Tube for condenser D = 9 x 1.5 0120300107 Fan O-ring. 012G2140066 Cable duct 0120800353 Red indicator 012G6040017 Power switch 0124000084 Power key-press 0120200214 Key-press 0120200215 Time delay window 0120200292 Spring for closing lever 012G1040017...
-
Page 33: Damageable Parts List → Remark
Damageable Parts List → Remark 15.Damageable Parts List NO. In Part Specialized Uint price explored Name of part QTY. Remark code (EURO) view Terminal box assembly 012G2150046 Micro switch Elbi Type S3 012G6050040 1-level pressure switch 012G6050031 Acquastop device 012G9381036 Dishplay panel 0124000056 Red indicator...
