Summary of Contents for SUPAIR DELIGHT M
- Page 1 SUPAIR-VLD PARC ALTAÏS 34 RUE ADRASTÉE 74650 ANNECY CHAVANOD FRANCE User’s manual 45°54.024’N / 06°04.725’ E Revision Indice: 20120314 EN...
- Page 2 Thank you for your choice of a Supair DELIGHT. We are proud to join you on your journey in our common passion : paragliding. SUP’ A IR has been designing, producing and selling accessories for free flying activities since 1984. By choosing a SUP’ A IR product you benefit from almost thirty years of exper- tise, innovation and listening.
-
Page 3: Table Of Contents
All the pictures of this user’s manual were shot by Thomas De Dorlodot and Horacio LLo- rens during their 2011 expe- dition in Pakistan where they set many new records such as Himalayan distance record (225 km). More information on : www.xp.supair.com... -
Page 4: Introduction
Introduction Welcome to the world of lightweight performance! You have in your hands the key that opens the door to exceptional flights. The DELIGHT is our most persuasive invitation to adventure and with it you will be able to go higher, further and fly longer. Now, you just have to find a playground big enough ! After reading this manual, we suggest you check your harness by hanging in it before flying. -
Page 5: Technical Sheet
Technical specifications Model DELIGHT M DELIGHT L Technical sheet Pilot size 1 m 55 -1 m 90 1 m 70 -2 m 05 Weight 60 - 80 kg 75 - 100 kg Harness weight (+ carabiners+speedbar) 2,45 kg 2,7kg (+ 140g+ 43g) -
Page 6: Size Choice
For a complete list of our retailers, please click here : www.supair.com Size 1m55 1m60 1m65 1m70 1m75 1m80 1m85 1m90 1m95... -
Page 7: Nomenclature
Nomenclature Speedbar Zicral 30 mm carabi- ners (x2) Rescue parachute handle Bumpair 14 cm Footrest Rescue parachute risers Unique size Cockpit O rings (x2) Maillon Rapide ® Inox 7 mm (x1) -
Page 8: Harness Overview
Harness overview This illustration will help you during your reading. Right ventral buckle Left automatic ventral buckle Safe-T-bar (Sup’ A ir patent A1-1832/981) Thigh strap buckle Ventral width adjustment Leaning setting Shoulders’straps adjustment Back pocket Feet glide part Speedbag leaning adjustment Footrest Speedbag closing buckles 12 13... -
Page 9: Storage And Attachments
Storage and attachments Cockpit Lateral storage poc- Walking poles holder (handgrip top) Back pocket pour ballast (≈ 3l) Under seating pocket for ballast (3 litres) -
Page 10: Rescue Parachute Pocket Characteristics
• 4 flaps back pocket. • Cable locking. • Handle on the right-hand side. • Volume : 3 to 6,5 litres. • Compatible with the SUPAIR light and X-tralite res- DELIGHT rescue para- cue parachutes and other solo rescue parachutes. chute handle... -
Page 11: Placing The Parachute In The Rescue Parachute Pocket
Placing the parachute in the rescue parachute pocket Thanks for reading carefully ! We recommend the initial rescue parachute assembly and installation is made by a qualified person. Upper flap grommets Under flap grommets 1. Place the risers’ straps and 2. -
Page 12: Connecting The Rescue Parachute Risers To The Harness : Y Risers
Connecting the rescue parachute risers to the harness : Y risers 1. Place the Maillon Rapide® 2. Pass the riser inside 3. Make a new twisted 4. Repeat steps #1, #2 and (locking nut upwards and on the free loop and inside loop with the ring and #3 with another O-ring for the exterior side) inside the web-... -
Page 13: Connecting The Rescue Parachute Risers To The Harness : Standard Risers
Connecting the rescue parachute risers to the harness : standard risers 1. Make a lark’s head 2. Fasten the lark’s head Your DELIGHT is fitted with light standard parachute risers between the risers and neatly the webbing loop for rescue attachment. 3. -
Page 14: Cockpit And Bumpair Assembly
Cockpit and BUMPAIR assembly Female buckle C - Pass the male buckle on speedbag A- Connect the female buckle (1) to the Harness (7) through the the strap loop with snap male buckle (2). Male buckle fasteners (6) and connect it to the female Cockpit buckle (3) of the harness. -
Page 15: Speedbar Assembly
Speedbar assembly A light speedbar is provided with harness. The following illustration shows how to install it. Composition Braided ropes First bar Centering spacer Second bar Pass the speedbar braided rope in- side the plastic keeper. Speedbar hook Pass the speedbar braided rope outside the strap. -
Page 16: Position Setting
Position setting Setting your position inside the harness before taking-off is extremely important. Lateral buckles Under seating buckle Tightening snapper (leaning setting) Loosening strap (leaning setting) Lumbar adjustment buckle Tightening snapper (shoulder strap) Loosening strap ( shoulder strap) -
Page 17: Speedbag Angle Setting
Speedbag angle setting With the help of the two lateral and under seating buckles, set the angle of the speedbag around horizontal position. Leaning angle setting Set the angle of leaning by tightening the snapper (towards a more tighten vertical position) or the black webbing (towards a more horizontal position). -
Page 18: Flight Behaviour
Flight behaviour The DELIGHT has equipped several X-ALPS 2011 pilots. It is consequently a high performance har- ness designed for XC flights, for competitions as well for bivy-flying adventures. But it is also aimed at “hike and fly” or high-mountain flying. -
Page 19: Pre-Flight Control
Pre-Flight control • Check that the harness and the carabiners did not deteriorate. • Check thoroughly that the rescue handle’s cable end has not got outside the snappers’ flaps. • Check that your personal settings haven’t changed. • Check that all zippers and buckles are closed. • Check that the speedbar is correctly connected and set. -
Page 20: Take-Off
Take-off After being correctly fitted into your harness, fasten the left buckle (1, on braided rope) of the speedbag then fasten the second speedbag buckle (2). During take-off, maintain a standing position and as soon as you are far enough from the ground, fetch the speedbag with one of your heels. -
Page 21: In Flight
In flight As soon as you are airborne, the behaviour is very instinctive and precise. Please set the distance between the two carabiners according to aerology and to wing’s manufacturer recommendations. Tightening provides more stability but less harness piloting efficiency. Be careful as it increas- es the risk of risers twisting. -
Page 22: Landing
Landing In order to land, during the approach, take your legs out of the speedbag in plenty of time. Stand up inside the harness and adopt an upright position in order to run to dissipate hori- zontal speed. Do not land whilst in the seated position, this is dangerous. Throwing the reserve parachute We strongly advise you to check frequently the location of the reserve parachute’s handle. -
Page 23: Complements/Accessories
MAILCONNECT Connect 12 g (part) Soft Dyneema® sleeved carabiners Rescue parachute PARXTRALITE S Parachute SUPAIR X-tralite S (PTV Max 80 kg) < 1 kg PARXTRALITE M Parachute SUPAIR X-tralite M (PTV Max 95 kg) < 1,2 kg PARXTRALITE L Parachute SUPAIR X-tralite L (PTV Max 115 kg) <... -
Page 24: Wash And Care Of Your Harness
Care Wash and care of your harness It is a good idea to wash your harness from time to time. To do this, we recommend to use a soft solvent (such as soap), use a brush and rinse thoroughly. In any case, do not use chemicals such as detergents or strong solvent because it may deteriorate the webbing, stitching and fabrics of your harness. -
Page 25: Repair
SUP’ A IR offer a repair facility for their products beyond the end of the warranty period. Please con- tact us either by telephone or by E-mail sav@supair.com in order to receive a quotation. Materials... -
Page 26: Warranty
Warranty Warranty SUP’ A IR takes the greatest care in the design and production of its products. SUP’ A IR guarantees its products 5 years (from purchase date) against any defect or design fault occurring during nor- mal use. Any damage or degradation resulting from incorrect or abusive use, abnormal exposure to aggressive factors, including, but not limited to;... -
Page 27: Service Book
Service Book This page will help you to record all the life stages of your harness. Serial number : Care Care Purchase date Resale Resale Owner’s name : Date Date Name and stamp of the shop : Workshop’s name/ Buyer’s name Workshop’s name/ Buyer’s name Care Care... - Page 28 SUPAIR-VLD PARC ALTAÏS 34 RUE ADRASTÉE 74650 ANNECY CHAVANOD FRANCE 45°54.024’N / 06°04.725’ E...
